- Page 1 S2-MiniBox, S2-GrandBox User’s Manual E-311 E-321...
- Page 2 SAFETY This HD Receiver has been manufactured to satisfy the international safety standards. Please read the following safety precautions carefully. MAINS SUPPLY: External DC 12V Adapter OVERLOADING: Do not overload wall outlet, extension cord or adapter as this may result in fire or electric shock. LIQUIDS: Keep liquids away from the HD Receiver.
- Page 3 FEATURES MPEG-Fully DVB-S / DVB-S2 (H.264) HD compliant 6000 channels (TV and Radio) programmable Multilingual menu text support Channel switching time less than 1 second Channel list editing Favorite channel list editing True-color On-Screen Display (OSD) ...
-
Page 4: Remote Control
Remote Control You can power on/off the receiver, operate on screen menu, and use a variety of hot key function. POWER To switch your receiver on from standby or standby to on. MUTE Used to enable or disable the audio NUMERIC KEYS Used to select channels or enter programming parameters TV / RADIO Receiver switches between TV and Radio mode. - Page 5 Front panel (E-311) Remote Sensor: Detects infrared signal from remote control unit. POWER Indicator: while the receiver is power on and at standby mode. Card Slot: One CA Interface for Conax. USB A: USB 2.0 Host, connect to USB hard disk, or flash disk. (On the left side of the receiver) Display: (LED type) Indicates operating status of receiver.
- Page 6 Front panel (E-321) Remote Sensor: Detects infrared signal from remote control unit. POWER Indicator: while the receiver is power on and at standby mode. Card Slot: One CA Interface for Conax. Display: (LED type) Indicates operating status of receiver. (Optional) Rear Panel (E-321) LNB IN: This port is to connect the coaxial cable from LNB of your Dish.
-
Page 7: Basic Operations
Favorite Basic Operations In full screen, press [FAV] key, it will display a Turn on STB window of “Favorite list” on the left of the screen, First, press the [Device’s Main Power] to turn on the which you can watch like below. unit. -
Page 8: Channel List
Press [Yellow] key in EPG menu can set one record Information timer or go to Timer List menu. In full screen, press [INFO] key (press [INFO] key and [RED] key) can open information screen, in the window shows the parameters of current channel. In EPG menu, when you select one event by high light item, you can set this event to record timer list directly by press [REC] button. -
Page 9: Page Up/Page Down
will switch the mode between Sleep Timer Off /10/30/60/90/120 minutes. Page Up/Page Down In Channel list, press [Page+/Page-] key can page up and page down the channel list. TEXT Press [green] key in full screen, you can open Press [Yellow] key you can change the current teletext page on the channel which has teletext •... -
Page 10: Organizing Service
dialogue for user to key in password. The TV/RCV default Password is “0000”. Press [TV/RCV] key can switch between TV mode and STB mode Press [Menu] key to go back to main menu. Menu Organizing Service Press [MENU] key can open the menu, exit the When you enter to “Organizing Service”... - Page 11 Options Select Lock icon by press [Channel • Up/Channel Down] key and [OK] key. Lock the channel by press [OK] key. • Like the following picture: • • Press [Green] key can open the “Options” window like above. • You can press [Up/Down] key to move Delete highlight and press [OK] key to confirm the select mode.
-
Page 12: Organizing Favourites
Press[Find] key can open the “Find” window • like above. You can press[Channel Up/Channel Down/Volume Up/Volume Down]key to move highlight and press [OK] key to input the selected symbol or letter into the dialogue. After input each character, the program list on •... -
Page 13: Satellite Installation
Installation Diseqc Diseqc: You can use [Volume Up/ Volume Down] Press [Left/Right] key to select menu • key to switch options. There are several options for pages among Service, Installation, Preference, System, Conditional Access, your selection: Internet, USB and Game. •... - Page 14 Tonebusrt will delete all transponders or not. If you select In “Toneburst” item, you can press [Volume Up/ “OK”, all transponders will be deleted. Volume Down]key to switch “Off/On” functions. For the existed transponder, you also can use • number keys to modify the parameters of “TP LNB Power Frequency”...
-
Page 15: Satellite Guide
“Auto Installation” is a very new and convenient function. It will automatically detect all dishes connecting to this machine and scan the available services belonging to the satellite matched according to satellites and transponders data in current database. You don’t have to input any parameter of your antenna settings. - Page 16 audio languages include: English, French, System German, Russian, Arabic, Portuguese, When you enter to “System” menu, you will see a Turkish, Spanish, Polish and Italian. screen like below: Second Audio: If the channel has no • correspond audio with “First Audio” but have corresponded audio with “Second Audio”, system will play the second audio language as default.
-
Page 17: Ethernet Setting
will be efficient for each other’s. By Source means system will set the video output resolution according to the program it’s playing, different resolution programs switching perhaps will makes TV screen flickering. By Native TV means system will be according to the HDMI TV’s max supported resolution to set its resolution, if system is not connected to a HMDI TV, it will set resolution to be default... - Page 18 12:00 ~ +12:00”, increase each half hour progressively. You can press [Left/Right] to control Summer time on or off. “Date” and “Time” items are valid only when the setting of “GMT Usage” is “No”. You can press [Volume Up / Volume Down] keys to moving highlight and use number keys to input directly.
-
Page 19: Parental Control
Miscellaneous Settings Parental Control When you enter to “Miscellaneous Settings” menu, you will see a screen like below: You can set a password for anyone who wishes to operate in the “Installation” menu. And you can also set the password for the lock channels. (How to set the lock channel please refer to LOCK) Here will show you how to setting and how to revising the password. - Page 20 Software Upgrade Default Setting Default Value: Upgrade By USB In this menu you can upgrade the software from When you press [OK] key In the “Default USB conveniently, Press “Left/Right” button select Setting” item: USB A or USB B; press ' OK ' button to enter. There will pop a dialogue for you to enter the password, and the default password is “0000”.
-
Page 21: Save Default Value
coded in this system. This menu shows detailed Save default value information about cord inserted into cord reader module. It allows inserted according to help messages visible on the bottom of the screen. When you press [OK] key in the “Save default value”... - Page 22 To edit the files or folders. Include rename, copy, Media delete and create folder function. You can press if you enter to the "USB" Menu, you will see the [Exit] key to previous menu. picture like the below: Note: If no USB Hard Disk insert to the receiver this Music menu is not available.
-
Page 23: Pvr Setting
PVR Setting Press “Blue” button to enter the USB Speed Test menu like the below picture，you can see the Standard speed and your USB harddisk speed, Time Shift: according this information you can know what operation your disk can support..In this menu,and ON: Enable the Time Shift function. - Page 24 Application Application Application Application If you enter to the " Application " Menu, you will see the picture like the below: Youtube Youtube Youtube Youtube This menu is some internet applications. "youtube" can play stream media from "www.youtube.com". RSS Reader RSS Reader RSS Reader RSS Reader...
-
Page 25: Troubleshooting
Trouble Shooting Trouble Shooting Trouble Shooting Trouble Shooting If you suspect there is a fault with your receiver, please check the following trouble shooting guide before calling authorized service agent. Warning! Under no circumstances attempt to repair the receiver yourself. Tampering with the receiver may result in fatal electric shock and will invalidate your warranty. - Page 26 Specifications (E-311) SYSTEM RESOURCES 594MHz based CPU Main Processor 64 Mbits Flash Memory 1024 Mbits DDR SDRAM Tuner/Front-end(Optional) Tuner Type DVB-S / DVB-S2 Input Connector F-type, Connector, Female Signal Level -65 to -25 dBm LNB Power & Polarization Vertical: +13V Horizontal: +18V Current: Max.
- Page 27 Specifications (E-321) SYSTEM RESOURCES 594MHz based CPU Main Processor 8 Mbyte Flash Memory 128 Mbyte DDR SDRAM Tuner/Front-end(Optional) Tuner Type DVB-S / DVB-S2 Input Connector F-type, Connector, Female Signal Level -65 to -25 dBm LNB Power & Polarization Vertical: +13V Horizontal: +18V Current: Max.
- Page 28 Specifications are subject to change without further notice. The manufacturer does not assume any responsibility regarding any errors or mistakes in printing. Please note that a new software may change the features of the receiver. The manufacturer holds the rights of changes without any further notice.
