- Page 1 OWNER’S MANUAL (LED Monitor*) * LG LED Monitor applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. 32GN500 32GN50T www.lg.com 32GN550 Copyright © 2019 LG Electronics Inc. All Rights Reserved.
-
Page 2: Table Of Contents
TABLE OF CONTENTS LICENSE ........3 USING THE MONITOR ....14 TROUBLESHOOTING ....30 - Connecting to a PC...........15 OPEN SOURCE SOFTWARE PRODUCT SPECIFICATION ..33 HDMI Connection NOTICE INFORMATION ....4 - Factory Support Mode..........37 DisplayPort Connection - HDMI Timing (Video) ..........38 - Connecting AV Devices ...........16 ASSEMBLING AND PREPARING 4 - Power LED ..............38... -
Page 3: License
LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. -
Page 4: Open Source Software Notice Information
• It is recommended that use the supplied components. • If you use generic cables not certified by LG, the screen may not display or there may be image noises. • Illustrations in this document represent typical procedures, so they may look different from the actual product. -
Page 5: Supported Drivers And Software
Supported Drivers and Software Product and Button Description You can download and install the latest version from the LGE website (www.lg.com). Drivers and Software Installation Priority Monitor Driver Recommended Recommended Joystick Button... -
Page 6: How To Use The Joystick Button
Moving and Lifting the Monitor How to Use the Joystick Button You can easily control the functions of the monitor by pressing the joystick button or When moving or lifting the monitor, follow these instructions to prevent the monitor moving it left/right with your finger. from being scratched or damaged and to ensure safe transportation, regardless of its shape or size. - Page 7 • If you use the monitor panel without the stand base, its joystick button may cause the monitor to become unstable and fall, resulting in damage to the monitor or human injury. In addition, this may cause the joystick button to malfunction. •...
-
Page 8: Installing On A Table
Installing on a Table CAUTION • Lift the monitor and place it on the table in an upright position. Place the monitor • Unplug the power cord before moving or installing the monitor. There is risk of at least 100 mm away from the wall to ensure sufficient ventilation. electric shock. -
Page 9: Adjusting The Stand Height (32Gn550)
Adjusting the Stand Height (32GN550) Adjusting the Angle (32GN550) Place the monitor mounted on the stand base in an upright position. Place the monitor mounted on the stand base in an upright position. Handle the monitor with both hands for safety. Adjust the angle of the screen. - Page 10 • Be careful not to touch or press the screen area when adjusting the angle of the WARNING monitor. • To avoid injury to the fingers when adjusting the screen, do not hold the lower part 32GN550 of the monitor’s frame as illustrated below. 32GN500 32GN50T 32GN550 32GN550...
-
Page 11: Tidying Up Cables
Tidying up Cables Using the Kensington Lock Arrange the cables using the cable holder as shown in the illustration. The connector for the Kensington security system is located at the bottom of the monitor. For more information on installation and usage, refer to the Kensington lock owner’s manual or visit the website at http://www.kensington.com. -
Page 12: Installing The Wall Mount Plate
Installing the Wall Mount Plate Installing on the Wall This monitor meets the specifications for the wall mount plate or other compatible Install the monitor at least 100 mm away from the wall and leave about 100 mm devices. of space at each side of the monitor to ensure sufficient ventilation. Detailed installation instructions can be obtained from your local retail store. - Page 13 The length of the screw may differ for each wall mounting bracket. Be sure to use A non-VESA standard screw may damage the product and cause the monitor the proper length. to fall. LG Electronics is not liable for any accidents relating to the use of non- standard screws. •...
-
Page 14: Using The Monitor
USING THE MONITOR • Use the wall mounting bracket and screws that conform to VESA standards. Damage caused by the use or misuse of inappropriate components will not be covered by the product warranty. • Illustrations in this manual may differ from the actual product. •... -
Page 15: Connecting To A Pc
Connecting to a PC DisplayPort Connection Transmits digital video and audio signals from your PC to the monitor. • This monitor supports the *Plug and Play feature. * Plug and Play: A feature that allows you to add a device to your computer without NOTE having to reconfigure anything or install any manual drivers. -
Page 16: Connecting Av Devices
Connecting AV Devices Connecting Peripherals HDMI Connection Connecting Headphones HDMI transmits digital video and audio signals from your AV device to the monitor. Connect peripherals to the monitor via the headphones port. NOTE NOTE • Using a DVI to HDMI / DP (DisplayPort) to HDMI cable may cause compatibility •... -
Page 17: User Settings
USER SETTINGS Button Menu Status Description Main menu disabled Enables the main menu. Exits the main menu. Activating the Main Menu (Holding down the button to turn off the monitor. You can Main menu enabled turn off the monitor this way at any time, including when the Press the joystick button on the bottom of the OSD is on.) monitor. -
Page 18: Main Menu Features
Main Menu Features Main Menu Description Input Sets input mode. Power Off Power Off Turns off the monitor. Menu Configures the screen settings. Exit Input Menu Game Mode Sets the game mode for gaming. Game Mode Exit Exits the main menu. -
Page 19: User Settings
User Settings Menu Settings To view the OSD menu, press the joystick button at the bottom of the monitor and then enter the Menu. Configure the options by moving the joystick up/down/left/right. To return to the upper menu or set other menu items, move the joystick to or pressing ( ) it. - Page 20 Game Mode on SDR(Non-HDR)signal. Menu > Game Mode Description Gamer 1 In this mode, users can customize elements including game-related options. Gamer 1 and Gamer 2 picture modes allow you to save two sets of customized display settings, including game-related setup Gamer 2 options.
- Page 21 Game Mode on HDR signal. Menu > HDR Game Mode Description Gamer 1 In this mode, users can customize elements including game-related options. Gamer 1 and Gamer 2 picture modes allow you to save two sets of customized display settings, including game-related setup Gamer 2 options.
- Page 22 This mode minimizes motion blur in fast-moving videos. To take full advantage of this function, select 1920 x 1080 @ 120Hz/144Hz/165Hz before enabling 1ms Motion Blur Reduction. This function is available for the following vertical frequency. (120Hz/144Hz/165Hz) Turns 1ms Motion Blur Reduction Mode off. 1ms Motion Blur Game Adjust Reduction...
- Page 23 Provides seamless and natural images by synchronizing the vertical frequency of the input signal with that of the output signal. CAUTION • In HDMI input, the menu name is displayed as certified AMD FreeSync Tier name instead of Adaptive-Sync. (FreeSync / FreeSync Premium / FreeSync Premium Pro) •...
- Page 24 Sets a response time for displayed pictures based on the speed of the screen. For a normal environment, it is recommended that you use Fast. For a fast-moving picture, it is recommended that you use Faster. Once Faster Mode is selected, Motion Blur may occur depending on the content. Response Time Faster Sets the response time to faster.
- Page 25 Menu > Picture Adjust Description Adjusts the brightness of the screen. Brightness Adjusts the contrast of the screen. Contrast Sharpness Adjusts the sharpness of the screen. Mode 1, Mode The higher the gamma value, the darker the image becomes. Likewise, the lower the gamma value, the lighter the image becomes.
- Page 26 Adjusts the brightness automatically according to the screen. Disables the DFC feature. Do you want to reset your picture settings? Picture Adjust Picture Reset Cancel the select. Returns to the default settings.
- Page 27 Menu > Input Description Input List Selects the input mode. Adjusts the aspect ratio of the screen. Full Wide Displays the video in widescreen, regardless of the video signal input. Input Original Displays video according to the aspect ratio of the video signal input. Aspect Ratio NOTE The display may look the same for Full Wide and Original options at the recommended resolution.
- Page 28 Menu > General Description Language Sets the menu screen to the desired language. High Saves energy using the high-efficiency SMART ENERGY SAVING feature. Saves energy using the low-efficiency SMART ENERGY SAVING feature. Disables the SMART ENERGY SAVING feature. SMART ENERGY SAVING NOTE •...
- Page 29 This feature lets you set the sound generated from Buzzer when your monitor powers on. Buzzer Enables your monitor's Buzzer. Disables your monitor's Buzzer. This feature disables the configuration and adjustment of menus. Enables OSD Lock. General Disables OSD Lock. OSD Lock NOTE All features are disabled except Brightness, Contrast in Picture Adjust, Input, OSD Lock and Information in General.
-
Page 30: Troubleshooting
Have you installed the display driver? • Be sure to install the display driver from our web site: http://www.lg.com. • Make sure to check if the graphics card supports Plug and Play function. Some features are disabled. - Page 31 The screen retains an image. Does image sticking occur even when the • Displaying a still image for a prolonged time may cause damage to the screen, resulting in the retention of the image. monitor is turned off? • To extend the lifetime of the monitor, use a screensaver. Screen display is unstable and shaky.
- Page 32 The display color is abnormal. Does the display appear discolored • Set the color to 24 bit (true color) or higher. In Windows, go to Control Panel > Display > Menu > Color Quality. (The settings (16 colors)? may differ depending on the operating system (OS) you use.) Does the display color appear unstable or •...
-
Page 33: Product Specification
PRODUCT SPECIFICATION 32GN500 32GN50T LCD Screen Color Depth 8-bit color is supported. Resolution Max Resolution 1920 x 1080 @ 165 Hz Recommended Resolution 1920 x 1080 @ 165 Hz Power Sources Power Rating 19 V 2.0 A Power Consumption On mode: 40 W Typ. (Outgoing condition)* (Typical) Sleep Mode: ≤... - Page 34 Dimensions Monitor Size (Width x Height x Depth) With Stand 714.7 x 515.1 x 224.8 (mm) Without Stand 714.7 x 428 x 77.5 (mm) Weight (Without Packaging) With Stand 5.9 kg Without Stand 5.2 kg Specifications are subject to change without notice. The Power Consumption level can be different by operating condition and monitor setting.
- Page 35 PRODUCT SPECIFICATION 32GN550 LCD Screen Color Depth 8-bit color is supported. Resolution Max Resolution 1920 x 1080 @ 165 Hz Recommended Resolution 1920 x 1080 @ 165 Hz Power Sources Power Rating 19 V 2.0 A Power Consumption On mode: 40 W Typ. (Outgoing condition)* (Typical) Sleep Mode: ≤...
- Page 36 Dimensions Monitor Size (Width x Height x Depth) With Stand 714.7 x 600.3 x 292.1 (mm) Without Stand 714.7 x 428 x 50.9 (mm) Weight (Without Packaging) With Stand 7.2 kg Without Stand 5.1 kg Specifications are subject to change without notice. The Power Consumption level can be different by operating condition and monitor setting.
-
Page 37: Factory Support Mode
Factory Support Mode (Preset Mode, HDMI/ DisplayPort PC) Preset Mode Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 76.302 800 x 600 37.879 60.317 1024 x 768 97.551 1024 x 768 48.363 60.0 1280 x 720... -
Page 38: Hdmi Timing (Video)
HDMI Timing (Video) Preset Mode Horizontal Frequency (kHz) Vertical Frequency (Hz) Remarks 480P 31.5 720P 1080P 67.5 1080P Only HDMI 2.0 and HDMI Freesync Premium 2160P Only HDMI 2.0 and HDMI Freesync Premium Power LED Mode LED Color On Mode Red (For a few seconds) Sleep Mode Off Mode... - Page 39 The model and serial number of the product are located on the back and on one side of the product. Record them below in case you ever need service. Model Serial No.
