- Page 1 KVM switch and rackmount screen technology User Manual 17” FHD 1080p LCD RM-111-DF17 1U Dual Slide LCD Console Drawer Options : - SDI - AV / HDMI / Audio - DC power UM-CV-751-DF17-Q113V1 www.rackmountsales.com...
- Page 3 Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.
-
Page 4: Table Of Contents
Contents < Part. 1 > RM-111-DF17 Package Content Structure Diagram & Dimension P.1 - 2 Installation P.3 - 5 Connection P.6 - 7 < Part. 2 > Specifi cations / OSD Product Specifi cations P.8 - 9 Keyboard / Mouse Specifi cations P.10 - 12... - Page 5 Contents < Part. 4 > KVM Integration www.rackmountsales.com/v/pdf/citumcat5m.pdf Matrix Local Remote 8-port 16-port 32-port Cat6 KVM Cat5M-IP116-3 Cat5M-IP132-3 Cat5M-IP216-4 Cat5M-IP232-4 Cat5M-16-2 Cat5M-32-2 Cat5M-16-3 Cat5M-32-3 Cat5M-16-4 Cat5M-32-4 www.rackmountsales.com/v/pdf/citumcat5.pdf Combo Local Remote 8-port 16-port 32-port Cat6 KVM Cat5-IP08 Cat5-IP16 Cat5-IP32 Cat5-08-2 Cat5-16-2 Cat5-32-2 Cat5-08 Cat5-16...
- Page 6 Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content.
-
Page 7: Rm-111-Df17
< Part 1 > < 1.1 > Package Content RM-111-DF17 RM-111-DF17 unit X 1 - DVI-6 6ft DVI-D console cable X 1 ( Alternative : USB-VGA-6 6ft VGA console cable ) - Power cord X 1 - M6 screw, cage nut & cup washer X 8 The above package content is only for the single console models. - Page 8 Weight 441.6 x 650 x 44 mm 595 x 860 x 140 mm 13 kg 18 kg RM-111-DF17 17.4 x 25.6 x 1.73" 23.4 x 33.9 x 5.5” 29 lb 40 lb The weight is only for the single console models. It varies with accessories & options such as KVM, SDI, HDMI, AV, audio &...
-
Page 9: Installation
< 1.3 > Installation - How to install Installation Slides RM-111-DF17 Step ■ Insert the left and right rear mounting brackets into the LCD console drawer. Step ■ Measure the depth of the front and rear mounting rails. ■ Align each rear mounting bracket to a suitable length. - Page 10 < 1.3 > Installation - How to Use the Dual Slides ■ Press the handle button and gently slide out the drawer. ■ Flip up the LCD to a suitable angle. ■ Operate the LCD console drawer. UM-CV-751-DF17-Q113V1 www.rackmountsales.com...
- Page 11 < 1.3 > Installation - How to Use the Dual Slides RM-111-DF17 ■ Flip down the front panel. ■ Press the handle button and gently push back the drawer into the rack. ■ Return the LCD console drawer to park position.
-
Page 12: Connection
< 1.4 > Connection to USB Server via DVI-6 cable LCD Console Drawer Power DVI-D DVI-D console cable DVI-D USB server < 1.4 > Connection to external KVM via DVI-6 cable LCD Console Drawer Power DVI-D KVM DVI-D console cable DVI-D DVI console KVM Caution :... - Page 13 < 1.4 > Connection to USB Server via USB/VGA-6 cable RM-111-DF17 LCD Console Drawer Power USB-VGA console cable USB server < 1.4 > Connection to external KVM via USB/VGA-6 cable LCD Console Drawer Power USB-VGA console cable USB console KVM...
-
Page 14: Product Specifi Cations
< Part 2 > < 2.1 > Product Specifi cations Panel Size ( diagonal ) 17.3-inch Widescreen TFT color LCD Panel Display pixel ( dots x lines ) 1920 x 1080 Brightness ( typ. ) Contrast Ratio ( typ. ) 600:1 Color 1.07 Billion, 10-bit... - Page 15 RM-111-DF17 Environmental Operating Temperature 0 to 50°C degree Conditions Humidity 20~90%, non-condensing Storage Temperature -5 to û °C degree Humidity 5~90%, non-condensing Shock 10G acceleration (11ms duration) Vibration 5~500Hz 1G RMS random Physical Product ( W x D x H ) 441.6 x 650 x 44 mm...
-
Page 16: Keyboard / Mouse Specifi Cations
< 2.2 > Keyboard / Mouse Specifi cations keyboard integrated with touchpad Key force 55 ± 5g Travelling distance 3 ± 0.3mm Switch life > 10 million life cycle time Software support MS Windows 7 / 2008 / 2003 / 2000 / XP / ME / 98 / DOC Linux / Mac Supporting layouts America... - Page 17 < 2.2 > MAC Keyboard / Mouse Options RM-111-DF17 MAC keyboard integrated with touchpad Supporting layouts America United States How to Use "MAC" Keyboard Keyboard Features Decrease display brightness Fast-forward Increase display brightness Mute sound Mission control * Only works with OS X Lion Decrease volume default Keyboard Shortcuts.
- Page 18 < 2.2 > SUN Keyboard / Mouse Options S keyboard integrated with touchpad Ca ps Scro ll Comp ose S keyboard integrated with touchpad / trackball ■ Incorporates SUN keys, including Stop, Cut, Paste, Compose, Copy and Help ■ 104 key notepad keyboard with full numerical pad and SUN function ■...
-
Page 19: On-Screen Display Operation ( Osd )
< 2.3 > On-screen Display Operation ( OSD ) RM-111-DF17 Membrane Switch Function Turn the monitor on or off Display the OSD menu Act as an Enter key to select screen setting options Scroll through menu options and adjust the displayed control... - Page 20 < 2.3 > On-screen Display Operation ( OSD ) Auto adjust : Automatically adjust sizes, centers and fi ne tunes the video signal to eliminate waviness and distortion. Clock : Adjust the clock value Phase : Adjust the phase value H.
- Page 21 < Part 3 > < 3.1 > Options : 3G / HD / SD-SDI input RM-111-DF17 Austin Hughes’ SDI input is an ideal solution for the broadcast- grade video and high resolution CCTV market. Designed for use with CyberView Full HD 1080p and ultra high...
- Page 22 < 3.2 > Options : - HDMI ( HDMI 1.1, CEA-861-D ) - AV ( S-Video + Composite, BNC ) - Audio ( 3.5mm audio jacks for audio in & out, and 2W + 2W speakers ) For dual slide 1U / 2U LCD console drawer, the user can only select one of the above four options. HDMI DVI-D Power...
- Page 23 < 3.3 > Options : DC Power RM-111-DF17 Model Input rating Input voltage: 12-Volt 24-Volt 48-Volt Input range: 9 ~ 18V 18 ~ 36V 36 ~ 75V Input current - No load 50 mA 50 mA 50 mA - Full load...
- Page 24 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. UM-CV-751-DF17-Q113V1 www.rackmountsales.com...
