welcoming
OPTION 1
(Semi-Recessed Sink)
30-IN VANITY WITH TOP
ITEM #4767938; 4767939; 4767936; 4767937; 1028459; 1028443; 864220; 3839336; 864221;
3839335; 4767934; 4767935; 4767932; 4767933; 720428; 1028439; 720451; 3839334;
720456; 3839333; 720444; 1028440; 720433
MODEL #2026VA-30-242-926; 2026VA-30-242-926-SR; 2026VA-30-242-925; 2026VA-30-242-925-SR;
2026VA-30-242-906; 2026VA-30-242-905; 2026VA-30-242-901; 2026VA-30-242-901-SR;
2026VA-30-242-900; 2026VA-30-242-900-SR; 2026VA-30-201-926; 2026VA-30-201-926-SR;
2026VA-30-201-925; 2026VA-30-201-925-SR; 2026VA-30-201-906; 2026VA-30-201-905;
2026VA-30-201-901; 2026VA-30-201-901-SR; 2026VA-30-201-900; 2026VA-30-201-900-SR;
2026VA-30-200-906; 2026VA-30-200-905; 2026VA-30-200-901
ATTACH YOUR RECEIPT HERE
Serial Number__________________ Purchase Date__________________
Questions, problems, missing parts? Before returning to your retailer, call our customer service
department at 1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Sunday.
•
sophisticated
OR
1
•
inspiring
OPTION 2
(Undermount Sink)
Advertisement
Table of Contents
Related Manuals for Allen + Roth 2026VA-30-242-926
Summary of Contents for Allen + Roth 2026VA-30-242-926
- Page 1 ITEM #4767938; 4767939; 4767936; 4767937; 1028459; 1028443; 864220; 3839336; 864221; 3839335; 4767934; 4767935; 4767932; 4767933; 720428; 1028439; 720451; 3839334; 720456; 3839333; 720444; 1028440; 720433 MODEL #2026VA-30-242-926; 2026VA-30-242-926-SR; 2026VA-30-242-925; 2026VA-30-242-925-SR; 2026VA-30-242-906; 2026VA-30-242-905; 2026VA-30-242-901; 2026VA-30-242-901-SR; 2026VA-30-242-900; 2026VA-30-242-900-SR; 2026VA-30-201-926; 2026VA-30-201-926-SR; 2026VA-30-201-925; 2026VA-30-201-925-SR; 2026VA-30-201-906; 2026VA-30-201-905;...
- Page 2 MODEL NUMBER DESCRIPTION 2026VA-30-242-926 RVLND 30-IN VTY LGRY ECLT TOP 2026VA-30-242-926-SR RVLND 30-IN VTY LGRY ECLT SR 2026VA-30-242-925 RVLND 30-IN VTY LGRY EC TOP 2026VA-30-242-925-SR RVLND 30-IN VTY LGRY EC SR 2026VA-30-242-906 RVLND 30-IN VTY LGRY DK GY TOP 2026VA-30-242-905...
-
Page 3: Table Of Contents
TABLE OF CONTENTS FOR OPTION 1 (Semi-Recessed Sink) Package Contents...........................4 Hardware Contents..........................4 Safety Information..........................4 Preparation............................5 Assembly or Installation Instructions ....................5 Care and Maintenance........................11 Warranty............................11 Replacement Parts List........................12 TABLE OF CONTENTS FOR OPTION 2 (Undermount Sink) Package Contents.........................14 Hardware Contents........................14 Safety Information..........................14 Preparation............................15 Assembly or Installation Instructions .....................15 Care and Maintenance........................21... -
Page 4: Package Contents
PACKAGE CONTENTS (Semi-Recessed Sink) PART DESCRIPTION QUANTITY CARTON Vanity box 2 of 3 box 1 of 3 Backsplash Sink box 3 of 3 Left Door (preassembled to vanity (A)) Right Door (preassembled to vanity (A)) Left Drawer (preassembled box 2 of 3 to vanity (A)) Right Drawer (preassembled... -
Page 5: Preparation
PREPARATION Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product. Estimated Installation Time: 45 minutes (24 hours for silicone caulk to dry). Tools Required for Installation (not included): Phillips screwdriver, utility knife or scissors, silicone caulk, power drill with drill bit, measuring tape, level INSTALLATION INSTRUCTIONS (Semi-Recessed Sink) - Page 6 INSTALLATION INSTRUCTIONS (Semi-Recessed Sink) 3. Using hardware appropriate for your wall type (not included), secure vanity cabinet (A) to two wall studs anywhere through the vanity mounting plates. Be careful not to disturb any electrical or water lines that may be concealed in the wall.
- Page 7 INSTALLATION INSTRUCTIONS (Semi-Recessed Sink) Note: A t this stage it may be easier to install the faucet and drain kit (not included) to top (B) per the manufacturer’s instructions, before moving on to Step 5. 5. Apply stain free silicone caulk (not included) to the top edge of vanity (A).
- Page 8 INSTALLATION INSTRUCTIONS (Semi-Recessed Sink) 7. Apply a thin bead of silicone caulk (not included) onto the stone top close to the edge of the sink cut out as pictured. 8. With the help of another adult, Gently lower the sink onto the stone top using even pressure to set the sink properly.
- Page 9 INSTALLATION INSTRUCTIONS (Semi-Recessed Sink) 9. To re-install drawers into vanity (A). Please fully extend metal glide tracks, gently lower and slide drawer box into rear glide catch, then, lower drawer box down to completely rest on extended glides, push plastic levers to lock the drawer box in place.
- Page 10 INSTALLATION INSTRUCTIONS (Semi-Recessed Sink) 11. Apply silicone caulk (not included) to unpolished side and bottom of backsplash (C). Position backsplash (C) on top (B) and against wall. Clean any excess caulk before allowing to dry. Assembly is now complete. Install desired faucet and drain assemblies (neither included) per the manufacturers’...
-
Page 11: Care And Maintenance
CARE AND MAINTENANCE • Dust the vanity regularly with a soft, non-lint producing cloth or household dusting product. • You can clean the vanity with a gentle, non-abrasive household cleaner. • Make sure to dry the wood immediately with a soft cloth or towel. •... -
Page 12: Replacement Parts List
REPLACEMENT PARTS LIST FOR 2026VA-30-201-SR (Semi-Recessed Sink) For replacement parts, call our customer service department at 1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Sunday. PART DESCRIPTION PART# Complete Set 30" Carrara Marble Top 3500VT-30-900 Complete Set 30" Engineered White Top 3500VT-30-901 Complete Set 30"... - Page 13 REPLACEMENT PARTS LIST FOR 2026VA-30-242-SR (Semi-Recessed Sink) For replacement parts, call our customer service department at 1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Sunday. PART DESCRIPTION PART# Complete Set 30" Carrara Marble Top 3500VT-30-900 Complete Set 30" Engineered White Top 3500VT-30-901 Complete Set 30"...
-
Page 14: Package Contents
PACKAGE CONTENTS (Undermount Sink) PART DESCRIPTION QUANTITY CARTON Vanity box 2 of 3 box 1 of 3 Backsplash Sink box 3 of 3 Left Door (preassembled to vanity (A)) Right Door (preassembled to vanity (A)) Left Drawer (preassembled box 2 of 3 to vanity (A)) Right Drawer (preassembled... -
Page 15: Preparation
PREPARATION Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product. Estimated Installation Time: 45 minutes (24 hours for silicone caulk to dry). Tools Required for Installation (not included): Phillips screwdriver, utility knife or scissors, silicone caulk, power drill with drill bit, measuring tape, level INSTALLATION INSTRUCTIONS (Undermount Sink) - Page 16 INSTALLATION INSTRUCTIONS (Undermount Sink) 3. Using hardware appropriate for your wall type (not included), secure vanity cabinet (A) to two wall studs anywhere through the vanity mounting plates. Be careful not to disturb any electrical or water lines that may be concealed in the wall.
- Page 17 INSTALLATION INSTRUCTIONS (Undermount Sink) 5. Apply silicone caulk (not included) to the top edge of sink (D). With the help of another adult, lower the sink onto the back side of the stone top. Make sure the sink over-flow hole is facing the front of stone top.
- Page 18 INSTALLATION INSTRUCTIONS (Undermount Sink) 7. Lower the sink brackets (BB) over the bolts (AA) and allow to rest on the sink lip. Adjust location of bracket to firmly grasp sink lip. Lower lock washers (DD) over bolts (AA) and secure with nuts (CC). Hand tighten nuts (CC) with included wrench (EE).
- Page 19 INSTALLATION INSTRUCTIONS (Undermount Sink) 9. To re-install drawers into vanity (A). Please fully extend metal glide tracks, gently lower and slide drawer box into rear glide catch, then, lower drawer box down to completely rest on extended glides, push plastic levers to lock the drawer box in place.
- Page 20 INSTALLATION INSTRUCTIONS (Undermount Sink) 11. Apply silicone caulk (not included) to unpolished side and bottom of backsplash (C). Position backsplash (C) on top (B) and against wall. Clean any excess caulk before allowing to dry. Assembly is now complete. Install desired faucet and drain assemblies (neither included) per the manufacturers’...
-
Page 21: Care And Maintenance
CARE AND MAINTENANCE • Dust the vanity regularly with a soft, non-lint producing cloth or household dusting product. • You can clean the vanity with a gentle, non-abrasive household cleaner. • Make sure to dry the wood immediately with a soft cloth or towel. •... -
Page 22: Replacement Parts List
REPLACEMENT PARTS LIST FOR 2026VA-30-200 (Undermount Sink) For replacement parts, call our customer service department at 1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Sunday. PART DESCRIPTION PART# Complete Set 30" Engineered White Top 2500VT-30-901 Complete Set 30" Terrazzo Top 2500VT-30-905 Complete Set 30"... - Page 23 REPLACEMENT PARTS LIST FOR 2026VA-30-201 (Undermount Sink) For replacement parts, call our customer service department at 1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Sunday. PART DESCRIPTION PART# Complete Set 30" Carrara Marble Top 2500VT-30-900 Complete Set 30" Engineered White Top 2500VT-30-901 Complete Set 30"...
- Page 24 REPLACEMENT PARTS LIST FOR 2026VA-30-242 (Undermount Sink) For replacement parts, call our customer service department at 1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Sunday. PART DESCRIPTION PART# Complete Set 30" Carrara Marble Top 2500VT-30-900 Complete Set 30" Engineered White Top 2500VT-30-901 Complete Set 30"...
