  • Page 1 Preface B85M-E43 DASH Motherboard G52-78301X1...

  • Page 2: Preface

    Copyright Notice The material in this document is the intellectual property of MICRO-STAR INTERNATIONAL. We take every care in the preparation of this document, but no guarantee is given as to the correctness of its contents. Our products are under continual improvement and we reserve the right to make changes without notice.

  • Page 3: Smartphone Application

    If a problem arises with your system and no solution can be obtained from the user’s manual, please contact your place of purchase or local distributor. Alternatively, please try the following help resources for further guidance. Visit the MSI website for technical guide, BIOS updates, driver updates, and other information: http://www.msi.com/service/download/ Contact our technical staff at: http://support.msi.com...

  • Page 4: Safety Instructions

    Safety Instructions ￭ Always read the safety instructions carefully. ￭ Keep this User’s Manual for future reference. ￭ Keep this equipment away from humidity. ￭ Lay this equipment on a reliable flat surface before setting it up. ￭ The openings on the enclosure are for air convection hence protects the equipment from overheating.

  • Page 5: Fcc-B Radio Frequency Interference Statement

    FCC-B Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 6: Radiation Exposure Statement

    Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment and its antenna should be installed and operated with minimum distance 20 cm between the radiator and your body. This equipment and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter.

  • Page 7: Battery Information

    Replace only with the same or equivalent type recommended by the manufacturer. Chemical Substances Information In compliance with chemical substances regulations, such as the EU REACH Regulation (Regulation EC No. 1907/2006 of the European Parliament and the Council), MSI provides the information of chemical substances in products at: http://www.msi.com/html/popup/csr/evmtprtt_pcm.html Preface...

  • Page 8: Weee (Waste Electrical And Electronic Equipment) Statement

    MSI will comply with the product take back requirements at the end of life of MSI-branded products that are sold into the EU. You can return these products to local collection points.
  • Page 9 MSI će poštovati zahtev o preuzimanju ovakvih proizvoda kojima je istekao vek trajanja, koji imaju MSI oznaku i koji su prodati u EU. Ove proizvode možete vratiti na lokalnim mestima za prikupljanje.
  • Page 10 MSI si adeguerà a tale Direttiva ritirando tutti i prodotti marchiati MSI che sono stati venduti all’interno dell’Unione Europea alla fine del loro ciclo di vita.

  • Page 11: Table Of Contents

    CONTENTS ▍ Preface ......................i Copyright Notice ......................ii Trademarks ......................ii Revision History ......................ii Smartphone Application ..................iii Technical Support ....................iii Safety Instructions ....................iv FCC-B Radio Frequency Interference Statement ........... v CE Conformity ......................v Radiation Exposure Statement ................vi European Community Compliance Statement ............vi Taiwan Wireless Statements ...................vi Japan VCCI Class B Statement ................vi Korea Warning Statements ..................vi...
  • Page 12 Internal Connectors .................... 1-19 SATA1~6: SATA Connectors ..............1-19 CPUFAN,SYSFAN1~2: Fan Power Connectors .......... 1-20 JFP1, JFP2: System Panel Connectors ............1-21 JUSB1~2: USB 2.0 Expansion Connector ........... 1-22 JUSB3: USB 3.0 Expansion Connector ............1-22 JCI1: Chassis Intrusion Connector .............. 1-23 JAUD1: Front Panel Audio Connector ............
  • Page 13 Security ......................3-24 Save & Exit ......................3-26 Appendix A Realtek Audio ................A-1 Software Configuration ..................A-2 Software panel overview ................A-2 Auto popup dialog ..................A-3 Hardware Default Setting ..................A-4 Appendix B Intel SBA ................. B-1 Prerequisites ......................B-2 Installing Intel SBA ....................B-3 Software Configuration ..................B-3 Software panel overview ................B-3 Password settings ..................B-4...

  • Page 15: Chapter 1 Getting Started

    Chapter 1 Getting Started Thank you for choosing the B85M-E43 DASH Series (MS-7830 v1.X) Micro- ATX motherboard. The B85M-E43 DASH Series motherboards are based on Intel B85 chipset for optimal system efficiency. Designed to fit the advanced ® Intel LGA1150 processor, the B85M-E43 DASH Series motherboards deliver ®...

  • Page 16: Packing Contents

    * These pictures are for reference only and may vary without notice. * The packing contents may vary according to the model you purchased. * If you need to purchase the optional accessories or request part numbers, please visit the MSI website at http://www.msi.com/index.php or consult the dealer. Getting Started...

  • Page 17: Assembly Precautions

    Assembly Precautions ■ The components included in this package are prone to damage from electrostatic discharge (ESD). Please adhere to the following instructions to ensure successful computer assembly. ■ Always turn off the power supply and unplug the power cord from the power outlet before installing or removing any computer component.

  • Page 18: Motherboard Specifications

    Motherboard Specifications ■ 4th Generation Intel Core™ i7 / Core™ i5 / Core™ i3 / Pentium ® ® Celeron processors for LGA 1150 socket Support ® Chipset ■ Intel B85 Express Chipset ® Memory ■ 4x DDR3 memory slots supporting up to 32GB ■...
  • Page 19 Internal ■ 1x 24-pin ATX main power connector ■ 1x 4-pin ATX 12V power connector Connectors ■ 4x SATA 6Gb/s connectors ■ 2x SATA 3Gb/s connectors ■ 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports) ■ 1x USB 3.0 connector (supports additional 2 USB 3.0 ports) ■...

  • Page 20: Connectors Quick Guide

    Connectors Quick Guide CPUFAN DIMM4 JCOM2 DIMM3 JPWR2 DIMM2 DIMM1 CPU Socket JCOM1 SYSFAN2 Back Panel SYSFAN1 JPWR1 PCI_E1 JBAT1 SATA5_6 PCI_E2 SATA1 PCI_E3 SATA2 SATA4 PCI1 SATA3 JAUD1 JUSB3 JFP2 JLPT1 JTPM1 JFP1 JUSB2 JUSB1 JCI1 Getting Started...
  • Page 21 PCIe x1 Expansion Slots 1-17 PCI1 PCI Expansion Slot 1-17 SATA1~4 SATA 6Gb/s Connectors 1-19 SATA5~6 SATA 3Gb/s Connectors 1-19 For the latest information about CPU, please visit http://www.msi.com/service/cpu-support/ For more information on compatible components, please visit http://www.msi.com/service/test-report/ Getting Started...

  • Page 22: Back Panel Quick Guide

    Back Panel Quick Guide VGA Port PS/2 Mouse LAN Port USB 2.0 Port Port Line-In RS-Out USB 3.0 Port Line-Out CS-Out SS-Out HDMI PS/2 Keyboard USB 2.0 Port DVI-D Port Port ▶ PS/2 Keyboard/Mouse Port The PS/2 mouse/keyboard DIN connectors for a PS/2 mouse/keyboard.
  • Page 23 ▶ HDMI Port The High-Definition Multimedia Interface (HDMI) is an all-digital audio-video interface that is capable of transmitting uncompressed streams. HDMI supports all types of TV formats, including standard, enhanced, or high-definition video, plus multi-channel digital audio on a single cable. ▶...

  • Page 24: Cpu (Central Processing Unit)

    This motherboard is designed to support overclocking. Before attempting to overclock, please make sure that all other system components can tolerate overclocking. Any attempt to operate beyond product specifications is not recommend. MSI does not guarantee the damages or risks caused by inadequate operation beyond product specifications.

  • Page 25: Cpu & Heatsink Installation

    CPU & Heatsink Installation When installing a CPU, always remember to install a CPU heatsink. A CPU heatsink is necessary to prevent overheating and maintain system stability. Follow the steps below to ensure correct CPU and heatsink installation. Wrong installation can damage both the CPU and the motherboard.
  • Page 26 3. Align the notches with the socket alignment keys. Lower the CPU straight down, without tilting or sliding the CPU in the socket. Inspect the CPU to check if it is properly seated in the socket. 4. Close and slide the load plate under the retention knob. Close and engage the load lever.
  • Page 27 7. Locate the CPU fan connector on the motherboard. 8. Place the heatsink on the motherboard with the fan’s cable facing towards the fan connector and the fasteners matching the holes on the motherboard. CPU fan connector 9. Push down the heatsink until the four fasteners get wedged into the holes on the motherboard.

  • Page 28: Memory

    Memory These DIMM slots are used for installing memory modules. For more information on compatible components, please visit http://www.msi.com/service/test-report/ DIMM1 DIMM2 DIMM3 DIMM4 Video Demonstration Watch the video to learn how to install memories at the address below. http://youtu.be/76yLtJaKlCQ Dual-Channel mode Population Rule In Dual-Channel mode, the memory modules can transmit and receive data with two data bus channels simultaneously.

  • Page 29: Mounting Screw Holes

    Mounting Screw Holes When installing the motherboard, first install the necessary mounting stands required for an motherboard on the mounting plate in your computer case. If there is an I/O back plate that came with the computer case, please replace it with the I/O backplate that came with the motherboard package.

  • Page 30: Power Supply

    Power Supply Video Demonstration Watch the video to learn how to install power supply connectors. http://youtu.be/gkDYyR_83I4 JPWR1~2: ATX Power Connectors These connectors allow you to connect an ATX power supply. To connect the ATX power supply, align the power supply cable with the connector and firmly press the cable into the connector.

  • Page 31: Expansion Slots

    Expansion Slots This motherboard contains numerous slots for expansion cards, such as discrete graphics or audio cards. PCI_E1~3: PCIe Expansion Slots The PCIe slot supports the PCIe interface expansion card. PCIe 3.0 x16 Slot PCIe 2.0 x1 Slot PCI1: PCI Expansion Slot The PCI slot supports additional LAN, SCSI, USB, and other add-on cards that comply with PCI specifications.

  • Page 32: Video/ Graphics Cards

    Adding on one or more discrete video cards will significantly boost the system’s graphics performance. For best compatibility, MSI graphics cards are recommended. Video Demonstration Watch the video to learn how to install a graphics card on PCIe x16 slot with butterfly lock.

  • Page 33: Internal Connectors

    Internal Connectors SATA1~6: SATA Connectors This connector is a high-speed SATA interface port. Each connector can connect to one SATA device. SATA devices include disk drives (HDD), solid state drives (SSD), and optical drives (CD/ DVD/ Blu-Ray). Video Demonstration Watch the video to learn how to Install SATA HDD. http://youtu.be/RZsMpqxythc SATA6 SATA1...

  • Page 34: Cpufan,Sysfan1~2: Fan Power Connectors

    CPUFAN,SYSFAN1~2: Fan Power Connectors The fan power connectors support system cooling fans with +12V. If the motherboard has a System Hardware Monitor chipset on-board, you must use a specially designed fan with a speed sensor to take advantage of the CPU fan control. Remember to connect all system fans.

  • Page 35: Jfp1, Jfp2: System Panel Connectors

    JFP1, JFP2: System Panel Connectors These connectors connect to the front panel switches and LEDs. The JFP1 connector is compliant with the Intel Front Panel I/O Connectivity Design Guide. When ® installing the front panel connectors, please use the optional M-Connector to simplify installation.

  • Page 36: Jusb1~2: Usb 2.0 Expansion Connector

    JUSB1~2: USB 2.0 Expansion Connector This connector is designed for connecting high-speed USB peripherals such as USB HDDs, digital cameras, MP3 players, printers, modems, and many others. Important Note that the VCC and GND pins must be connected correctly to avoid possible damage.

  • Page 37: Jci1: Chassis Intrusion Connector

    JCI1: Chassis Intrusion Connector This connector connects to the chassis intrusion switch cable. If the computer case is opened, the chassis intrusion mechanism will be activated. The system will record this intrusion and a warning message will flash on screen. To clear the warning, you must enter the BIOS utility and clear the record.

  • Page 38: Jtpm1: Tpm Module Connector

    JTPM1: TPM Module Connector This connector connects to a optional TPM (Trusted Platform Module) Module. Please refer to the TPM security platform manual for more details and usages. JLPT1: Parallel Port Connector This connector is used to connect an optional parallel port bracket. The parallel port is a standard printer port that supports Enhanced Parallel Port (EPP) and Extended Capabilities Parallel Port (ECP) mode.

  • Page 39: Jcom1~2: Serial Port Connector

    JCOM1~2: Serial Port Connector This connector is a 16550A high speed communication port that sends/receives 16 bytes FIFOs. You can attach a serial device. Jumper JBAT1: Clear CMOS Jumper There is CMOS RAM onboard that is external powered from a battery located on the motherboard to save system configuration data.

  • Page 40: Drivers And Utilities

    After you install the operating system you will need to install drivers to maximize the performance of the new computer you just built. MSI motherboard comes with a Driver Disc. Drivers allow the computer to utilize your motherboard more efficiently and take advantage of any special features we provide.
  • Page 41 Chapter 2 Quick Installation This chapter provides demonstration diagrams about how to install your computer. Some of the installations also provide video demonstrations. Please link to the URL to watch it with the web browser on your phone or tablet. You may have even link to the URL by scanning the QR code. Important The diagrams in this chapter are for reference only and may vary from the product you purchased.
  • Page 42 CPU Installation http://youtu.be/bf5La099urI Quick Installation...

  • Page 43: Chapter 2 Quick Installation

    Quick Installation...

  • Page 44: Memory Installation

    Memory Installation http://youtu.be/76yLtJaKlCQ Quick Installation...

  • Page 45: Motherboard Installation

    Motherboard Installation Quick Installation...
  • Page 46 Quick Installation...

  • Page 47: Power Connectors Installation

    Power Connectors Installation http://youtu.be/gkDYyR_83I4 Quick Installation...
  • Page 48 Quick Installation...

  • Page 49: Sata Hdd Installation

    SATA HDD Installation http://youtu.be/RZsMpqxythc Quick Installation...

  • Page 50: Msata Ssd Installation

    mSATA SSD Installation Quick Installation 2-10...

  • Page 51: Front Panel Connector Installation

    Front Panel Connector Installation JFP1 Connecotr Installation http://youtu.be/DPELIdVNZUI Front Panel Audio Connector Installation 2-11 Quick Installation...

  • Page 52: Peripheral Connector Installation

    Peripheral Connector Installation USB2.0 Connector Installation USB3.0 Connector Installation Quick Installation 2-12...

  • Page 53: Graphics Card Installation

    Graphics Card Installation http://youtu.be/mG0GZpr9w_A 2-13 Quick Installation...
  • Page 54 Quick Installation 2-14...

  • Page 55: Chapter 3 Bios Setup

    Chapter 3 BIOS Setup This chapter provides information on the BIOS Setup program and allows you to configure the system for optimum use. Using your mouse and keyboard, users can change BIOS settings, monitor CPU temperature and view system information such as the CPU name, DRAM capacity, the OS version and the BIOS version.

  • Page 56: Entering Setup

    (optional) on the motherboard to enable the system going to BIOS setup directly at next boot. Click "GO2BIOS" tab on "MSI Fast Boot" utility screen. Important Please be sure to install the “MSI Fast Boot” utility before using it to enter the BIOS setup. BIOS Setup BIOS Setup...

  • Page 57: Overview

    Overview After entering BIOS, the following screen is displayed. BIOS menu selection General Help Menu display ▶ BIOS menu selection ■ Main - Use this menu for basic system configurations, such as time, date etc. ■ Advanced - Use this menu to set up the items of special enhanced features. ■...

  • Page 58: Operation

    Operation You can control BIOS settings with the mouse and the keyboard. The following table lists and describes the hot keys and the mouse operations. Hot key Mouse Description <↑↓→← > Select Item Move the cursor <Enter> Select Icon/ Field Click/ Double-click the left button <Esc>...

  • Page 59: Main

    Main ▶ System Date Sets the system date. Use tab key to switch between date elements. The format is <day> <month> <date> <year>. <day> Day of the week, from Sun to Sat, determined by BIOS. Read-only. <month> The month from Jan. through Dec. <date>...

  • Page 60: Advanced

    Advanced ▶ PCI Subsystem Settings Sets PCI, PCI express interface protocol and latency timer. Press <Enter> to enter the sub-menu. ▶ PEG0 - Gen X [Auto] Sets PCI Express protocol for matching different installed devices [Auto] Enables all PCIe Gen1, Gen2 and Gen3. supports. [Gen1] Enables PCIe Gen1 support only.
  • Page 61 ▶ LAN Option ROM [Disabled] Enables or disables the legacy network Boot Option ROM for detailed settings. This item will appear when "Onboard LAN Controller" is enabled. [Enabled] Enables the onboard LAN Boot ROM. [Disabled] Disables the onboard LAN Boot ROM. ▶...
  • Page 62 ▶ Intel(R) Rapid Start Technology Sets Intel Rapid Start Technology for optimizing the system resume operation. Press ® <Enter> to enter the sub-menu. ▶ Intel(R) Rapid Start Technology [Disabled] Intel Rapid Start Technology lets the system resume from sleep mode quickly. ®...
  • Page 63 ▶ RapidStart Display Type [BIOS Save/Restore] Selects the screen type of Intel Rapid Start Display. [BIOS Save/Restore] The BIOS POST splash screen will be saved/ restored. [DeskTop Save/Restore] The desktop image will be saved/ restored. ▶ LakeTiny Feature [Disabled] Enables or disables Intel Lake Tiny technology with iRST for SSD. This item appears when "Intel C-State"...
  • Page 64 ▶ Device Mode [Printer Mode] Selects an operating mode for parallel port. [Printer Mode] Printer port mode [SPP] Standard Parallel Port mode [EPP-1.9/ 1.7 + SPP] Enhanced Parallel Port-1.9/ 1.7 mode + Standard Parallel Port mode. [ECP] Extended Capability Port mode [ECP + EPP-1.9/ 1.7] Extended Capability Port mode + Enhanced Parallel Port-1.9/ 1.7 mode.
  • Page 65 ▶ MCTP Configuration Sets the Management Component Transport Protocol (MCTP). Press <Enter> to enter the sub-menu. ▶ MCTP Support [Disabled] Enables or disables the Management Component Transport Protocol (MCTP) of onboard Realtek LAN chip. ▶ PLDM for SMBIOS [Enabled] Sends the BIOS information (ex. CPU speed, memory size, etc.) to the Realtek Management Console Utility.This item will appear when “MCTP Support”...
  • Page 66 Disables this function. ▶ MSI Fast Boot [Disabled] MSI Fast Boot is the fastest way to boot the system. When enabled, the USB, PS2 and SATA devices will not be detected while booting. [Enabled] Enables the MSI Fast Boot function to minimize booting time. And the following related "Fast Boot"...
  • Page 67 If you disable the PS/2 or USB devices and you want to enter BIOS with PS/2 or USB keyborard, you have to click the "GO2BIOS" tab on MSI Fast Boot utility screen or press the "GO2BIOS" button (optional) on the motherboard. And then the system will enter to BIOS setup directly at next boot.
  • Page 68 ▶ Image Execution Policy Sets the policy when the system image execution policy on Security Violation. Press <Enter> to enter the sub-menu. This sub-menu will appear when “Secure Boot Mode” sets to [Custom]. ▶ Key Management Manages the secure boot keys. Press <Enter> to enter the sub-menu. This sub- menu will appear when “Secure Boot Mode”...

  • Page 69: Overclocking

    Overclocking Important Overclocking your PC manually is only recommended for advanced users. • • Overclocking is not guaranteed, and if done improperly, can void your warranty or severely damage your hardware. • If you are unfamiliar with overclocking, we advise you to use OC Genie for easy overclocking.
  • Page 70 [Disabled] Disables this function. ▶ OC Genie [Disabled] Enables the OC Genie function. Enabling OC Genie function can automatically overclock the system with MSI optimized overclocking profile. [Enabled] Enables the OC Genie function. [Disabled] Disables the OC Genie function. Important We recommend that you do not to make any modification in overclocking menu and •...
  • Page 71 ▶ Extreme Memory Profile (X.M.P) [Disabled] X.M.P. (Extreme Memory Profile) is the overclocking technology by memory module. This item will be available when you install the memory modules that support X.M.P. technology. [Disabled] Disables this function. [Profile 1] Uses profile1 over-clocking settings of installed XMP memory module. [Profile 2] Uses profile2 over-clocking settings of installed XMP memory module.
  • Page 72 ▶ CPU Core Voltage [Auto] Sets CPU Core voltage. If set to "Auto", BIOS will set these voltages automatically or you can set it manually. ▶ Current CPU Core Voltage Show the current CPU Core voltage. Read-only. ▶ DRAM Voltage [Auto] Sets the memory voltage.
  • Page 73 ▶ MEMORY-Z Press <Enter> to enter the sub-menu. This sub-menu displays all the settings and timings of installed memory. You can also access this information menu at any time by pressing [F5]. ▶ DIMM1~4 Memory SPD Press <Enter> to enter the sub-menu. The sub-menu displays the information of installed memory.
  • Page 74 ▶ Hardware Prefetcher [Enabled] Enables or disables the hardware prefetcher (MLC Streamer prefetcher). [Enabled] Allows the hardware prefetcher to automatically pre-fetch data and instructions into L2 cache from memory for tuning the CPU performance. [Disabled] Disables the hardware prefetcher. ▶ Adjacent Cache Line Prefetch [Enabled] Enables or disables the CPU hardware prefetcher (MLC Spatial prefetcher).
  • Page 75 ▶ LakeTiny Feature [Disabled] Enables or disables Intel Lake Tiny feature with iRST for SSD. This item appears when a installed CPU supports this function and "Intel C-State" is enabled. [Enabled] Enhance the dynamic IO load adjusted performance for accelerating the SSD speed.

  • Page 76: M-Flash

    Enables the system to boot from the BIOS within USB flash disk. [Disabled] Enables the system to boot from the BIOS within ROM on motherboard. *This may cause system unstable, MSI recommend it only for power users. ▶ Select one file to boot Selects a BIOS file in the USB flash disk (NTFS/ FAT 32 format) to boot the system.

  • Page 77: Boot

    Boot ▶ Full Screen Logo Display [Enabled] Enables or disables to show the full screen logo while system POST. [Enabled] The OS boots straight to the GUI without showing the POST screen. [Disabled] Shows the POST messages at booting. ▶ Boot Mode Select [LEGACY+UEFI] Sets the system boot mode from legacy or UEFI architecture depending on OS installation requirement.

  • Page 78: Security

    Security ▶ Administrator Password Sets administrator password for system security. Enters the administrator password if set; user has full rights to change the BIOS items. ▶ User Password Sets User Password for system security. Enters the user password if set; but user might have limited rights to change the BIOS items.
  • Page 79 ▶ Chassis Intrusion Configuration Press <Enter> to enter the sub-menu. ▶ Chassis Intrusion [Disabled] This function will be available if the chassis equips a chassis intrusion switch. Once the chassis is opened, the system will record and issue a warning message. To clear the warning message, set the item to [Reset], then it will return to [Enabled] later.

  • Page 80: Save & Exit

    Save & Exit ▶ Discard Changes and Exit Exit BIOS setup without saving any change. This it is used to abandon all changes and exit BIOS setup. ▶ Save Changes and Reboot This item is used to save all changes and reboot the system. ▶...

  • Page 81: Appendix A Realtek Audio

    Appendix A Realtek Audio The Realtek audio provides 10-channel DAC that simultaneously supports 7.1 sound playback and 2 channels of independent stereo sound output (multiple streaming) through the Front-Out-Left and Front-Out-Right channels.

  • Page 82: Software Configuration

    Software Configuration After installing the audio driver (see Chapter 1 - Driver and Utilities), the “Realtek HD Audio Manager” icon will appear at the notification area (lower right of the screen). You may double click the icon and the GUI will pop up accordingly. double click the icon It is also available to enable the audio driver by clicking the Realtek HD Audio Manager from the Control Panel.

  • Page 83: Auto Popup Dialog

    ▶ Device Selection Here you can select a audio output source to change the related options. The “check” sign (in orange) indicates the devices as default. ▶ Volume Adjustment You can control the volume or balance the right/left side of the speakers that you plugged in front or rear panel by adjust the bar.

  • Page 84: Hardware Default Setting

    Hardware Default Setting The following diagrams are audio back panel default setting. ■ Backpanel audio jacks to 2-channel speakers diagram F r o ■ Backpanel audio jacks to 4-channel speakers diagram F r o R e a Realtek Audio...
  • Page 85 ■ Backpanel audio jacks to 6-channel speakers diagram F r o C e n R e a t e r & S u b w o o f ■ Backpanel audio jacks to 8-channel speakers diagram F r o C e n R e a t e r &...

  • Page 87: Appendix B Intel Sba

    Appendix B Intel SBA Intel Small Business Advantage (Intel SBA) provides an out-of-the-box ® ® hardware-based security and productivity suite designed for the small business user. Intel SBA includes a customizable user interface and several ® bundled Intel applications.

  • Page 88: Prerequisites

    Prerequisites ■ Supported Operating Systems Intel SBA supports following OS: ■ Windows 7 Professional 64-bit and 32-bit ■ Windows 7 Enterprise 64-bit ■ Windows 8 PRO 64-bit and 32-bit ■ Required User Permissions You must run the installer and the customization wizard with a user that has local administrator permissions on the computer.

  • Page 89: Installing Intel Sba

    Installing Intel SBA This procedure describes how to install Intel SBA. ■ To install Intel SBA: Logon to the computer with a user that has administrator privileges. Insert the application DVD into the DVD-ROM drive. The setup screen will automatically appear. Click OTHERS tab.

  • Page 90: Password Settings

    Password settings By default, the system is in an unconfigured state. Before the hardware capabilities can be used by Intel SBA software, the system must be configured. This is done in the Settings > Password Settings tab in the main menu of the GUI. Fill out the form to create the new password and click “Save”.
