Richen A8 Manual

Bluetooth sports headset
Hide thumbs
1
2
3

Advertisement

Table of Contents

Richen Industrial Co.,Ltd
Product Name Bluetooth Sports Headset
Model No.: A8
Product Image:

Basic Specification

·Product Size 500X45X28mm
·Bluetooth Name: A8 ( customized is available)
·Unit Product Weight 20g
·Battery Capacity: 3.7V/90mAh
·Charge Port micro USB
·Charge Voltage DC5V
·Charge Current 60mA
·Charge time about 1.5hour
·Playing time:about 5 hours at 100% volume
·Rated Audio Power 5mW*2
·Rated Power 5mW*2
·Impendence: 32
·Frequency Response 20Hz 20KHz
. Sensitivity: 98± 3dB/1KHz
. Audio Total Harmonic Distortion: <1%
·Operating distance: over 10Meters
·Talking Time approximately 5~6hours
·Standyby time over 100hours
A8 SPECIFICATION SHEET
For internal use only

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A8 and is the answer not in the manual?

Questions and answers

Summary of Contents for Richen A8

  • Page 1 A8 SPECIFICATION SHEET Product Name Bluetooth Sports Headset Model No.: A8 Product Image: Basic Specification ·Product Size 500X45X28mm ·Bluetooth Name: A8 ( customized is available) ·Unit Product Weight 20g ·Battery Capacity: 3.7V/90mAh ·Charge Port micro USB ·Charge Voltage DC5V ·Charge Current 60mA ·Charge time about 1.5hour...
  • Page 2 Richen Industrial Co.,Ltd CONTROLS–ILLUSTRATED Mircophone Hook Silicon cushion Mirco USB Port LED indicator Volume Down / Previous Power Button/Play/Pause Volume Up/Next Operation Instruction .Power On Press Power/Play/Pause button for 2 seconds, Blue light on. .Pairing Press and hold the Power/Play/Pause button for 3 seconds to enter Bluetooth Pairing mode. the Led indicator light will quickly flash blue and red .Power off Press Power/Play/Pause button for 2 seconds, Red light on.
  • Page 3 Step 2 -- Re-open A8 and enter Bluetooth paring mode, Paired with Phone B.Then close A8. Step 3 – Re-open A8 and enter Bluetooth paring mode,also Bluetooth of Phone A and Phone B should keep opening, then paired with A8 in 5 seconds.Kindly pls noted the function will just prefer the equipment is working with music/video player ,calling and so on.
