Gebruikershandleiding (Engels)
INTEGRATED CONTROLLER VSC-5400
P/N : 388085110
PRINTED IN KOREA
Please read the instructions carefully and keep this manual for future reference.
VSC-5400
Advertisement
Summary of Contents for VSS Nederland VSC-5400
- Page 1 Gebruikershandleiding (Engels) INTEGRATED CONTROLLER VSC-5400 VSC-5400 P/N : 388085110 PRINTED IN KOREA Distributed by Nederland B.V. | Telfordstraat 11m | 8013 RL | Zwolle T.038 - 428 9 420 info@vssnederland.nl | www.vssnederland.nl Please read the instructions carefully and keep this manual for future reference.
- Page 2 - Unplug the power when thunder, lightning storm. 5.Auto Pan (May cause fire or damage.) ………………………………………… VSC-5400 PROTOCOL MAINTENANCE . SPECIFICATION …………………………………………………… - When controller body dirt, turn off the power and wipe the surface with a soft cloth. . DRAWING…………………………………………………………...
- Page 3 Excellent system compatibility with a variety of protocol implementations. An array of buttons, user convenience easy connection with other products and fine control make this unit as market needful product. This CCTV dedicated controller is very convenient to use by anyone. VSC-5400 2. Features (Controller) •...
- Page 4 HARDWARE OVERVIEW PART NAME & FUNCTION 1. DC12V Input 1. MOUSE 4. PTZ Function Keys 2. USB Port 3. RS-485 / RS-422 2. ESC/POWER 5. LCD Display 4. Program Update Port 3. Numbers 6. Joystick 7. Controller Function Keys 8. Camera Focus Control 9.
- Page 5 CONNECTION SYSTEM CONFIGURATION INTEGRATED Controller Keyboard VSC-5400 Single system configuration (Camera 1, kyeboard 1, DVR 1) can be used to connect&control DVR, MULTIPLEXER and other external devices. DVR PORT RS-485/422 Connection External device’s RS-485/422 port is connected to this Keyboard’s RS-485/422 terminal block.
- Page 6 SYSTEM CONFIGURATION PTZ CONTROL 1.Power On This device has two types of power use. Single system configuartion (PTZ connected directly) 1)Connect provided adaptor to power. 2)Insert 9V batteries inside.(Do not connect adaptor.) 3)Power on external devices which are connected to this device Max16 CAMERA before power on of this device.
- Page 7 Instructions and Setting up the MAIN SETUP MAIN SETUP : OFF / ON Select BUZZER ON/ OFF Connect the power adapter into the back of the keyboard and pressing button, The following 9. BUZZER : ON display appears on the LCD screen. MAIN SETUP Main MENU Set up : OFF / ON...
- Page 8 PTZ SETUP It is for the keyboard to set the Max.movement of joystick If you press button 1 + for 2~3 seconds, you can enter into the PTZ SETUP menu. If you press button 3 + for 2~3 seconds, you can enter into the JOYSTICK CALIBRATION menu.
- Page 9 3. PATTERN 3. PATTERN 1. PRESET 1. PRESET Camera memorizes the path (mostly curve path) by joystick of controller for assigned time and User can set the camera position where user want to see. revives the path exactly as it memorized. Consecutively operating 90˚...
- Page 10 VSC-5400 Protocol VSC-5400 Protocol DATA DATA 1. Serial Communication Format 1. Serial Communication Format short 0x01 short 0x01 Data Communication : RS485 / RS-422 0x11 shitf + short 0x03 long 0x02 Data bit : 8bit short 0x01 shift + short...
- Page 11 VSC-5400 MODEL Pan/Tilt interface : RS-485/422 Interface : RS-485/422 Keyboard Pan/Tilt operating distance : 4700FT (1029m) on 24 AWG wire communication Protocol : Multiple (Pelco-D, Pelco-P , Etc.) (Baud rate selectable) 180mm Connector Type Data TERMINAL BLOCK(8p) Rubber button Keyboard button...
