Thermaltake Pacific RL240 User Manual

Pacific
RL240
Hard Tube
Water Cooling Kit
Cautions: Make sure there's enough space when you start set up the LCS product
Radiators
To ensure a clean loop, flush and rinse your radiators
and water blocks with distilled water before using.
Make sure the fittings are screwed securely when
placing them onto the radiator.
Pump and Reservoir
Choose the proper way to mount the pump and reservoir
by referring to the manual (suggest vertical palcement)
or
1
Place the motherboard into the case.
Cautions:
Make sure there's enough space when you start to set up your LCS products.
It requires a hard tube bending kit to bend and install the tube, ex. Pacific Hard Tube Bending Kit.
This product is intended for installation only by expert users. Please consult with a qualified technician for installation.
Improper installation may result in damage to your equipment.
1. Please carefully read the manual before beginning the installation process !
2. It is strongly recommended to use market proven pre-mix coolant, such as Thermaltake Coolant 1000.
3. DO NOT USE any kind of alcohol or alcohol derivatives with this reservoir or the acrylic tube may crack and fail !
Do not clean it using alcohol either !
Before Installation
Installation Walkthrough
Case Fan
Attach the fans to the radiator
Attach fittings onto the pump and reservoir
(Example: Core V51)
2
Position the radiator.
Water Blocks
Attach the fittings to the inlet and outlet of the
waterblock.
Attach the waterblock onto the motherboard by
referring to the enclosed manual.
3
Attach the pump and reservoir into
the chosen locations.
