WIRELESS
Hardwire Photoelectric Smoke & Carbon Monoxide Alarm
with Voice and Wireless Interconnect
User Guide
Model P4010ACSCO-WCA
WIRELESS INTERCONNECT:
You do NOT need a home wi-fi system
to use these units. Multiple wireless
units create their own independent
wireless alarm network.
COMBINATION ALARM
120 V HARDWIRE
10-YEAR BATTERY BACKUP
HARDWIRE & WIRELESS
INTERCONNECT
VOICE ALARM
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Kidde P4010ACSCO-WCA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for United Technologies Kidde P4010ACSCO-WCA

Summary of Contents for United Technologies Kidde P4010ACSCO-WCA

  • Page 1 WIRELESS Hardwire Photoelectric Smoke & Carbon Monoxide Alarm with Voice and Wireless Interconnect User Guide Model P4010ACSCO-WCA WIRELESS INTERCONNECT: You do NOT need a home wi-fi system to use these units. Multiple wireless units create their own independent wireless alarm network. COMBINATION ALARM 120 V HARDWIRE 10-YEAR BATTERY BACKUP...
  • Page 2 Thank You for Purchasing this Kidde Alarm Hardwired for 120 V AC, this model features a non-replaceable, sealed-in battery backup. It also contains a voice message system and Hush Control to temporarily silence nuisance alarms. It is capable of both ®...

  • Page 3: Table Of Contents

    Contents 1. Smoke Alarm: What To Do When The Alarm Sounds ..4 2. Carbon Monoxide Alarm: What To Do When The Alarm Sounds ..5 3.

  • Page 4: Smoke Alarm: What To Do When The Alarm Sounds

    1. Smoke Alarm: What To Do When the Alarm Sounds Smoke alarm pattern is three long beeps with voice “Fire!,” a 1.5 second pause, and three long beeps repeating. The red LED blinks in time with alarm pattern. The smoke alarm takes precedence when both smoke and carbon monoxide are present. •...

  • Page 5: Carbon Monoxide Alarm: What To Do When The Alarm Sounds

    2. Carbon Monoxide Alarm: What To Do When the Alarm Sounds Carbon monoxide (CO) alarm pattern is four quick beeps with voice “Warning! Carbon Monoxide” repeating every 5 seconds. The red LED blinks in time with alarm pattern. WARNING: CARBON MONOXIDE ALARM ACTIVATION INDICATES THE PRESENCE OF CARBON MONOXIDE (CO) AT HIGH CONCENTRATIONS WHICH CAN KILL YOU.

  • Page 6: Other Alarm Visual And Audible Indicators

    3. Other Alarm Visual and Audible Indicators Operational Mode Visual Indications Audible Indications Action/Note: Normal (standby) AC power: Green LED on continuously during light conditions, or blink every 60 sec during dark conditions. DC power: Green LED blink approx every 60 sec. Test (button press when •...

  • Page 7: Troubleshooting Guide

    4. Troubleshooting Guide Trouble Condition Visual Indications Audible Indications Action: Low Battery Chirp every 60 sec, voice every * Remove, discharge, dispose unit, and replace as soon 30 sec: “Replace alarm.” as possible. Voice stops after 5 mins. Fault Mode Chirp every 30 sec.

  • Page 8: Introduction, Product Features & Specifications

    5. Introduction, Product Features and Specifications INTRODUCTION This alarm detects products of combustion using photoelectric technology and carbon monoxide using an electrochemical cell. Many times throughout this User Guide, we will refer to Carbon Monoxide as “CO.” Ten (10) years after the unit is installed, this unit will automatically alert you that it is time to replace the unit. This is called “End of Unit Life”...

  • Page 9: Limitations Of Smoke And Carbon Monoxide Alarms

    6. Limitations of Smoke and Carbon Monoxide Alarms WARNING: PLEASE READ CAREFULLY AND THOROUGHLY • Life safety from fire in residential occupancies is based primarily on early notification to occupants of the need to escape, followed by the appropriate egress actions by those occupants. •...
  • Page 10 WARNING: PLEASE READ CAREFULLY AND THOROUGHLY • IMPORTANT: This alarm is designed to detect carbon monoxide gas from ANY source of combustion. It is NOT designed to detect any other gas. This alarm will only indicate the presence of carbon monoxide gas at the sensor. Carbon CAUTION: monoxide gas may be present in other areas.

  • Page 11: Recommended Locations For Smoke Alarms

    10 cm 7. Recommended Locations for Smoke Alarms (4") 10 cm (4") ANYWHERE ALONG ANYWHERE ALONG THIS BOLD SURFACE THIS BOLD SURFACE 10 cm 10 cm (4") (4") 30.5 cm 30.5 cm (12") (12") • Locate smoke alarms in all sleeping areas. Try to monitor the exit path as the bedrooms are usually farthest 30.5 cm 30.5 cm from the exit.
  • Page 12 • For mobile home installation, select locations carefully to avoid thermal barriers that may form at the ceiling. For more details, see MOBILE HOME INSTALLATION section. • When mounting an alarm on the ceiling, locate it at a minimum of 10 cm (4") from the side wall. •...

  • Page 13: Locations To Avoid

    8. Locations to Avoid • In the garage. Products of combustion are present when you start your automobile. • Normal cooking may cause nuisance alarms. If a kitchen alarm is desired, it should have an alarm silence feature or be a photoelectric type. •...

  • Page 14: Setting Up A Wireless Alarm Network

    At any time during wireless alarm network setup, if you have a problem, you can push and hold NOTE: the Test/Hush button on any problem unit until you hear three (3) beeps (approx 8 sec), and then release the button. The unit will reset the unit’s wireless settings (described in Section 9.3). Once wireless network settings are reset, the unit will prompt the user to follow Quickstart instructions.

  • Page 15: Adding Another Device To An Existing Wireless Alarm Network

    D. PICK ONE DEVICE “Searching for other devices.” Press and hold the button on only ONE device until you hear two beeps. Release button. You will hear “Searching for other devices”. Hold for DON'T press buttons • 5 seconds on other devices The light will pulse and device will sound a continuous “Sonar”...
  • Page 16 A. REMOVE THE NEW DEVICE FROM ITS PACKAGING. B. POWER UP NEW DEVICE USE ACTIVATION TOOL OR SCREWDRIVER Locate the red wheel on the back of the device being added. Turn the red wheel to the “ON” position using the white activation tool included in the Quick Start Guide or a standard screwdriver.

  • Page 17: Resetting A Device's Wireless Settings

    F. PICK THE INSTALLED DEVICE “Setup complete!” Press and hold the button on the INSTALLED device for 5 SECONDS until you hear two beeps. Release button. ”Sonar” ping will stop. • Device will announce that setup is complete and the number of Installed Device Added Device connected devices.

  • Page 18: Wiring Instructions

    10. Wiring Instructions WIRING REQUIREMENTS • This alarm should be installed on a CSA-Listed or recognized junction box. All connections should be made by a qualified electrician and all wiring used shall be in accordance with codes having jurisdiction in your area. The multiple station interconnect wiring to the alarms must be run in the same raceway or cable as the AC power wiring.
  • Page 19 • A maximum of 24 Kidde Safety devices may be interconnected in a multiple station arrangement. The interconnect system should not exceed the NFPA interconnect limit of 12 smoke alarms and/or 18 alarms total (smoke, CO, Smoke/ CO Combination, heat, etc.). With 18 alarms interconnected, it is still possible to interconnect up to a total of 6 remote signaling devices and / or relay modules.
  • Page 20 • After selecting the proper location for your Alarm, and wiring the AC QUICK CONNECT harness as described in the WIRING INSTRUCTIONS, attach the mounting bracket to the electrical box. To ensure aesthetic alignment of the alarm with the hallway, or wall, the “A” line on the mounting bracket must be parallel with the hallway when ceiling mounted, or horizontal when wall mounted.
  • Page 21 The battery activation is a one-time feature. After activation, the battery cannot be turned off, NOTE: and can only be discharged at the end of unit life. If the alarm is removed from the mounting plate, the backup battery will remain active. See Permanently Disable Alarm / Discharge Battery section. The alarm is now activated! After installation / activation, test your alarm as described in Operation and Testing section.

  • Page 22: Operation And Testing

    11. Operation and Testing OPERATION The alarm is operating once it is activated and testing is complete. When products of combustion (smoke or CO) are sensed, the unit sounds a loud alarm with voice messages. See Sections 1 and 2 for alarm signal descriptions. In high levels of CO, the unit will go into alarm in a shorter period of time than at low levels of CO.

  • Page 23: Recognizing Nuisance Alarms

    AMBIENT LIGHT SENSING In low light ambient conditions, the green LED ring fades to off, and then blinks approx every 60 seconds. This unit samples the ambient light conditions of the alarm’s location and, if possible, determines a Night / Day cycle.
  • Page 24 This alarm is designed to minimize nuisance alarms. Cigarette smoke will not normally cause the unit to alarm, unless the smoke is blown directly into the alarm. Combustion particles from cooking may set off the alarm if it is located too close to a cooking appliance. Large quantities of combustible particles are generated from spills or when broiling.

  • Page 25: Battery Backup

    13. Battery Backup NOTE: This alarm is powered with AC power, but also contains a sealed lithium battery backup system. No battery installation or replacement is necessary for the life of the alarm. IMPORTANT: AC power must be connected to obtain the full 10 year battery and unit life. Constant exposure to high or low humidity or temperatures may reduce battery life.

  • Page 26: Permanently Disable Alarm / Discharge Battery

    14. Permanently Disable Alarm / Discharge Battery WARNING: FAILURE TO DISCHARGE ALARM BATTERY AS INSTRUCTED PRIOR TO DISPOSAL MAY CREATE POTENTIAL FOR LITHIUM BATTERY RELATED FIRE OR HAZARD. WARNING: DISCHARGING THE ALARM BATTERY IS PERMANENT • Once the alarm battery has been discharged, it cannot be reactivated! •...

  • Page 27: General Carbon Monoxide (Co) Information

    15. General Carbon Monoxide (CO) Information Carbon monoxide (CO) is a colorless, odorless, and tasteless poison gas that can be fatal when inhaled. CO inhibits the blood’s capacity to carry oxygen. POSSIBLE SOURCES OF CO Inside your home, appliances used for heating and cooking are the most likely sources of CO. Vehicles running in attached garages can also produce dangerous levels of CO.
  • Page 28 THE FOLLOWING CONDITIONS CAN RESULT IN TRANSIENT CO SITUATIONS: Excessive spillage or reverse venting of fuel-burning appliances caused by: (1) outdoor ambient conditions, such as wind direction and/or velocity, including high gusts of wind, and insufficient draft in the vent pipes; (2) negative pressure differential resulting from the use of exhaust fans;...
  • Page 29 SYMPTOMS OF CO POISONING Initial carbon monoxide poisoning symptoms are similar to the flu with no fever and can include dizziness, severe headaches, nausea, vomiting and disorientation. Everyone is susceptible but experts agree that unborn babies, pregnant women, senior citizens and people with heart or respiratory problems are especially vulnerable.

  • Page 30: Cleaning Your Alarm

    16. Cleaning Your Alarm YOUR ALARM SHOULD BE CLEANED AT LEAST ONCE A YEAR You can clean the interior of your alarm (sensing chamber) by using compressed air or a vacuum cleaner hose and blowing or vacuuming through the openings around the perimeter of the alarm.

  • Page 31: Good Safety Habits

    Storing the unit in a plastic bag during any of the above projects will protect the sensors from damage. When household cleaning supplies or similar contaminates are used, the area must be well ventilated. WARNING: REINSTALL THE ALARM AS SOON AS POSSIBLE TO ENSURE CONTINUOUS PROTECTION.
  • Page 32 • Current studies have shown smoke/CO alarms may not awaken all sleeping individuals, and that it is the responsibility of individuals in the household that are capable of assisting others to provide assistance to those who may not be awakened by the alarm sound, or to those who may be incapable of safely evacuating the area unassisted.
  • Page 33 NFPA (NATIONAL FIRE PROTECTION ASSOCIATION) FIRE SAFETY IN THE HOME: NFPA 72 IS INTENDED TO PROVIDE REASONABLE SAFETY FOR PERSONS IN FAMILY LIVING UNITS. REASONABLE FIRE SAFETY CAN BE PRODUCED THROUGH THE FOLLOWING THREE-POINT PROGRAM: (1) Minimizing fire hazards (2) Providing fire-warning equipment (3) Having and practicing an escape plan.

  • Page 34: Service And Warranty

    18. Service and Warranty TEN-YEAR LIMITED WARRANTY Kidde warrants that the enclosed alarm will be free from defects in material and workmanship or design under normal use and service for a period of ten years from the date of purchase. The obligation of Kidde under this warranty is limited to repairing or replacing the alarm or any part which we find to be defective in material, workmanship or design, free of charge, upon receiving the alarm with proof of date of purchase, postage and return postage prepaid, to: Kidde Canada Inc., P.O.
