CIS VCC-G22V31ACL Product Specification & Operational Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VCC-G22V31ACL
Rev.900-614-34
English
VGA B/W Camera
49MHz Pixel Clock Camera Link
VCC-G22V31ACL
Product Specification
& Operational Manual
CIS Corporation
©2009-2016 CIS Corporation. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VCC-G22V31ACL and is the answer not in the manual?

Questions and answers

Summary of Contents for CIS VCC-G22V31ACL

  • Page 1 VCC-G22V31ACL Rev.900-614-34 English VGA B/W Camera 49MHz Pixel Clock Camera Link VCC-G22V31ACL Product Specification & Operational Manual CIS Corporation ©2009-2016 CIS Corporation. All rights reserved.

  • Page 2: Table Of Contents

    9. Initial Settings ............................. 16 10. CCD Optical Axis Accuracy ........................17 11. Dimensions ............................18 12. Cases for Indemnity (Limited Warranty) ....................19 13. CCD Pixel Defect ..........................20 14. Product Support ..........................20 ©2009-2016 CIS Corporation. All rights reserved.

  • Page 3: Scope Of Application

    VCC-G22V31ACL Rev.900-614-34 1. Scope of Application This is to describe VCC-G22V31ACL Camera Link B/W CCD Camera. All specifications contained herein are subject to change without prior notice. Reproduction in whole or in part is prohibited. 2. Handling Precautions The camera must not be used for any nuclear equipments or aerospace equipments with which mechanical failure or malfunction could result in serious bodily injury or loss of human life.
  • Page 4 The rising time of camera power supply voltage shall be less than +10V, Max 60ms. Please avoid noises like chattering when rising. Voltage Rising Time [ ms ] In case of abnormal operation, contact the distributor from whom you purchased the product. ©2009-2016 CIS Corporation. All rights reserved.

  • Page 5: Product Outline

    Rev.900-614-34 3. Product Outline VCC-G22V31ACL is a high-resolution industrial B/W digital video camera module utilizing a 1/3 type PS IT CCD. 330K CCD image sensor with on-chip micro-lenses realizes high sensitivity and high resolution. At Full Frame Scan Mode, entire pixels can be read out within approx. 1/120s. Interface of G22V31ACL complies with camera link standard.

  • Page 6: Specification

    OFF (1/120), 1/200, 1/240, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/14000, variable range 1/24000, 1/40000, 1/100000s ・Fixed Trigger Shutter Mode ・Pulse Width Trigger Shutter Mode Trigger shutter mode *Trigger pulse width shall be over 1H and less than 1/2s. ©2009-2016 CIS Corporation. All rights reserved.
  • Page 7 Y, and ±Z, 6 directions. (without package) Temperature Operation guaranteed: -5℃～+45℃ Performance guaranteed: 0℃～+40℃ Operation environment RH 20～80% with no condensation Humidity Temperature -25℃ ～ +60℃ Storage environment RH 20～80% with no condensation Humidity ©2009-2016 CIS Corporation. All rights reserved.

  • Page 8: Camera Output Signal Specification

    □ 5 seconds shall be waited after turning on power to get proper camera operation. □ When the camera is started with the trigger mode, input a dummy trigger signal more than three (3) times to stabilize operation of the CCD. ©2009-2016 CIS Corporation. All rights reserved.

  • Page 9: Ccd Spectral Response (Representative Value)

    VCC-G22V31ACL Rev.900-614-34 4.3. CCD Spectral Response (Representative value) ※ Lens characteristics and illuminant characteristics are not considered. ©2009-2016 CIS Corporation. All rights reserved.

  • Page 10: Function Settings

    Shutter Speed = (524.6-Data) x 15.89μs Max Data = 20Ch = 524 Positive Input Trigger Polarity Negative Input 26pin Camera Link connector (12226-1100-00 PL) LVDS Input Trigger Port Select 012 6pin circular connector (HR10-7R-6PA) ©2009-2016 CIS Corporation. All rights reserved.
  • Page 11 Re-triggering at H-Synchronous Mode shall be after 2H of CCD read out signal. Re-triggering at CLK-Synchronous Mode shall be after completion of video output. Trigger pulse width shall be within the range of over 1HD to less than 1/2 sec. ©2009-2016 CIS Corporation. All rights reserved.

  • Page 12: External Connector Pin Assignment

    Do not connect 6.2. 26pins camera Link connector 12226-1100-00 PL (SUMITOMO 3M) Pin No. Pin No. Xclk- Xclk+ SerTC+ SerTC- SerTFG- SerTFG+ CC1- CC1+ (Trigger IN-) (Trigger IN+) CC2+ CC2- CC3- CC3+ CC4+ CC4- (GND) ©2009-2016 CIS Corporation. All rights reserved.

  • Page 13: Timing Chart

    525 H Partial Scan Mode 1 18 H 310 H 345 H Partial Scan Mode 2 23 H 222 H 262 H Partial Scan Mode 3 28 H 124 H 13 H 174 H ©2009-2016 CIS Corporation. All rights reserved.

  • Page 14: Trigger Shutter Mode

    28 H 124 H 13 H 174 H CLK- Synchronous Mode Details at Pulse Width Trigger Shutter Mode Trigger Input Signals Discharge Signals Read OUT Signals Delay Time 2.3µs Delay Time 12.0µs Exposure Time ©2009-2016 CIS Corporation. All rights reserved.

  • Page 15: Remote Interface Function

    (Reboot the camera, and the data is reset to the initial setting.) To save the data into EEPROM, please refer to Clause 5.4. Function Setting. Note: Once the data was saved into EEPROM, it may not be reset to t he initial settings. ©2009-2016 CIS Corporation. All rights reserved.

  • Page 16: Initial Settings

    Manual Shutter Control 009&010 Invalid Trigger Polarity 0: Positive Input Input Trigger Port Select 0: 26 pins Camera Link connector (12226-1100-00 PL) Output Data Select 0:8bit Output Data Trigger Reset Mode 0: H-Synchronous Mode ©2009-2016 CIS Corporation. All rights reserved.

  • Page 17: Ccd Optical Axis Accuracy

    Inclination of effective pixels θ to datum plane shall be The center of effective pixels shall θ≦±0.5° be within Φ0.6 to the center of lens mount. (＊) Dimension from datum plane to the center of lens mount. ©2009-2016 CIS Corporation. All rights reserved.

  • Page 18: Dimensions

    VCC-G22V31ACL Rev.900-614-34 11. Dimensions ©2009-2016 CIS Corporation. All rights reserved.

  • Page 19: Cases For Indemnity (Limited Warranty)

    In case damage or losses are caused by repair or modification conducted by the customer or any unauthorized third party (such as an unauthorized service representative). Expenses we bear on this product shall be limited to the individual price of the product. ©2009-2016 CIS Corporation. All rights reserved.

  • Page 20: Ccd Pixel Defect

    We shall be exempted from taking responsibility and held harmless for damage or malfunction of your hardware and software caused by using this control software. The purpose of this control software is for you to check operation and evaluate our products. Please be noted that CIS does not customize the program nor provide source code.
