ASSEMBLY INSTRUCTIONS
Coloreidge 42 in. Mantel Console with Infrared Electric Fireplace
Questions, problems, missing parts? Before returning to the store,
We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this fireplace
console. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of
products available for your home improvement needs. Thank you for choosing Home Decorators Collection!
call Home Decorators Collection Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday
9 a.m. - 6 p.m., EST, Saturday
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
THANK YOU
Model # WSFP42ECHD-28
# WSFP42ECHD-29
# WSFP42ECHD-30
Advertisement
Table of Contents
Summary of Contents for Home Decorators Collection WSFP42ECHD-28
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this fireplace console. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ............2 Hardware Included ............. 3 Safety Information ............2 Package Contents ............4 Warranty ................. 2 Assembly ............... 5 Pre-Assembly ..............2 Care and Maintenance ..........18 Planning Assembly ............. 2 Tools required ............2 Safety Information Fits up to most 127 cm / 50 in. -
Page 3: Hardware Included
Pre-Assembly (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. MAXIMUM LOAD 50 LB (22.7 kg) MAXIMUM LOAD 50 LB (22.7 kg) MAXIMUM LOAD 50 LB (22 MAXIMUM LOAD 50 MAXIMUM MAXIMUM LOAD 50 LB (22.7 kg) MAXIMUM LOAD 50 LB (22.7 kg MAXIMUM LOAD 50 MAXIMUM MAXIMUM LOAD 50 LB (22.7 kg) -
Page 4: Package Contents
Pre-Assembly (continued) PACKAGE CONTENTS Quantit Quantit Part Description Part Description Top panel Right lower side panel Back panel Barrister door Center shelf Center crossbar Base Left Upper front molding Left upper side panel Right Upper front molding Barrister door left support Support Barrister door right support Adjustable shelf... -
Page 5: Assembly
Assembly Screwing the cam bolts NOTE: Do not fully tighten all bolts until you finish assembling all parts. Once assembled, go back and fully tighten all bolts. This will make the assembly easier. □ Unpack the unit and confirm that you have all the hardware and required parts. Assemble the unit on a carpeted floor or the empty carton to avoid any scratches. - Page 6 Assembly (continued) Combining the upper moldings and side panels NOTE: Refer to the dowel and cam lock assembling guide drawings in this step for further clarification on how to properly glue in the wooden dowels and install cam locks. Apply this method whenever instructed to install wood dowels and cam locks □...
- Page 7 Assembly (continued) Attaching the barrister door supports □ Glue four wood dowels (CC) into the inner holes on the upper edge of the barrister door supports (F and G) and attach them to the top panel (A) by engaging four cam locks (AA). Securing the barrister door supports □...
- Page 8 Assembly (continued) Installing the center crossbar and the center shelf □ Align and attach the center crossbar (N) to the center shelf (C) with two wood dowels (CC) and three cam locks (AA). □ Glue six wood dowels (CC) into the inner holes at the bottom edge of the upper side panels (E and H) and front moldings.
- Page 9 Assembly (continued) Attaching the lower back panels □ Align and attach lower back panels (I) to the lower side panels (K and L) with two wood dowels (CC) and two long wood screws (DD) per panel. Installing the lower side panel assemblies □...
- Page 10 Assembly (continued) Attaching the center crossbar □ Align and attach the remaining center crossbar (N) to the base (D) with two wood dowels (CC) and three cam locks (AA). Installing the supports □ Align and attach the supports (Q) to the base (D) with two wood dowels (CC) and two cam locks (AA) in each, as shown.
- Page 11 Assembly (continued) Installing the base assembly □ Align and attach the base assembly to the lower side panel assemblies with eight wood dowels (CC) and eight cam locks (AA). Securing the base □ Insert four long wood screws (DD) through the drilled holes on the base (D) and securely screw into the lower side panels (K and L).
- Page 12 Assembly (continued) Installing the metal plate □ Flip the assembled unit around at its front edges. Secure the middle crossbars (N) to both lower front panels (J) by attaching four metal plates (KK) at the joints, using two short wood screws (EE) in each, as shown. Attaching the back panel □...
- Page 13 Assembly (continued) Attaching the bottom pivot hinges □ Using the pilot holes as a guide, attach the left bottom pivot hinge (PP) to the left door (S) with two short wood screws (EE) as shown. Make sure that the pivot pin runs against the edge. □...
- Page 14 Assembly (continued) Installing the right door □ Repeat the same procedure with the right door (T). Installing the adjustable shelves and cam lock covers □ Open the doors and insert four shelf supports (JJ) into the desired holes inside each side compartment. Make sure you place the four shelf supports in the same level so the shelf is not tilted.
- Page 15 Assembly (continued) Installing the hooks and knob □ Using the pilot holes as a guide, fasten two hooks (OO) to the upper corners of the barrister door (M) with four short wood screws (EE). □ Attach one knob (SS) to the front side of the barrister door (M) with the knob bolt (TT). Installing the barrister door □...
- Page 16 Assembly (continued) Installing the fireplace insert □ Lift the fireplace insert carefully into the back of the assembled mantel and center it in the opening. DO NOT drag the insert across the bottom panel (D) as it may scratch the unit. Attaching the L-shaped metal braces □...
- Page 17 Assembly (continued) Installing the acrylic stopper □ Remove the paper backing of acrylic stopper (RR), then properly align the acrylic stopper into the cut-out on the acrylic stopper template on the front of the top panel (A). Press down on the acrylic stopper to help adhesion. □...
-
Page 18: Care And Maintenance
Care and Maintenance A Touch-up Pen has been provided to repair any small nicks or scratches that may occur during assembly or shipping. To clean and care for your furniture: □ Use a soft, clean cloth that will not scratch the surface when dusting. □... - Page 19 Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday 9 a.m. - 6 p.m., EST, Saturday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS Retain this manual for future use.
