Blaze Outdoor Products BLZ-36-VHOOD User Manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

user manual

Model #:

BLZ-36-VHOOD

Table of Contents

Need help?

Do you have a question about the BLZ-36-VHOOD and is the answer not in the manual?

Questions and answers

Summary of Contents for Blaze Outdoor Products BLZ-36-VHOOD

Page 1 Model #: BLZ-36-VHOOD...
Page 2: Table Of Contents
| Table of Contents Table of Contents Safety Notice III-V Diagrams Hood Dimensions Control Panel . Clearance . Installation 4-10 Instructions Venting Options Hood Installation Motor Rotation Instructions 11-12 Care & Cleaning Wiring Diagram Troubleshooting Warranty Information Warranty...
Page 3 IMPORTANT SAFETY NOTICE upon receipt of your hood: 1) Inspect your hood for any damage in shipping 2) Plug in and test controls (lights, fan) before installing . 3) Call your dealer immediately to report any damage Please note: You must report any damage directly to your dealer immediately upon receipt to address any issues.
Page 4: Safety Notice
| Safety Notices IMPORTANT SAFETY NOTICE Installer: Leave this guide with the homeowner. Consumer: Keep this guide for future reference. The Important Safety Notice and warnings in this manual are not meant to cover all possible problems and situations that can occur. Use common sense and caution when installing, maintaining or operating this or any other appliance.
Page 5 Safety Notices IMPORTANT SAFETY NOTICE Warning If you receive a damaged product, immediately contact your dealer. Do not install or use a ♦ damaged hood. Do not install, repair or replace any part of the range hood unless specifically recommend-ed ♦...
Page 6: Diagrams
BLAZE OUTDOOR clearance dimensions...
Page 7: Control Panel
USER MANUAL | Control Panel MAIN SWITCH FAN: To adjust the speed of motor, each motor has 4 speed settings. Turning the knob once clockwise will start the motor in the lowest speed setting. Continuing to turn the knob clockwise will allow the motor to advance to the highest setting.
Page 8: Clearance
BLAZE OUTDOOR clearance dimensions...
Page 9: Installation
USER MANUAL | instructions warning It is important to install the hood at the proper mounting height. Hoods mounted too low could result in heat damage and fire hazard. Hoods mounted too high will be hard to reach and will lose performance and efficiency. For best installation, we recommend you: Plug in and test controls (lights, fan) before installing.
Page 10 BLAZE OUTDOOR instructions Tools Needed Measuring Tape Utility Knife Marker or Pencil Level Powered Drill Flat & Phillips Screwdrivers...
Page 11 USER MANUAL | instructions Parts Supplied Range Hood Stainless Steel Baffle Filters: 6 PCS Grease Trays: 2 PCS Duct Connector 1 PCS Qty: 10 PCS Amounting Screws Qty: 7 PCS Qty: 8 PCS Mounting Bracket: 2 PCS Amounting Screws Qty: 4 PCS Wall Anchors Qty: 2 PCS...
Page 12: Venting Options
BLAZE OUTDOOR venting options Wall venting Option 1 vertical roof venting A -18” from the side edge of the hood to the center of the duct B - 5 11/16" from the wall to the center of the duct (using the included mounting bracket which is between the wall and hood and is roughly an 1/8”...
Page 13 USER MANUAL | 8 wall hood installation PREPARATION Plan where the ductwork will be located. Install proper-sized ductwork, and roof or wall cap, depending on where you will be venting your hood. Adjust your measurements to accommodate heights of ceilings, cabinets, or range-tops.
Page 14 BLAZE OUTDOOR wall hood installation STEP 2 Install the two grease trays in the front and back of the unit. When installed, these trays. will accept the grease filters on the bottom side. When installing the drip trays, place each tray in the recession at the front and rear as show in the drawing.
Page 15: Motor Rotation Instructions
USER MANUAL | 10 MOTOR ROTATION INSTRUCTIONS Getting Started The image to the right shows the position of the motors directly from the factory. This position of the motor is used when running vertical pipe for your venting. REMOVE COVER PLATE STEP 1 There are two sets of screws you will be working with on the cover plate.
Page 16: Care & Cleaning
BLAZE OUTDOOR Care & Cleaning warning ♦ Never put your hand into the area housing the fan while the fan is operating. ♦ Turn off and disconnect power to the hood before cleaning. ♦ Make sure your cook-top and hood are cool before cleaning. ♦...
Page 17: Wiring Diagram
USER MANUAL | 12 Care & Cleaning step 2 step 1 When cleaning filters, always remove the grease channels and clean with hot soapy water. Both the filters and the channels are dishwasher safe. Slide filter forward off of rear lip. Dry throughly before re-installing.
Page 18: Troubleshooting
BLAZE OUTDOOR troubleshooting NOTHING WORKS (Control Panel not responding, Blower not working) Solution 1: Turn on power at circuit breaker panel or fuse box . Check for tripped breaker or blown fuse under the black plastic cover on the rear of the hood.
Page 19: Warranty Information
| 14 USER MANUAL Warranty One Year Warranty - Parts Only For one year from the date of original purchase, we will repair or replace any non-consumable parts or components that failed due to manufacturing defects. ATTENTION International Customers: Please consult your selling dealer or distributor for specifics pertaining to your product warranty and procedure.
