Power Blower
Operator's Manual
MODEL:
Read rules for safe operation and all instructions carefully. ECHO provides this Operator's
Manual which must be read and understood for proper and safe operation.
X7501128101
PB-750H
Serial Number 05004460 - 05999999
PB-750T
Serial Number 05005115 - 05999999
WARNING
DANGER
X750005351
09/03
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Echo PB-750H
Summary of Contents for Echo PB-750H
- Page 1 Serial Number 05004460 - 05999999 PB-750T Serial Number 05005115 - 05999999 WARNING DANGER Read rules for safe operation and all instructions carefully. ECHO provides this Operator's Manual which must be read and understood for proper and safe operation. X750005351 X7501128101 09/03...
-
Page 2: Table Of Contents
NTRODUCTION Welcome to the ECHO family. This ECHO product was designed and manufactured to provide long life and on-the-job- dependability. Read and understand this manual. You will find it easy to use and full of helpful operating tips and SAFETY messages. -
Page 3: Manual Safety Symbols And Important Information
Locate these safety decals on your unit. Make sure the decals are legible and that you understand and follow the instructions on them. If a decal cannot be read, a new one can be ordered from your ECHO dealer. See PARTS ORDERING instructions for specific information. -
Page 4: International Symbols
Proper clothing and safety gear must be worn when operating a blower. Physical Condition Hearing Protection Your judgment and physical dexterity may not be good: ECHO recommends wearing hearing protection whenever • if you are tired or sick, unit is used. • if you are taking medication, •... -
Page 5: Extended Operation/Extreme Conditions
OWER LOWER PERATOR ANUAL EXTENDED OPERATION EXTREME CONDITIONS To reduce the risk of RSI/CTS, do the following: Vibration and Cold -- It is believed that a condition called Raynaud’s Phenomenon, which • Avoid using your wrist in a bent, affects the fingers of certain individuals may be brought about by extended or twisted position. -
Page 6: Safe Operation
SAFE OPERATION WARNING DANGER Do not operate this product indoors or in inadequately ventilated areas. Engine exhaust contains poisonous emissions and can cause serious injury or death. Noise Control Determine Operation Area • Follow local noise regulations on sound • Review area to be cleared. Look for potential hazards such as stones levels and hours of operations. -
Page 7: Description
__ 1 - Straight Pipe __ 1 - Straight Pipe __ 1 - Operator's Manual __ 1 - Warranty Registration Card __ 1 - ECHO Emissions and Warranty Statement __ 1 - Plastic Bag 2 - Clamps w/screws 1 - Stick Handle... -
Page 8: Contents Pb-750T
__ 1 - Straight Pipe __ 1 - Straight Pipe __ 1 - Operator's Manual __ 1 - Warranty Registration Card __ 1 - ECHO Emissions and Warranty Statement __ 1 - Plastic Bag 2 - Clamps w/screws 1 - Cable Clamp... - Page 9 OWER LOWER PERATOR ANUAL 1. AIR CLEANER - Contains replaceable air filter element. 2. SPARK PLUG - Provides spark to ignite fuel mixture. 3. SAFETY DECAL - Lists important safety precautions. 4. SPARK ARRESTOR - CATALYTIC MUFFLER / MUFFLER - The muffler or catalytic muffler controls exhaust noise and emission.
-
Page 10: Specifications
Width (PB-750H) ------------------------------------------- 485 mm (19 in.) Width (PB-750T) ------------------------------------------- 470 mm (18.5 in) Height ------------------------------------------------------- 527 mm (20.8 in.) Weight (dry) (PB-750H) ---------------------------------- 11.4 kg (25.1 lb.) Weight (dry) (PB-750T) ----------------------------------- 11.3 kg (24.9 lb.) Engine Type ------------------------------------------------ Air cooled, two-stroke, single cylinder gasoline engine Displacement ----------------------------------------------- 63.3 cc (3.86 cu. -
Page 11: Assembly
OWER LOWER PERATOR ANUAL SSEMBLY PB-750H WARNING DANGER Never perform maintenance or assembly procedures with engine running or serious personal injury may result. INSTALL BLOWER PIPES STICK HANDLE 1. Assemble clamps (A) onto both ends of flexible pipe (B). 2. Assemble swivel pipe (C) into flexible pipe (B) and tighten clamp (A). -
Page 12: Install Blower Pipes Pb-750T
PB-750T WARNING DANGER Never perform maintenance or assembly procedures with engine running or serious personal injury may result. INSTALL BLOWER PIPES 1. Assemble clamps (A) onto both ends of flexible pipe (B). 2. Assemble swivel pipe (C) into flexible pipe (B). NOTE Assure throttle cable is not twisted before installing handle (F). -
Page 13: Pre-Operation
Universal 2-Stroke Oil may be Storage - Fuel storage laws vary by locality. mixed at 50:1 ratio for application in all Echo engines sold in the Contact your local government for the laws past regardless of ratio specified in those manuals. -
Page 14: Operation
• Recoil starter: Use short pulls - only 1/2-2/3 of rope length for starting. Do not allow the rope to snap back in. Always hold the unit firmly. • (PB-750H): Rotate spring loaded throttle arm downward to a comfort- able operating position. STARTING COLD ENGINE... -
Page 15: Starting Warm Engine
Slide stop switch (B) to Stop position. WARNING DANGER If engine does not stop when stop switch is moved to STOP position, close choke - COLD START position - to stall engine. Have your ECHO dealer repair stop switch before using blower again. -
Page 16: Operating Blower
1. Use only during appropriate hours. 2. Allow the engine to warm up at a fast idle for a few minutes. PB-750H 3. Set engine speed with throttle lever (A). 4. Use lower speed to blow dry leaves from walks, patios and drives. -
Page 17: Maintenance
ECHO Service Dealer for maintenance. To help you decide whether you want to DO-IT-YOURSELF or have the ECHO Dealer do it, each maintenance task has been graded. If task is not listed, see your ECHO Dealer for repairs. -
Page 18: Air Filter
AIR FILTER Level 1. Tools required: 25 - 50mm (1 - 2 in.) cleaning brush Parts required: Repower Tune Up Kit P/N 90071 NOTE Clean daily. 1. Close choke (Cold Start Position). This prevents dirt from entering the carburetor throat when the air filter is removed. Brush accumulated dirt from the air cleaner area. -
Page 19: Spark Plug
OWER LOWER PERATOR ANUAL SPARK PLUG Level 1. Tools required: 19mm Spark Plug deep socket, Feeler gauge Parts Required: Repower Tune Up Kit P/N 90071 1. Remove spark plug , and check for fouling, worn and rounded center electrode. 2. Clean the plug or replace with a new one. DO NOT sand blast to clean. -
Page 20: Exhaust System
The cylinder exhaust port must be inspected and cleaned of excess carbon every 3 months or 90 hours of operation in order to maintain this engine within the emissions durability period. ECHO strongly recommends that you return your unit to your ECHO dealer for this important maintenance service. -
Page 21: Carburetor Adjustment
High Altitude Adjustment High altitude adjustment is not required for proper operation of this engine. Level 2. Tools required: Screwdriver, tachometer (Echo P/N 99051130017) Parts required: None. NOTE Do not adjust carburetor unless necessary. If you have difficulty, see your ECHO dealer. -
Page 22: Troubleshooting
ROUBLESHOOTING i l l r e l i l y r e l i l y t l i f f f u r e l h t i s t r r e l t ' n f f o i r t r e l o l r... -
Page 23: Storage
7. Remove the spark plug and pour 7cc (1/4 oz.) of fresh, WARNING DANGER clean ECHO 2-stroke engine oil into the cylinder Do not store in enclosure where fuel fumes may through the spark plug hole. accumulate or reach an open flame or spark. -
Page 24: Servicing Information
• Sending a check or money order for $2.00 per Parts Catalog or $1.50 per Operator's Manual made payable to ECHO, INCORPORATED. State on a sheet of paper the model number and serial number of the ECHO unit you have, part number of the manual (if known), your name and address and mail to address above.
