Copyright © 2008 Huawei Technologies Co., Ltd.
All Rights Reserved
No part of this document may be reproduced or transmitted in any form or by any
means without prior written consent of Huawei Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are trademarks of Huawei Technologies Co.,
Ltd.
All other trademarks and trade names mentioned in this document are the
property of their respective holders.
Notice
The information in this document is subject to change without notice. Every effort
has been made in the preparation of this document to ensure accuracy of the
contents, but all statements, information, and recommendations in this document
do not constitute the warranty of any kind, express or implied.
Advertisement
Related Manuals for Huawei E156B
Summary of Contents for Huawei E156B
- Page 1 All Rights Reserved No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd. Trademarks and Permissions and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
-
Page 2: Table Of Contents
Table of Contents What Is in Your Package ................ 1 Getting to Know Your E156B ..............2 Preparation ..................5 Installation/Removal Guide..............7 Safety Information ................10 Acronyms and Abbreviations..............17... -
Page 3: What Is In Your Package
E156B, you can access the Internet through wireless network at a high speed. Note: This manual describes the appearance, installation and removal of the E156B. For the operation of the management program, refer to the User Manual. What Is in Your Package... -
Page 4: Getting To Know Your E156B
Getting to Know Your E156B The following figure shows the appearance of the E156B. It is only for your reference. The actual product may differ. USB Interface It connects the E156B to a computer. - Page 5 It is where you insert the Micro Secure Digital Memory (SD) card RF testing slot It connects the RF test cables for RF testing. Strap Hole Indicator It indicates the status of the E156B. Colour Status Meaning Blinking (on for 100ms and Green The E156B is powered on.
- Page 6 The E156B is connected to a WCDMA Blue network. The E156B is connected to a HSDPA Cyan network. The E156B is removed.
-
Page 7: Preparation
Preparation Requirements for the Computer To use the E156B, the computer should meet the following requirements: USB Type A Receptacle, Compatible with USB 2. 0 High Speed. Windows 2000 SP4, Windows XP SP2, Windows Vista. Your computer’s hardware system should meet or exceed the recommended system requirements for the installed version of OS. - Page 8 Inserting the Micro SD Card (Optional) Insert the micro SD card into the E156B, as shown in the following figure. Note: Do not remove the micro SD card when it is being used. Removing the card during an operation may damage the micro SD card as well as the device, and data...
-
Page 9: Installation/Removal Guide
First, power on the computer. Then connect the E156B with the computer. Otherwise, the E156B cannot be installed as normal. Plug the E156B into the USB interface of the laptop or desktop computer. You can connect the E156B to a laptop or desktop computer using the USB cable for better signals. - Page 10 Starting the Management Program After the E156B is installed, the management program is launched automatically. Then every time the E156B is connected to the PC, the management program is launched automatically. You can also double-click the shortcut icon on the desktop to launch the management program.
- Page 11 Click Add/Remove Program to remove the management program of the E156B. Note: Before removing the management program, exit the management program.
-
Page 12: Safety Information
Safety Information Read the safety information carefully to ensure the correct and safe use of your wireless device. Interference Do not use your wireless device if using the device is prohibited or when it cause danger or interference with electric devices. Medical Device Do not use your wireless device and follow the rules and regulations set forth by the hospitals and health care facilities. - Page 13 Area where the air contains chemical substances and particles (such as granule, dust, or metal powder) Area indicated with the "Explosives" sign Area indicated with the "Power off bi-direction wireless equipment" sign Area where you are generally suggested to stop the engine of a vehicle Traffic Security Observe local laws and regulations while using the wireless device.
- Page 14 WEEE Approval The wireless device is in compliance with the essential requirements and other relevant provisions of the Waste Electrical and Electronic Equipment Directive 2002/96/EC (WEEE Directive). RoHS Approval The wireless device is in compliance with the restriction of the use of certain hazardous substances in electrical and electronic equipment Directive 2002/95/EC (RoHS Directive).
- Page 15 Do not leave your wireless device and accessories in a place with a considerably low or high temperature. Use only accessories of the wireless device approved by the manufacture. Contact the authorized service center for any abnormity of the wireless device or accessories.
- Page 16 Directive 1999/5/EC (R&TTE Directive). In Europe, the SAR limit for mobile devices used by the public is 2.0 watts/kg (W/kg) averagedover 10 grams of tissue for the body or head (4.0 W/kg averaged over 10 grams of tissue for theextremities - hands, wrists, ankles and feet). The standard incorporates a substantial margin ofsafety to give additional protection for the public and to account for any variations inmeasurements.
- Page 17 15.21 NOTICE: Changes or modifications made to this equipment not expressly approved by (HUAWEI) may void the FCC authorization to operate this equipment. 15.105 NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
-
Page 19: Acronyms And Abbreviations
Acronyms and Abbreviations EDGE Enhanced Data Rates for GSM Evolution GPRS General Packet Radio Service Global System for Mobile Communications HSDPA High Speed Downlink Packet Access Operating System Personal Identification Number Specific Absorption Rate Subscriber Identity Module UMTS Universal Mobile Telecommunications System Universal Serial Bus USIM UMTS Subscriber Identity Module... - Page 20 Version: V100R001_01 Part Number: 31019600...
