- Page 1 1602011 19” LCD TV/DVD Combo FLC1900 Instruction Manual Read all of the instructions before using this TV and keep the manual in a safe place for future reference.
-
Page 2: Table Of Contents
Contents Important Safety Instructions ......... . . 3-4 What’s Included . -
Page 3: Important Safety Instructions
Important Safety Instructions • Read these instructions. All the safety and operating instructions should be read before this product is operated. • Keep these instructions. The safety and operating instructions should be retained for future reference. • Heed all warnings. All warnings on the appliance and in the operating instructions should be adhered to. • Follow all instructions. All operating and use instructions should be followed. • Do not use this apparatus near water. The appliance should not be used near water or moisture, for example, in a wet basement or near a swimming pool. • Clean only with dry cloth. • Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. • Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. • Do not defeat the safety purpose of the polarized or grounding plug. A polarized plug has two blades with one wider than the other. A grounding plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. • Protect the power cord from being walked on or pinched particularly at the plugs, convenience receptacles, and at the point where they exit from the apparatus. • Only use attachments/accessories specified by the manufacturer. • Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart or rack is used, use caution when moving the cart/ apparatus combination to avoid injury from tip-over. • Unplug the apparatus during lightning storms or when unused for long periods of time. • Refer all servicing to qualified personnel. Servicing is required when the apparatus has been damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. - Page 4 Safety Information To ensure reliable and safe operation of this equipment, please read carefully all the instructions in this user guide, especially the safety information below. Electrical safety • The TV set should only be connected to a main power supply with voltage that matches the label at the rear of the product.
-
Page 5: What's Included
What’s Included Unit and Accessories TV Set Remote Control with Batteries FLC1900 User’s Manual Initial Assembly AV connection cable Base Stand Screw (TPW3x12A-HO, 1PC) -
Page 6: Getting Started
Getting Started Front View POWER Button Functions POWER: Turns on/standby SOURCE: Displays the input source menu MENU: Displays the OSD menu, press again to exit the menu CH +/-: Scans through channels VOL +/-: Adjusts the volume... -
Page 7: Tv Terminal Connections
Getting Started Rear View AC power input terminal Headphone Output Antenna input (75 Ohm VHF/UHF) AV input Component input terminal PC AUDIO input VGA input HDMI1/HDMI2 input SERVICE port Wall Mounting The TV is provided with mounting holes for a VESA approved wall mounting bracket (NOT SUPPLIED). -
Page 8: Connecting To External Devices
Connecting to External Devices Connecting external devices to your LED TV Note: YPBPR and VIDEO share with audio in R/L. -
Page 9: Remote Control Key Functions
Remote Control Key Functions Mute button Power button Numeric buttons Channel setup/DVD 10+ button Return channel/DVD subtitle Sound mode button MTS button Sleep button Picture mode button Signal source selection button Information button Channel selection buttons Volume adjust buttons CH. LIST button Auto button FREEZE/TITLE button Aspect button... - Page 10 Remote Control Key Functions POWER: Power on/off button, press once to turn TV on and press again to turn TV off. P.MODE: Sets the picture mode. S.MODE: Sets the sound mode. MTS: Press to select the audio channel. • Make sure the TV has searched the channels and that there is a Analog Stereo/Dual Sound Signal shown on the program.
- Page 11 Remote Control Key Functions DVD Functions Press OPEN/CLOSE with power on, with the disc label facing the back. Press OPEN/ CLOSE again to close. When playing the disc, press PLAY/PAUSE once to pause, press PLAY/PAUSE again to return to normal play. When playing DVD, SVCD, VCD, CD, press STOP once, the unit will memorize the previous ending point.
-
Page 12: Operating Your Television
Operating Your Television Basic Operations Turning Your TV On and Off TURN ON LCD TV 1. Connect to power with the main power cable, the TV will enter STANDBY mode and the LED indicator light will be red. 2. From STANDBY mode, use the POWER button either on the main unit or on the remote to turn the television on. -
Page 13: Select Your Onscreen Language Preference
Operating Your Television Note: If you wish to change between Home Mode (energy saving) and Standard Mode later, this can be changed under the Display mode in the Setup menu. Natural Resources Canada’s (NRCan’s) Office of Energy Efficiency (OEE) promotes the international Energy Star®... -
Page 14: Navigating The Onscreen Display
Operating Your Television Navigating the On Screen Display • Press the MENU button to display the main menu. f / g • Use buttons to navigate and select the available menus. Display Mode Standard Mode Choosing a TV Channel CH+/CH- 1. -
Page 15: Selecting Input Source
Operating Your Television Selecting Input Source SOURCE You can display the input screen menu by pressing on the SOURCE on the top panel. Press e d button to remote control or select your choice, then press “ ” to confirm. Picture Menu Options MENU Press... -
Page 16: Audio Menu Options
Operating Your Television Audio Menu Options f / g MENU Press on the top panel or the remote control, then use AUDIO menu. Press d or select the to enter (see picture). Sound Mode f / g Press e d then use to select User, Standard, Music and Movie. -
Page 17: Setup Menu Options
Operating Your Television Setup Menu Options f / g MENU to select the Setup menu. Press d or Press on the top panel or the remote control, then use to enter (see picture). Menu Language Press then use to select menu language for either English, French or Spanish. -
Page 18: Lock Menu Options
Operating Your Television Lock Menu Options f / g MENU Press on the top panel or the remote control, then use to select the LOCK menu and press d or OK to enter. Use the d button to enter the “Enter Password” selection and use the numeric buttons to input a 4-digit password. -
Page 19: Channel Menu Options
Operating Your Television Channel Menu Options f / g MENU Press on the top panel or remote control, then use to select the CHANNEL menu and press d or OK to enter (see picture). Air Cable Allows you to select the input signal between Air and Cable. If you select “Air”... -
Page 20: Parental Menu Options
Parental Menu Options Parental Control Press Enter to enter the sub-menu and then use the numeric keypad to enter the correct password: 0,0,0,0. If used, this option feature can “block” undesirable programming from appearing on the TV. Parental Control offers the user a wide variety of options and settings that restrict or “block”... -
Page 21: Dvd Operation
DVD Operation Basic Operation 1. Turn ON and OFF the DVD function Turn on the LCD TV and then press SOURCE repeatedly to select DVD mode. 2. Insert disc to DVD OPEN READ Insert the disc automatically. The onscreen message will indicate “ ”... - Page 22 DVD Operation Supporting DVD format This product can play the following DVD disc formats. Disc Type Disc Size Recorded Time Recorded Content Remarks (Diameter) 12 cm Single side: DVD format: 120 mins. Approx Compressed digital Double side: audio and video 240 mins.
-
Page 23: Dvd Functions
DVD Functions DVD Remote Functions 1. Play (for DVD/ Super VCD/VCD/CD/CD-G/HD-CD and MP3/JPEG discs) For DVD disc, press the II button from root or title menu. While playing the DVD, play a favorite title directly with title selection TITLE by pressing the button. -
Page 24: Dvd Remote Functions
DVD Functions DVD Remote Functions For DVD discs with 2 pages, press INFO button once to display the first page as shown below: Disc Type Chapter -/- (Current/Full) Elapsed disc time Title -/- (Current/Full) Press the INFO button again to display the second page shown below: Audio Language -/- (Current/Full) -
Page 25: Mp3/Jpeg Playback
DVD Functions DVD Remote Functions 9. Mute (for DVD/Super VCD/VCD/CD/CD-G/HD-CD and MP3/JPEG discs) Press MUTE button to mute the audio output, there will be an onscreen symbol to indicate “MUTE”. Press again to cancel, or press VOL+/VOL- to cancel and adjust the volume. In case there is no audio output, press MUTE button to cancel mute. -
Page 26: Function Settings
DVD Functions Function Settings DVD Function General Set Up DVD SETUP - Press button to activate the DVD player’s OSD menu. - Press the button to move and highlight between different sub-menu. Press the OK button to enter the highlighted sub-menu. - Page 27 DVD Functions Function Settings DVD Function General Set Up - Press DVD SETUP button to activate the DVD player’s OSD menu. - Press the / button to move and highlight between different sub-menu. Press the OK button to enter the highlighted sub-menu. - Press DVD SETUP button to exit the OSD menu.
-
Page 28: Language Setup
DVD Functions Function Settings DVD Function General Set Up NOTE: Only editable when password is unlocked, and can only function when the password is locked. It does not, however, reset either the Password or the Rating setting. Default Setting Press OK button to restore factory default. Press the OK button to confirm. Language Setup SETUP DVD OSD... - Page 29 DVD Functions Function Settings DVD Function General Set Up NOTE: If the selected language is not included in your DVD disc content, it will select the default language of the disc automatically. The default language setting is English. MENU Language Use the navigation buttons to select the MENU LANG set up, press OK button to confirm.
-
Page 30: Dolby Digital Setup
DVD Functions Function Settings Dolby Digital Setup Dynamic Range Moving the dynamic range switch changes the compression of the audio output signal. The lower the compression, the louder the volume will be. Dual Mono You can select 4 different audio output: STEREO, MONO L, MONO R, MIX MONO. -
Page 31: Troubleshooting
Troubleshooting If your television does not operate normally or does not turn on, please check the following troubleshooting questions. Remember to also check the other connected electronic devices, such as DVDs or Blu-ray players to pinpoint any problem. If the television still fails to operate normally, please contact Customer Service (refer to Warranty page). - Page 32 Troubleshooting Before contacting the service technician, perform the following simple checks. If any problems still persists, unplug the LED TV and call for assistance. PROBLEM POSSIBLE SOLUTION No sound and picture - Check that the main plug has been connected to a wall outlet - Check that you have pressed the POWER button on the front of the TV set...
- Page 33 Troubleshooting NOTE : When there is a problem in VGA mode (only when VGA mode is applied) PROBLEM POSSIBLE SOLUTION The signal is out of range - Adjust resolution, horizontal frequency, or vertical frequency - Check whether the signal cable is connected or loose - Check the input source Vertical bar or stripe on background, horizontal noise and Set the auto configure or adjust clock, phase or H/V...
-
Page 34: Specifications
Specifications Panel Size 19 inches diagonally Display Type Panel Technology Panel 60 Hz vs 120 Hz 60 Hz Display Resolution 720P HD Compatible up to 1080p Panel Resolution 1366 x 768 TV Demodulator AIR/CABLE/QAM Aspect Ratio 16:9 Contrast Ratio - panel 800:1 Brightness (Centre Typ.) cd/m2 Response Time (G to G) -
Page 35: Warranty
