INTRODUCTION
The AL5721 PCB Radio module is a complete compact device radio reference design
that enables quick design of UWB enabled products.
The AL5721 combines the Alereon AL5000 chipset along with on board power supplies,
an antenna output, a USB function controller and a USB 2.0 system interface.
1.0 REFERENCE DESIGN FEATURES
•
Optimized Performance with AL5100 (3.1GHz to 8.976GHz) WiMedia BG#1, 3, 6
•
Complete Baseband Processor (BBP) and Media Access Controller (MAC)
•
High Precision Data Path and Data Converters allowing reliable link at extended
ranges
•
Fully Integrated MAC Protocol Engine Supports All Industry Standards WiMedia
protocols
- Certified Wireless USB
- WiMedia Link Layer Protocol
- Bluetooth 3.0 (supported by future SW releases)
•
Industry Standard Interfaces
- USB 2.0 – Data
- USB 2.0 – WiMedia Cable Association
•
Operates from a single (+3.3 V, regulated) supply
•
Small Form Factor (Minicard form factor)
•
3 GPIO lines for LED Indicators or additional system control signals
2.0 Usage and Documentation
The AL5721 is a complete, self-contained UWB radio module requiring only +3.3V
regulated power from the host system and providing USB 2.0 interfaces to the host
system for data and the WiMedia association function. The AL5712 is intended to
provide a simple path for a wired USB product design to migrate to a UWB enabled
wireless USB product design.
The AL5721 is a wireless USB certified platform and has received FCC approval as a
Modular UWB transmitter under subpart F of the FCC rules with the FCC ID:
U9YAL5721. The product implementation can apply these approvals to the product
which incorporates the AL5721.
This document provides an outline of the purpose and functionality provided by the
AL5721, complete information for the product system designer is contained in the
Alereon Reference Design Kit (RDK) package consisting of: Schematic diagram, BOM,
and PCB fabrication information including a full Gerber data set.
UG-AL5721_1.0
P.1/7
