Wistron NeWeb DNUA-93S User Manual

Wlan 802.11 b/g/n usb module
Hide thumbs

Advertisement

Quick Links

Download this manual
WLAN 802.11 b/g/n USB module
DNUA-93S
User Manual
June 2011

Advertisement

loading
Need help?

Need help?

Do you have a question about the DNUA-93S and is the answer not in the manual?

Questions and answers

Related Manuals for Wistron NeWeb DNUA-93S

Summary of Contents for Wistron NeWeb DNUA-93S

  • Page 1 WLAN 802.11 b/g/n USB module DNUA-93S User Manual June 2011...
  • Page 2 Copyright Statement No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, whether electronic, mechanical, photocopying, recording or otherwise without the prior writing of the publisher. Pentium is trademark of Intel. All copyright reserved.
  • Page 3 FCC Statement Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 4 This device is intended only for OEM integrators under the following conditions: The antenna must be installed such that 20 cm is maintained between the antenna and users, The transmitter module may not be co-located with any other transmitter or antenna, For all products market in US, OEM has to limit the operation channels in CH1 to CH11 for 2.4G band by supplied firmware programming tool.

  • Page 5: Table Of Contents

    Table of Contents 1. INTRODUCTION 2. DRIVER/UTILITY INSTALLATION / UNINSTALLATION 5 3. CONNECTING TO AN EXISTING NETWORK 5 4. MODIFYING A WIRELESS NETWORK 4.1 M ....................6 ODIFYING ENERAL ETTINGS 4.2 M ....................7 ODIFYING ECURITY ETTINGS 5. SPECIFICATIONS 9 APPENDIX A: FAQ ABOUT WLAN...

  • Page 6: Introduction

    1. Introduction Thank you for purchasing the WLAN 802.11 b/g/n USB adaptor that provides the easiest way to wireless networking. This User Manual contains detailed instructions in the operation of this product. Please keep this manual for future reference. System Requirements 128 MB of RAM or later (recommended) 300 MHz processor or higher 2.

  • Page 7: Modifying A Wireless Network

    4. Modifying a Wireless Network 4.1 Modifying General Settings 1. Use the remote control that came with your TV to access the network configuration settings page. 2. From the profile list, select one profile and choose the modify function. 3. Modify the settings below for your network. Profile Name Profile Name Identifies the configuration wireless network profile.

  • Page 8: Modifying Security Settings

    4.2 Modifying Security Settings 1. Use the remote control that came with your TV to access the network configuration settings page. 2. Select a security option of this wireless network. This product provides security options below. Contact your wireless network administrator for choosing a correct option. •...
  • Page 9 None No security (not recommended). Allow Association to Check this check box if the access point with which the client adapter is Mixed Cells to associate has WEP set to Optional and WEP is enabled on the client adapter. Otherwise, the client is unable to establish a connection with the access point.

  • Page 10: Specifications

    5. Specifications Dimensions: 30(L) * 17(W) * 8.5(H) mm Frequency range: USA: 2.400 ~ 2.483GHz, Europe: 2.400 ~ 2.483GHz, Japan: 2.400 ~ 2.497GHz, China: 2.400 ~ 2.483GHz, Channels support: 802.11n b/g US/Canada: 11 (1 ~ 11) Major European country: 13 (1 ~ 13) France: 4 (10 ~ 13) Japan: 11b: 14 (1~13 or 14 ), 11g: 13 (1 ~ 13)

  • Page 11: Appendix A: Faq About Wlan

    Appendix A: FAQ about WLAN What is Spread Spectrum? Spread Spectrum technology is a wideband radio frequency technique developed by the military for use in reliable, secure, mission-critical communications systems. It is designed to trade off bandwidth efficiency for reliability, integrity, and security. In other words, more bandwidth is consumed than in the case of narrowband transmission, but the trade-off produces a signal that is, in effect, louder and thus easier to detect, provided that the receiver knows the parameters of the spread-spectrum signal being broadcast.
  • Page 12 What is roaming? Roaming is the ability of a portable computer user to communicate continuously while moving freely throughout an area greater than that covered by a single access point. Before using the roaming function, the workstation must make sure that it is the same channel number with the access point of dedicated coverage area.
