If you smell gas:
1. Shut off gas to appliance.
2. Extinguish any open flame.
3. If odour continues, immediately call your
gas supplier.
*
For Use Indoor/Outdoor Commercial and Outdoor Residential Use Only
* The HABANERO heater has been approved for indoor use in non-residential applications for Natural
Gas units ONLY
WARNING:
Improper installation, adjustment, alteration, service or maintenance can cause injury
or property damage. Read the installation, operating and maintenance instructions thoroughly before
installing or servicing this equipment.
OWNER: Please retain these instructions for future reference.
INSTALLER: The installer or seller must leave these instructions with the owner. Only those who are
certified to do so should perform service on these heaters.
A PATIO HEATER LIKE NO OTHER"
"
Series HAB
Model: HAB-M20
Manual for Installation, Operation & Maintenance
DANGER
Model: HAB-M40
Model: HAB-M50
Do not store or use gasoline or other flammable
vapours and liquids in the vicinity of this or any
other appliance. An LP cylinder not connected
for use shall not be stored in the vicinity of this or
any other appliance.
IMPORTANT
563 Barton Street,
Stoney Creek, Ontario L8E 5S1
www.irenergy.ca
FOR YOUR SAFETY
05/14 LT169
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Superior Radiant HAB Series
- Page 1 A PATIO HEATER LIKE NO OTHER” “ Series HAB Model: HAB-M20 Model: HAB-M40 Model: HAB-M50 Manual for Installation, Operation & Maintenance DANGER FOR YOUR SAFETY If you smell gas: Do not store or use gasoline or other flammable 1. Shut off gas to appliance. vapours and liquids in the vicinity of this or any 2.
-
Page 2: Table Of Contents
Table Of Contents CAUTION AND GENERAL SAFETY..........................3 ..............................3 AFETY EQUIREMENTS CODE REQUIREMENTS ..............................4 ..............................4 NSTALLATION ODES .................................. 4 ODES Gas Supply Lines..................................4 ................................. 4 LECTRICAL ODES SPECIFICATIONS ................................. 5 : ..............................5 IMENSIONAL ETAILS : ..........................5 AS AND LECTRICAL ONNECTIONS... -
Page 3: Caution And General Safety
Caution and General Safety CAUTION: FIRE OR BURN INJURY HAZARD At all times maintain clearance to combustible materials as further specified in this manual. Failure to do so can result in serious fire hazard. Never operate heaters in atmosphere containing flammable vapours or combustible dusts. -
Page 4: Code Requirements
Code Requirements - Installation Codes Installations must comply with local building codes, or in their absence, the latest edition of the national regulations and procedures as listed below. - Gas Codes Heaters must be installed only for use with the type of gas appearing on the rating plate. The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA 54 in the US, Natural Gas and Propane Installation Code, CSA B149.1, or Propane Storage and Handling Code B149.2 in Canada. -
Page 5: Specifications
Specifications Dimensional Details: Note: All dimensions are in inches. Model: HAB-M20 12.34 10.64 32.52 11.41 11.25 32.91 Model: HAB-M40 HAB-M50 12.34 10.64 47.06 11.41 11.25 47.45 - Gas and Electrical Connections: 5.41" Connection Electrical Connection Connection Optional Electrical 6.56" HAB-M20 Connection 6.09"... -
Page 6: Power & Gas Specifications
Specifications Important Installation or repair should only be done by a qualified service person. The heater should be inspected before use and at least annually by a qualified service person. The appliance and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of ½... -
Page 7: Equipment
Equipment - Standard Equipment Included: Model: HAB-M20 Model: HAB-M40 Model: HAB-M50 Series HAB Page 7 May-27-14... -
Page 8: Optional Equipment
Equipment - Optional Equipment: The following bolts are approved for installing this heater with the hanging brackets. 3/8” X 3” long Lag Bolts (minimum 4 per heater) with minimum 16.0” mounting spacing on centres. 3/8” X 3” Anchor Bolts (minimum 4 per heater) with minimum 16.0” mounting spacing on centres. ULTIMATE MOUNTING KITS STANDARD MOUNTING KITS HAB-M20... - Page 9 Equipment Optional Equipment continued: Optional Low Clearance Ceiling Mounting Kits HAB-M40 HAB-M20 HAB-M50 Hanging Bracket Assembly Heat Shield (QTY: 1) (QTY: 1) Heat Shield (QTY: 1) Low Clearance Mounting Bracket (QTY: 2) Heat Shield Heat Shield Mounting Bracket Mounting Bracket Extension Arm (QTY: 4) Hanging Bracket...
-
Page 10: Installation Instructions
Installation Instructions - Clearance to Combustibles A general clearance of 18” (0.5 m) in every direction is recommended for servicing only around each Burner, also to ensure adequate air flow in and around the Heating System. The stated clearance to combustibles represents a surface temperature of 90°F (50°C) above room temperature. - Page 11 Installation Instructions Clearance to Combustibles Table Model # Dim A Dim B Dim C Dim D Dim E Dim F Dim G Dim H HAB-M20 HAB-M40 HAB-M50 Optional Shield 30° Less than 30° mounting angle Less than 30° 31.0" HAB-M40 & M50 21.0"...
-
Page 12: Installation Sequence
Installation Instructions - Installation Sequence: The Habanero can be mounted either horizontally or at an incline of up to 30° as shown in the clearance to combustibles table (previous section). A review of the job site will usually indicate a logical installation location and order. -
Page 13: Ceiling / Wall Installation
Installation Instructions - Ceiling / Wall Installation Using Optional Standard Ceiling / Wall Mounting Kits The mounting kits have provision for 0°, 15° and 30° mounting angles using the optional mounting brackets. Figure below shows the possible angle configurations to install at desired angle. Ceiling Installation for HAB-M20, HAB-M40 and HAB-M50. -
Page 14: Using Optional Low Clearance Ceiling Mounting Kit Hab-M20 Only
Installation Instructions Using Optional Low Clearance Ceiling Mounting Kit HAB-M20 Only Step 1. Mount Low Clearance Brackets to ceiling using 3/8" X 3" long "Lag Bolt" or "Anchor Bolt" (Qty 4) not supplied. 31.0" Step 2. Install heat shield mounting brackets (as shown) using 5/16"... -
Page 15: Using Optional Low Clearance Ceiling Mounting Kit Hab-M40 And M50 Only
Installation Instructions Using Optional Low Clearance Ceiling Mounting Kit HAB-M40 and M50 Only Step 1. Mount Hanging Bracket Assembly to ceiling using 3/8" X 3" long "Lag Bolt" or "Anchor Bolt" (Qty 4) not supplied. Use these two bolt holes to attach bracket to extension arm refer to step 4. -
Page 16: Using Optional Low Clearance Non Combustible Ceiling Mounting Kits (All Models)
Installation Instructions Using Optional Low Clearance NON COMBUSTIBLE Ceiling Mounting Kits (all models). Step 1. Secure Hanging Bracket Assembly to ceiling / wall using 3/8" X 3" long "Lag Bolt" or "Anchor Bolts" (Qty 4) not supplied. Attach heater to hanging bracket assembly using these bolt holes. -
Page 17: Angle Mounting Configurations
Installation Instructions - Angle Mounting Configurations: The mounting kits have provision for 0°, 15° and 30° mounting angles using the optional mounting brackets. Figure below shows the possible angle configurations to install at desired angle. Ceiling Mount / Hanging Configuration Left side Right side of bracket... -
Page 18: Hab-M20 Installation
Installation Instructions - HAB-M20 Installation: Mounting heater at 0° from horizon. The figure below shows the minimum mounting distances to achieve the clearance to combustibles. Minimum Ceiling Mount Distance Use these bolt 9.00 holes for positioning at this angle. Note: Other clearances must be maintained as per clearance to combustibles table. - Page 19 Installation Instructions HAB-M20 Installation continued: Mounting heater at 30° from horizon. The figure below shows the minimum mounting distances to achieve the clearance to combustibles. Minimum Ceiling Mount Distance LEFT side view RIGHT side view 10.00 Cut unistrust to 10.00" to achieve the minimum 9.00 clearances to combustibles...
-
Page 20: Hab-M40 And M50 Installation
Installation Instructions - HAB-M40 and M50 Installation: Mounting heater at 0° from horizon. The figure below shows the minimum mounting distances to achieve the clearance to combustibles. Minimum Ceiling Mount Distance Use these bolt holes for positioning at this angle. 13.00 12.00 Cut unistrust to 12.00"... - Page 21 Installation Instructions HAB-M40 and M50 Installation continued: Mounting heater at 30° from horizon. The figure below shows the minimum mounting distances to achieve the clearance to combustibles. Minimum Ceiling Mount Distance LEFT side view RIGHT side view 18.00 16.00 Cut unistrust to 18.00" to achieve the minimum clearances to combustibles for this model...
-
Page 22: Gas Connection / Code Requirements
Installation Instructions - Gas Connection / Code Requirements Installation must comply with local building codes and/or, for the USA/National Fuel Gas Code, ANZI Z 223.1 (NFPA 54) and for Canada, CAN/CGA B149.1 and B149.2, National Gas and Propane Installation Code (latest editions). Do not use high pressure (above ½... -
Page 23: Electrical Connection / Code Requirements
Installation Instructions - Electrical Connection / Code Requirements The Habanero Heaters require 24VAC power supply (transformer to be supplied by installer). In all cases, heaters must be electrically grounded in accordance with local codes or in their absence, the National Electric Code, ANSI/NFPA 70 in the US, and the Canadian Electric Code, CSA C22.1. Heaters may also be controlled with a manual line switch or timer switch in place of the thermostat. -
Page 24: External Wiring Options. (Manual Line Switch With Hi-Lo Or Two Stage Switch)
Installation Instructions External wiring Options. (Manual line switch with Hi-Lo or Two Stage Switch) Manual Line Switch with Hi-LO wiring diagram Notes: - Allow Min. contact rating of Hi (on) 1AMP per heater inductive. - Allow 20VA / 24V. transformer per heater. -
Page 25: Venting
Installation Instructions - Venting This heater does not require venting. WARNING! This heater is NOT approved for any indoor Residential application. If in doubt of your application consult with your local fire marshal or gas authority having jurisdiction. Indoor spaces include but are not limited to attached garages, solariums, living quarters etc. -
Page 26: Lighting & Shutdown Instructions
Lighting & Shutdown Instructions - Lighting 1. Open manual gas supply valve (ensure gas supply lines have been purged). 2. Turn on switch to energize electric supply. 3. The electronic control module will time begin the ignition period in 3 seconds. 4. -
Page 27: Maintenance & Trouble Shooting
Maintenance & Trouble Shooting - Maintenance For best performance, the certain minimal maintenance procedures should be performed before each heating season: A service agency qualified to adjust and repair infrared heaters should be engaged for service other than routine maintenance. ... -
Page 28: Parts List
Parts List - Replacement Parts Description Item # Part # Spark Electrode HE001 Ignition Wire (not shown) CE006 Electronic Ignition Module EE009 EG001 Gas Valve NAT Burner Assembly HAB-M20 HG034 Burner Assembly HAB-M40 and HAB-M50 HG035 20VA 24V Transformer (not supplied) SE004 40VA 24V Transformer (not supplied) SE009... -
Page 29: Warranty
SOLE AND EXCLUSIVE REMEDIES. NO OTHER EXPRESS OR IMPLIED WARRANTIES ARE MADE INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR USE OR PURPOSE. Superior Radiant Products 563 Barton Street, Stoney Creek, Ontario L8E 5S1 www.superiorradiant.com...
