VWR SCBAF-1420 Owner's Manual

Basic auto defrost freezers

Advertisement

Part number 20052, Rev 0
This manual describes how to operate and care for your appliance to get the best, most efficient,
Note to Customer:
This merchandise was carefully packed and thoroughly inspected before leaving our plant.
Responsibility for its safe delivery was assumed by the carrier upon acceptance of the shipment. As directed on
the side of your packing carton, claims for loss or damage sustained in transit must be made on the carrier as
A.) Visible Loss, Damage, Shortage External Evidence of Loss or Damage: This type of damage must be noted on
the freight bill and acknowledged by the carrier's agent (driver) at time of delivery. Make sure you get a signed
copy. Send a written request for an inspection to the carrier.
B.) Concealed Damage: This type of damage may not be discovered until the unit is being unpacked. When
concealed damage is discovered, stop unpacking immediately and contact the carrier immediately to report
the claim and request an inspection. This should be done as soon as possible and, in any case, must be done
within 15 days or receiving the merchandise. If at all possible, do not move the item and save all packaging
material for carrier's inspection.
C.) FAILURE TO FOLLOW THESE INSTRUCTIONS MAY RESULT IN THE CARRIER REFUSING TO HONOR YOUR
COMPANY'S CLAIM. UNDER NO CIRCUMSTANCES SHOULD THE MERCHANDISE BE RETURNED TO THE
MANUFACTURER. NO RETURNS WILL BE ACCEPTED WITHOUT PRIOR AUTHORIZATION.
Horizon Scientific
125 Varnfield Drive
Summerville, SC 29483
Phone: 800-648-4041
Fax:
843-821-8051
BASIC AUTO DEFROST FREEZERS
SCBAF-1420, SCBAF-2020
OWNER'S INSTRUCTIONS
performance.
READ THIS BOOK!
follows:
Warranty:
Two-Year Parts and Labor
5 Years Compressor Parts
1
Revision Date
08/23/2012

Advertisement

loading
Need help?

Need help?

Do you have a question about the SCBAF-1420 and is the answer not in the manual?

Questions and answers

Summary of Contents for VWR SCBAF-1420

  • Page 1 Part number 20052, Rev 0 BASIC AUTO DEFROST FREEZERS SCBAF-1420, SCBAF-2020 OWNER’S INSTRUCTIONS This manual describes how to operate and care for your appliance to get the best, most efficient, performance. READ THIS BOOK! Note to Customer: This merchandise was carefully packed and thoroughly inspected before leaving our plant.
  • Page 2: Table Of Contents

    Part number 20052, Rev 0 Table of Contents RECEIVING ......................3 INSTALLATION ......................4 TEMPERATURE CONTROL ..................5 FREEZER OPERATION ..................... 6 QUICK TROUBLESHOOTING GUIDE ................ 7 MAINTENANCE AND CLEANING ................9 PRODUCT WARRANTY ..................10 BEFORE CALLING THE MANUFACTURER’S TECHNICAL SUPPORT DEPARTMENT, please have the unit’s model and serial number ready as well as the problem description.
  • Page 3: Receiving

    Part number 20052, Rev 0 RECEIVING Your unit was built, packaged, and inspected with extreme care. We shipped it to you using carriers we trust with a proven track record of careful handling, good customer service, and on time delivery. Unfortunately, regardless of all of these efforts sometimes accidents happen and occasionally those accidents result in shipping damage.
  • Page 4: Installation

    Part number 20052, Rev 0 INSTALLATION UNCRATING – Move your refrigerator as close to the final location as possible before unpacking. Remove the wooden planks or skid. The location should be as close as possible to the power outlet. This unit requires a minimum of 4 inches of air flow space in back and 3 inches on the sides and top.
  • Page 5: Temperature Control

    Part number 20052, Rev 0 TEMPERATURE CONTROL NOTE: The controls are preset and locked at the factory to provide the desired air and product temperatures inside of the units and require no further adjustment. Please contact the manufacturer’s Technical Support Department before making any adjustments to determine if adjustment is necessary and, if so, to make sure it is performed properly.
  • Page 6: Freezer Operation

    Part number 20052, Rev 0 FREEZER OPERATION After the unit is properly installed and power is applied, it will take some time before the system is cooled down to temperature and cycling normally. You should wait 8 hours on the first startup before beginning to add product to the unit.
  • Page 7: Quick Troubleshooting Guide

    Part number 20052, Rev 0 Quick Troubleshooting Guide Check these items before calling for service PROBLEM: POSSIBLE CAUSE / SOULTIONS: • Electrical circuit is not 110-120V 60Hz. • The power cord is not plugged in. • No power at electrical outlet. Check to make sure Unit does not run breaker is not tripped or fuse is not blown.
  • Page 8 Part number 20052, Rev 0 PROBLEM: POSSIBLE CAUSE / SOULTIONS: • Compressor may be overheated. Please check the room Compressor noises temp and ensure the range is within 65°F to 85°F. If the problem still exists, call for service. • Door gasket is not sealing properly. Check for debris, cracks, and items passing through door at the gasket.
  • Page 9: Maintenance And Cleaning

    Part number 20052, Rev 0 Maintenance and Cleaning Auto-Defrost Freezers require little maintenance but should be cleaned periodically to keep them running efficiently. Use the cleaning agents and suggestions in this table for best results. CLEANING PART CLEANING AGENTS TIPS AND PRECAUTIONS Interior and Door Soap and water Use 2 tablespoons of baking soda in 1 quart of...
  • Page 10: Product Warranty

    Part number 20052, Rev 0 HORIZON SCIENTIFIC, INC. PRODUCT WARRANTY Horizon Scientific, Inc. warrants to the original purchaser every new Horizon Scientific, Inc. refrigerated unit, the cabinet and all parts thereof, to be free from defects in material or workmanship, when such unit is installed, used, and maintained in accordance with provided instructions, for a period of two (2) years.
  • Page 11 Part number 20052, Rev 0 WARRANTY IS NOT TRANSFERABLE. This warranty is not assignable and applies only in favor of the original purchaser/user to whom delivered. Any such assignment or transfer shall void the warranties herein made and shall void all warranties, express or implied, including any warranty of merchantability or fitness for a particular purpose.
