  • Page 1 Distributor of Olimex LTD: Excellent Integrated System Limited Datasheet of STM32-H407 - ST M3 STM32F407 HEADER BOARD Contact us: sales@integrated-circuit.com Website: www.integrated-circuit.com Excellent Integrated System Limited Excellent Integrated System Limited Stocking Distributor Stocking Distributor Click to view price, real time Inventory, Delivery & Lifecycle Information: Click to view price, real time Inventory, Delivery &...
  • Page 2 Distributor of Olimex LTD: Excellent Integrated System Limited Datasheet of STM32-H407 - ST M3 STM32F407 HEADER BOARD Contact us: sales@integrated-circuit.com Website: www.integrated-circuit.com STM32-H407 development board USER’S MANUAL Document revision E, May 2016 Designed by OLIMEX Ltd, 2012 All boards produced by Olimex LTD are ROHS compliant...

  • Page 3: Disclaimer

    Distributor of Olimex LTD: Excellent Integrated System Limited Datasheet of STM32-H407 - ST M3 STM32F407 HEADER BOARD Contact us: sales@integrated-circuit.com Website: www.integrated-circuit.com OLIMEX© 2016 STM32-H407 user's manual DISCLAIMER © 2016 Olimex Ltd. Olimex®, logo and combinations thereof, are registered trademarks of Olimex Ltd. Other product names may be trademarks of others and the rights belong to their respective owners.

  • Page 4: Table Of Contents

    Distributor of Olimex LTD: Excellent Integrated System Limited Datasheet of STM32-H407 - ST M3 STM32F407 HEADER BOARD Contact us: sales@integrated-circuit.com Website: www.integrated-circuit.com OLIMEX© 2016 STM32-H407 user's manual Table of Contents DISCLAIMER ......................2 CHAPTER 1 OVERVIEW ..................5 1. Introduction to the chapter ....................... 5 1.1 Features .............................
  • Page 5 Distributor of Olimex LTD: Excellent Integrated System Limited Datasheet of STM32-H407 - ST M3 STM32F407 HEADER BOARD Contact us: sales@integrated-circuit.com Website: www.integrated-circuit.com OLIMEX© 2016 STM32-H407 user's manual 6.11.1 PWR_SEL ..........................19 6.11.2 B1_1/B1_0 and B0_1/B0_0 ...................... 20 6.11.3 R-T ............................20 6.11.4 3.3V_E ............................

  • Page 6: Chapter 1 Overview

    Distributor of Olimex LTD: Excellent Integrated System Limited Datasheet of STM32-H407 - ST M3 STM32F407 HEADER BOARD Contact us: sales@integrated-circuit.com Website: www.integrated-circuit.com OLIMEX© 2016 STM32-H407 user's manual CHAPTER 1 OVERVIEW 1. Introduction to the chapter Thank you for choosing the STM32-H407 single board computer from Olimex! This document provides a user’s guide for the Olimex STM32-H407 board.

  • Page 7: H407 Or E407

    Distributor of Olimex LTD: Excellent Integrated System Limited Datasheet of STM32-H407 - ST M3 STM32F407 HEADER BOARD Contact us: sales@integrated-circuit.com Website: www.integrated-circuit.com OLIMEX© 2016 STM32-H407 user's manual 1.2 H407 or E407? The major difference between STM32-H407 and STM32-E407 is that the latter has built-in Ethernet (physical level transceiver Micrel).

  • Page 8: Chapter 2 Setting Up The Stm32-H407 Board

    Distributor of Olimex LTD: Excellent Integrated System Limited Datasheet of STM32-H407 - ST M3 STM32F407 HEADER BOARD Contact us: sales@integrated-circuit.com Website: www.integrated-circuit.com OLIMEX© 2016 STM32-H407 user's manual CHAPTER 2 SETTING UP THE STM32-H407 BOARD 2. Introduction to the chapter This section helps you set up the STM32-H407 development board for the first time. Please consider first the electrostatic warning to avoid damaging the board, then discover the hardware and software required to operate the board.

  • Page 9: Powering The Board

    Distributor of Olimex LTD: Excellent Integrated System Limited Datasheet of STM32-H407 - ST M3 STM32F407 HEADER BOARD Contact us: sales@integrated-circuit.com Website: www.integrated-circuit.com OLIMEX© 2016 STM32-H407 user's manual 2.3 Powering the board The board is powered in one of the following ways: 1) by PWR jack, 2) by JTAG/SWD programmer, 3) by USB-OTG.

  • Page 10: Chapter 3 Stm32-H407 Board Description

    Distributor of Olimex LTD: Excellent Integrated System Limited Datasheet of STM32-H407 - ST M3 STM32F407 HEADER BOARD Contact us: sales@integrated-circuit.com Website: www.integrated-circuit.com OLIMEX© 2016 STM32-H407 user's manual CHAPTER 3 STM32-H407 BOARD DESCRIPTION 3. Introduction to the chapter In this chapter you will get acquainted with the main parts of the board. Note the names used on the board differ from the names used to describe them.

  • Page 11: Layout (Bottom View)

    Distributor of Olimex LTD: Excellent Integrated System Limited Datasheet of STM32-H407 - ST M3 STM32F407 HEADER BOARD Contact us: sales@integrated-circuit.com Website: www.integrated-circuit.com OLIMEX© 2016 STM32-H407 user's manual 3.2 Layout (bottom view) On the bottom there are three tables printed – general jumper table, boot mode jumper table, power mode jumper table.

  • Page 12: Chapter 4 The Stm32F407Zgt6 Microcontroller

    Distributor of Olimex LTD: Excellent Integrated System Limited Datasheet of STM32-H407 - ST M3 STM32F407 HEADER BOARD Contact us: sales@integrated-circuit.com Website: www.integrated-circuit.com OLIMEX© 2016 STM32-H407 user's manual CHAPTER 4 THE STM32F407ZGT6 MICROCONTROLLER 4. Introduction to the chapter In this chapter is located the information about the heart of STM32-H407 – its Cortex-M4F microcontroller.
  • Page 13 Distributor of Olimex LTD: Excellent Integrated System Limited Datasheet of STM32-H407 - ST M3 STM32F407 HEADER BOARD Contact us: sales@integrated-circuit.com Website: www.integrated-circuit.com OLIMEX© 2016 STM32-H407 user's manual  USB 2.0 high-speed/full-speed device/host/OTG controller with dedicated DMA, on- chip full-speed PHY and ULPI ...

  • Page 14: Chapter 5 Control Circuity And Hardware Modules

    Distributor of Olimex LTD: Excellent Integrated System Limited Datasheet of STM32-H407 - ST M3 STM32F407 HEADER BOARD Contact us: sales@integrated-circuit.com Website: www.integrated-circuit.com OLIMEX© 2016 STM32-H407 user's manual CHAPTER 5 CONTROL CIRCUITY AND HARDWARE MODULES 5. Introduction to the chapter Here you can find information about reset circuit and quartz crystals locations, the power supply circuit is discussed.

  • Page 15: Chapter 6 Connectors And Pinout

    Distributor of Olimex LTD: Excellent Integrated System Limited Datasheet of STM32-H407 - ST M3 STM32F407 HEADER BOARD Contact us: sales@integrated-circuit.com Website: www.integrated-circuit.com OLIMEX© 2016 STM32-H407 user's manual CHAPTER 6 CONNECTORS AND PINOUT 6. Introduction to the chapter In this chapter are presented the connectors that can be found on the board all together with their pinout and notes about them.

  • Page 16: Uext Module

    Distributor of Olimex LTD: Excellent Integrated System Limited Datasheet of STM32-H407 - ST M3 STM32F407 HEADER BOARD Contact us: sales@integrated-circuit.com Website: www.integrated-circuit.com OLIMEX© 2016 STM32-H407 user's manual microSD card connector Pin # Signal Name DAT2/RES CD/DAT3/CS CMD/DI SCL/SCLK DAT0/RES DAT1/RES Notice that the pad numeration is written at the bottom of STM32-H407 under the microSD card connector.

  • Page 17: Usb Host

    Distributor of Olimex LTD: Excellent Integrated System Limited Datasheet of STM32-H407 - ST M3 STM32F407 HEADER BOARD Contact us: sales@integrated-circuit.com Website: www.integrated-circuit.com OLIMEX© 2016 STM32-H407 user's manual 6.4 USB HOST The big advantage of having USB hosts available over USB devices is that you can as well use them as masters.
  • Page 18 Distributor of Olimex LTD: Excellent Integrated System Limited Datasheet of STM32-H407 - ST M3 STM32F407 HEADER BOARD Contact us: sales@integrated-circuit.com Website: www.integrated-circuit.com OLIMEX© 2016 STM32-H407 user's manual Arduino platform pinholes CON1 CON2 Processor Pin Signal Name Pin Signal Name Processor pin# pin# 3.3V Arduino platform pinholes...

  • Page 19: 20-Pin Connectors - Pd - Pe - Pf - Pg

    Distributor of Olimex LTD: Excellent Integrated System Limited Datasheet of STM32-H407 - ST M3 STM32F407 HEADER BOARD Contact us: sales@integrated-circuit.com Website: www.integrated-circuit.com OLIMEX© 2016 STM32-H407 user's manual 6.7 20-pin connectors – PD – PE – PF – PG The 4×20-pin connectors combine different processor ports and provide very nice GPIO option – you can use them with your breadboarding wires, you can mount headers, you can take measures, etc, etc.

  • Page 20: Pwr Jack

    Distributor of Olimex LTD: Excellent Integrated System Limited Datasheet of STM32-H407 - ST M3 STM32F407 HEADER BOARD Contact us: sales@integrated-circuit.com Website: www.integrated-circuit.com OLIMEX© 2016 STM32-H407 user's manual 6.8 PWR Jack The power jack used is the typical 2.5mm one used by Olimex in most of our products. You should provide between 6 and 16 volts @ 1A to the board.

  • Page 21: B1_1/B1_0 And B0_1/B0_0

    Distributor of Olimex LTD: Excellent Integrated System Limited Datasheet of STM32-H407 - ST M3 STM32F407 HEADER BOARD Contact us: sales@integrated-circuit.com Website: www.integrated-circuit.com OLIMEX© 2016 STM32-H407 user's manual If powering from the USB-OTG set it in 5-6 position (to the tall capacitor C46) The default position is 1-2.

  • Page 22: Aref_En

    Distributor of Olimex LTD: Excellent Integrated System Limited Datasheet of STM32-H407 - ST M3 STM32F407 HEADER BOARD Contact us: sales@integrated-circuit.com Website: www.integrated-circuit.com OLIMEX© 2016 STM32-H407 user's manual 6.11.6 AREF_EN This is SMD type jumper. If open/unsoldered will disable ADC reference. The default position is closed.

  • Page 23: Chapter 7 How To Use The Board With Arduino Ide

    Distributor of Olimex LTD: Excellent Integrated System Limited Datasheet of STM32-H407 - ST M3 STM32F407 HEADER BOARD Contact us: sales@integrated-circuit.com Website: www.integrated-circuit.com OLIMEX© 2016 STM32-H407 user's manual CHAPTER 7 HOW TO USE THE BOARD WITH ARDUINO IDE In order to program the board with Arduino IDE you would need a mini USB cable. Note that you you would also need to enter bootloader mode by manipulating the B1 and B0 jumpers.

  • Page 24: Chapter 8 Block Diagram And Memory

    Distributor of Olimex LTD: Excellent Integrated System Limited Datasheet of STM32-H407 - ST M3 STM32F407 HEADER BOARD Contact us: sales@integrated-circuit.com Website: www.integrated-circuit.com OLIMEX© 2016 STM32-H407 user's manual CHAPTER 8 BLOCK DIAGRAM AND MEMORY 8. Introduction to the chapter Below you can find a memory map for this family of processors. It is strongly recommended to refer to the original datasheet released by STMicroelectronics for one of higher quality.

  • Page 25: Physical Memory Map

    Distributor of Olimex LTD: Excellent Integrated System Limited Datasheet of STM32-H407 - ST M3 STM32F407 HEADER BOARD Contact us: sales@integrated-circuit.com Website: www.integrated-circuit.com OLIMEX© 2016 STM32-H407 user's manual 8.2 Physical memory map Page 24 of 30...

  • Page 26: Chapter 9 Schematics

    Distributor of Olimex LTD: Excellent Integrated System Limited Datasheet of STM32-H407 - ST M3 STM32F407 HEADER BOARD Contact us: sales@integrated-circuit.com Website: www.integrated-circuit.com OLIMEX© 2016 STM32-H407 user's manual CHAPTER 9 SCHEMATICS 9. Introduction to the chapter In this chapter are located the schematics describing logically and physically STM32-H407. 9.1 Eagle schematic STM32-H407 schematic is visible for reference here.
  • Page 27 Distributor of Olimex LTD: Excellent Integrated System Limited Datasheet of STM32-H407 - ST M3 STM32F407 HEADER BOARD Contact us: sales@integrated-circuit.com Website: www.integrated-circuit.com OLIMEX© 2016 STM32-H407 user's manual 3.3V 3.3V 3.3V 3.3V 3.3V 3.3V PA9/OTG_FS_VBUS 0R(board_mounted) USB_HOST 3.3V USB_HOST 3.3V PA11/OTG_FS_DM +5V_HOST_PWR +5V_HOST_PWR USB_HOST_D-...

  • Page 28: Physical Dimensions

    Distributor of Olimex LTD: Excellent Integrated System Limited Datasheet of STM32-H407 - ST M3 STM32F407 HEADER BOARD Contact us: sales@integrated-circuit.com Website: www.integrated-circuit.com OLIMEX© 2016 STM32-H407 user's manual 9.2 Physical dimensions Note that all dimensions are in millimeters. The three highest elements on the board in order from the tallest to the shortest are: capacitor C46 – 17.2mm (0.677'') over the pcb;...

  • Page 29: Chapter 10 Revision History And Support

    Distributor of Olimex LTD: Excellent Integrated System Limited Datasheet of STM32-H407 - ST M3 STM32F407 HEADER BOARD Contact us: sales@integrated-circuit.com Website: www.integrated-circuit.com OLIMEX© 2016 STM32-H407 user's manual CHAPTER 10 REVISION HISTORY AND SUPPORT 10. Introduction to the chapter In this chapter you will find the current and the previous version of the document you are reading. Also the web-page for your device is listed.

  • Page 30: Useful Web Links And Purchase Codes

    Distributor of Olimex LTD: Excellent Integrated System Limited Datasheet of STM32-H407 - ST M3 STM32F407 HEADER BOARD Contact us: sales@integrated-circuit.com Website: www.integrated-circuit.com OLIMEX© 2016 STM32-H407 user's manual 10.3 Useful web links and purchase codes The web page you can visit for more info on your device is https://www.olimex.com/Products/ARM/ST/STM32-H407/.

  • Page 31: Product Support

    Distributor of Olimex LTD: Excellent Integrated System Limited Datasheet of STM32-H407 - ST M3 STM32F407 HEADER BOARD Contact us: sales@integrated-circuit.com Website: www.integrated-circuit.com OLIMEX© 2016 STM32-H407 user's manual 10.4 Product support For product support, hardware information and error reports mail to: support@olimex.com. All document or hardware feedback is welcome.
