- Page 1 STV-692N ADJUSTABLE WALL MOUNTS FOR FLAT SCREENS N Instruction manual...
- Page 2 DESCRIPTION - Adjustable wall mount for flat screens from 37" to 70" (94 to 178 cm). - For installation in corners. - 2 articulated arms. - 60° horizontally adjustable. - ±15° vertical tilt. - Spirit level. - Lock system. - Colour: black. - Maximum borne weight: 60 kg.
- Page 3 1.- FIXING THE MOUNT TO THE WALL 2.- ATTACHING THE SCREEN TO THE MOUNT - 3 -...
- Page 4 2.1.- Back of the flat screen: 2.2.- Back of the curved screen or the screen with inset: - 4 - - 4 -...
- Page 5 5.- ADJUSTMENT OF THE TILT OF THE SCREEN - 5 -...
- Page 6 2 months after being conscious of the problem. It is only necessary to contact FONESTAR if it is impossible or imposes an undue burden for them to solve it. To benefit from this warranty it is necessary to show the proof of purchase with the date clearly visible, with no corrections or crossing out.
