OWNER'S MANUAL
TRINITY BASICS 5-TIER NSF 24"x12"x55.5"
PANTRY RACK
Model # TBFZ-0955 / TBFPBR-0955
Important / Important / Importante
FOR QUICK & EASY 3D ASSEMBLY INSTRUCTIONS
Direct ives int elligent es
POUR DES DIRECTIVES D'ASSEMBLAGE 3D RAPIDES ET FACILES
Inst rucciones Int eligent es
PARA INSTRUCCIONES DE ENSAMBLAJE RÁPIDAS Y SENCILLAS EN 3D
DOWNLOAD THE FREE APP | TÉLÉCHARGER L'APPLICATION GRATUITE | DESCARGUE LA APLICACIÓN GRATUITA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EcoStorage TBFZ-0955 and is the answer not in the manual?

Questions and answers

Summary of Contents for Trinity Basics EcoStorage TBFZ-0955

  • Page 1 OWNER’S MANUAL TRINITY BASICS 5-TIER NSF 24"x12"x55.5" PANTRY RACK Model # TBFZ-0955 / TBFPBR-0955 Important / Important / Importante FOR QUICK & EASY 3D ASSEMBLY INSTRUCTIONS Direct ives int elligent es POUR DES DIRECTIVES D’ASSEMBLAGE 3D RAPIDES ET FACILES Inst rucciones Int eligent es PARA INSTRUCCIONES DE ENSAMBLAJE RÁPIDAS Y SENCILLAS EN 3D...

  • Page 2: Parts List

    PARTS LIST Your TRINITY Basics 5-Tier Pantry Rack should include the following parts. Please inspect box contents to ensure you have received all components. If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY Customer Service: 800.985.5506 or customerservice@trinityii.com.
  • Page 3 ASSEMBLY INSTRUCTIONS STEP 1 A (4) H (2) I (2) J (1) Screw each CASTER (H) and (I) into each BOTTOM POLE (A). Turn clockwise to screw in place. Make sure locking casters are on same side. Use provided caster wrench to tighten completely. Failure to do as instructed could result in caster stem breaking.
  • Page 4 ASSEMBLY INSTRUCTIONS STEP 3 Place SHELF (D) on its side and slide each BOTTOM POLE (A) through each corner cylinder on SHELF (D). Make sure D (1) SHELF (D) corner cylinders are positioned over SLIP SLEEVES (G). Stand unit upright. Note: •...
  • Page 5 ASSEMBLY INSTRUCTIONS STEP 5 In the same way as indicated in STEP 2 & 3, G (36) D (4) E (1) install 2 SHELVES (D) and then PUSH HANDLE (E). Then install another 2 SHELVES (D) above PUSH HANDLE (E). Note: •...
  • Page 6 ASSEMBLY INSTRUCTIONS Anti-tip Hardware Installation ANTI-TIP HARDWARE PACK (K) is used to protect against accidental tipping – especially due to curious children. Note that installing Washer (2) Anchor (2) Screw (2) ANTI-TIP HARDWARE PACK (K) will no longer allow your rack to be K (1) mobile.

  • Page 7: Service Parts List

    SERVICE PARTS LIST – TBFZ-0955 Chrome Color TRINITY Customer Service provides the following replacement parts: Part Number Description Part Number Description ZSV-03-079-2412 Shelf XXX-97-002-0005 Wrench ZSV-04-047-1650 Top Pole ZSV-02-012-0003 Divider ZSV-01-029-1922 Pole Connector XBK-01-011-1936 Slip Sleeve ZSV-04-048-1800 Middle Pole ZSV-05-028-1200 Handle ZSV-04-049-1825 Bottom Pole...
  • Page 8 SERVICE PARTS LIST – TBFPBR-0955 Bronze Color TRINITY Customer Service provides the following replacement parts: Part Number Description Part Number Description PBR-03-079-2412 Shelf XXX-97-002-0005 Wrench PBR-04-047-1650 Top Pole PBR-02-012-0003 Divider ZSV-01-029-1922 Pole Connector XBK-01-011-1936 Slip Sleeve PBR-04-048-1800 Middle Pole PBR-05-028-1200 Handle PBR-04-049-1825 Bottom Pole...

  • Page 9: Care And Maintenance

    WARNINGS 1. Read and understand all instructions. Failure to follow all instructions may result in injury and/or damage. 2. Use the provided caster wrench to tighten casters completely. Failure to do as instructed could result in the caster stem breaking thereby causing the shelving rack to collapse. 3.

  • Page 10: Product Registration

    PRODUCT REGISTRATION Thank you for purchasing a TRINITY Basics 5-Tier Pantry Rack. In order to register your product and receive streamlined customer service, please fill out the following Product Registration Form and (1) fax the form to 310.347.4134 (2) complete the Product Registration Form online at www.trinityii.com or (3) scan and email the form to customerservice@trinityii.com.

  • Page 11: Year Limited Warranty

    Trinity International Industries (“Trinity”) warrants to the original consumer purchaser (“Purchaser”) of the TRINITY Basics 5-Tier Pantry Rack (“Product”) that each Product shall be free from defects in workmanship and materials for a period of 1 year from the date of original purchase. Trinity’s obligation under this...
  • Page 12 CONTACT US QUESTIONS? NEED PARTS? WE ARE HERE TO HELP! Please feel free to contact us. There are no questions too small, or any problems too big. We’re committed to providing our customers with the highest level of service. TRINITY Customer Service TEL: 800.985.5506 FAX: 310.347.4134 EMAIL: customerservice@trinityii.com...
