Summary of Contents for JohnDow Industries Professional Series
- Page 1 ™ Professional Series Hose Reels Models JD-3850, JDM-1250 and JDH-1450 Owner’s Manual 151 Snyder Ave. www.johndow.com Barberton, OH 44203 customerservice@johndow.com REV 5/11/2018...
- Page 2 OPERATOR’S MANUAL JD-3850, JDM-1250 & JDH-1450 Specifications: Automatic rewind. Lock to maintain the desired hose length. Please read the following cautions and instructions before using your new hose reel. Failure to comply with these instructions could result in personal injury or property damage. Keep these instructions in a convenient location for future reference.
- Page 3 OPERATOR’S MANUAL JD-3850, JDM-1250 & JDH-1450 Installation of Hose: 1. Securely stabilize the reel. 2. Facing the swivel fitting side of reel: Turn the drum clockwise, by hand, until the rewind spring is tight and drum has latched. As an extra precaution while installing new hose, secure drum in the latched position.
- Page 4 OPERATOR’S MANUAL JD-3850, JDM-1250 & JDH-1450 Replacement of Swivel Seal: 1. Turn OFF and disconnect supply line from swivel inlet. 2. Remove swivel assembly from reel axle. 3. Remove clip from swivel and take apart. NOTE: You may want to remove swivel from reel hose end, but this is NOT necessary unless a new swivel is being installed.
