REDATOM REDXLFOPEN175P Instruction Manual page 10

STEP 4A- ATTACH PANELTO WALL PLATE & ADJUST TILT ANGLE
Hang vertical rails with monitor attached
Cuelgue con el monitor adherido.
Accrochez avec le moniteur installé.
Pull spring lock
cord down and
gently push
bottom of panel
to wall and
release spring
lock. Panel is
now locked on
to wall plate.
STEP 4B- ADJUST THE SCREWS ON THE VERTICAILS TO LEVEL THE FLAT PANEL
Vertical
Rails
Maximum leveling
adjustment 0.5"
D
Flat
Panel
P10
