- Page 1 KVM switch and rackmount screen technology User Manual RK-2e / RK-2b 1U Short Depth Keyboard Drawer Designed and manufactured by Austin Hughes UM-CV-751-RK2e-Q420V1 www.austin-hughes.com...
- Page 2 Legal Information First English printing, November 2020 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.
-
Page 3: Table Of Contents
Contents < Part. 1 > RK-2e / RK-2b Package Content Structure Diagram & Dimension Installation Connection < Part. 2 > Specifi cations Keyboard / Mouse Specifi cations Environmental Conditions UM-CV-751-RK2e-Q420V1 www.austin-hughes.com... -
Page 4: Part 1 > Rk-2E / Rk-2B
Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content. - Page 5 < 1.2 > Dimension RK-2e / b Front View Rear View Power KB / MS UNIT : mm Side View 1mm = 0.03937 inch Top View Product Dimension Packing Dimension Gross Model Net Weight (W x D x H) (W x D x H) Weight 441.6 x 400 x 44 mm 582 x 500 x 100 mm...
- Page 6 < 1.3 > Installation- How to install L-bracket Step ■ Install left & right rear L-brackets with two fasteners shown above. ■ Leave the fasteners slightly loose. Step ■ Measure the depth of the front and rear mounting rails. ■ Align each rear L-bracket to a suitable length and tighten the fasteners.
- Page 7 < 1.4 > Connection to USB Server RK-2e / b Keyboard Drawer attached 2-in-1 K/B cable USB server < 1.4 > Connection to external KVM Keyboard Drawer attached 2-in-1 K/B cable USB console KVM Caution : The keyboard drawer is hot-pluggable, but components of connected devices, such as the servers and KVM switch, may not be hot-pluggable.
-
Page 8: Part. 2 > Specifi Cations
< Part 2 > Specifi cations < 2.1 > Standard Keyboard / Mouse Specifi cations G keyboard integrated with touchpad G keyboard integrated with trackball Key force 55 ± 5g Travelling distance 3 ± 0.3mm Switch life > 10 million life cycle time OS support Windows / Linux / Unix / Mac OS Supporting layouts... - Page 9 < 2.1 > MAC Keyboard / Mouse Options RK-2e / b MAC keyboard integrated with touchpad MAC keyboard integrated with trackball Supporting layouts America United States How to Use "MAC" Keyboard Keyboard Features Decrease display brightness Fast-forward Increase display brightness Mute sound Mission control * Only works with OS X Lion...
- Page 10 < 2.1 > SUN Keyboard / Mouse Options GS keyboard integrated with touchpad GS keyboard integrated with trackball Ca ps Scro ll Comp ose Ca ps Scro ll Comp ose GS keyboard integrated with touchpad / trackball ■ Incorporates SUN keys, including Stop, Cut, Paste, Compose, Copy and Help ■...
-
Page 11: Environmental Conditions
< 2.2 > Environmental Conditions RK-2e / b Operating Temperature 0 to 55°C degree Humidity 20~90%, non-condensing Altitude 16,000 ft Storage / Non-operating Temperature -20 to 60°C degree Humidity 5~90%, non-condensing Altitude 40,000 ft Shock 10G acceleration (11ms duration) Vibration 10~300Hz 0.5G RMS random vibration UM-CV-751-RK2e-Q420V1 www.austin-hughes.com... - Page 12 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2020 Austin Hughes Electronics Ltd. All rights reserved. UM-CV-751-RK2e-Q420V1 www.austin-hughes.com...
