Furniture of America CM6778-SF Assembly Instructions

For more information contact our team: service.ec@foagroup.com

ASSEMBLY RATING

The Assembly Rating is a 5-point system that

shows the degree of effort needed in

assembling a specific product (with 1 being

easy and 5 being difficult). For some

products, two persons are recommended.

EASY

Assembly Instructions

CM6778-SF

DIFFICULT

Tools Required For Assembly:

Allen Wrench

Phillips Screwdriver

2 PERSONS RECOMMENDED

Page 1 of 5

(Included)

(Not Included)

Rev: 18-08-21

Table of Contents

Do you have a question about the CM6778-SF and is the answer not in the manual?

Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM6778-SF ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench assembling a specific product (with 1 being (Included) easy and 5 being difficult).
Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 5...
Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #A x 8pcs #1 x 1pc Sofa Bolt 5/16"x1-1/4" #B x 8pcs Spring washer Ø5/16" #2 x 4pcs #C x 8pcs #3 x 1pc Ø5/16"...
Page 4 #A x 8pcs #B x 8pcs #C x 8pcs Align legs (#2) to the sofa (#1), then secure by using bolts (#A) with washers (#B,C). #E x 16pcs Secure legs (#2) onto sofa (#1) by using screws (#E). Page 4 of 5...
Page 5 Attach support leg (#3) to the sofa (#1), then adjust the leveler of the support leg (#3) according to ground level. ASSEMBLY IS COMPLETED Page 5 of 5...
