SYNTEK BLUEW-2310 miniCard User Manual

Wifi 802.11 b/g and bluetooth v2.0 + edr combo module
Hide thumbs Also See for BLUEW-2310 miniCard:
Table of Contents

Advertisement

Quick Links

Download this manual
太 欣 半 導 體 股 份 有 限 公 司
BlueW-2310
User's Manual
SYNTEK Semiconductor Co., Ltd.
BlueW_2310 miniCard
WiFi 802.11 b/g and Bluetooth v2.0 + EDR
Combo Module
User's Manual
Version 1.1
太 欣 半 導 體 股 份 有 限 公 司
1/44

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BLUEW-2310 miniCard and is the answer not in the manual?

Questions and answers

Related Manuals for SYNTEK BLUEW-2310 miniCard

Summary of Contents for SYNTEK BLUEW-2310 miniCard

  • Page 1 太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. BlueW_2310 miniCard WiFi 802.11 b/g and Bluetooth v2.0 + EDR Combo Module User’s Manual Version 1.1 太 欣 半 導 體 股 份 有 限 公 司...
  • Page 2 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 3 • At least 50 MB of available free hard disk space for installing the drive • An IEEE 802.11b, or IEEE 802.11g Access Point (for Infrastructure Mode) or another Wireless Adapter (for Ad-Hoc Mode). Also, the BlueW-2310 miniCard can compatible with most 802.11n AP router.

  • Page 4: Table Of Contents

    太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. Contents Introduction......................5 Product Features.....................6 Install the Drivers and Utilities ................7 Wireless Configuration ..................19 4.1 Configuring Your Wireless Network with Windows XP ......19 4.2 Single Access Point Network...............21...

  • Page 5: Introduction

    Integrated on-chip power amplifier and LNA reduce external component count, while still able to deliver ample transmit power for most applications. Different from any other wireless LAN and Bluetooth chip set vendor, SYNTEK and 3DSP uses its patented Software Radio technology to implement both wireless LAN and Bluetooth in software.

  • Page 6: Product Features

    太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. 2. Product Features [WiFi] Data Rate up to 54Mbps. Single-band 2.4-GHz 802.11b/g with Bluetooth v2.0 + EDR RF IC integrated on-chip PA capable of delivering 20dBm output power...

  • Page 7: Install The Drivers And Utilities

    太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. 3. Install the Drivers and Utilities 1. Insert the Installation Software CD into CD-ROM drive. If the Auto-Run function of CD-ROM is disabled, you can utilize the Windows Explorer to browse CD content and run Setup.exe manually.
  • Page 8 太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. 3. Please click Next button several times to continue the software installation. In the License Agreement window, please read license agreement carefully. Select “I accept the terms in the license agreement”...
  • Page 9 太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. 4. Select you want to place the program shortcut, and indicate the location of where you want Bluetooth Software to be stored; if you do not change the default settings, it will be stored under C:\Program Files\IVT Corporation\BlueSoleil (Recommended).
  • Page 10 太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. 5. The Install Shield Wizard will begin to install the software and copy files to your hard disk. After copy all the files, the installation will try to install virtual Bluetooth device in your system.
  • Page 11 太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. 6. After finish installation the IVT Bluesoleil, then the install system will continue install. If your system is not install the WPA2 hotfix yet. The install program will ask you install it first.
  • Page 12 太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. 7. Continue install the 3DSP WLAN driver will be stored under C:\Program Files\3DSP\BluetoothWLAN_usb\. Click the “Next” for continue. 8. The Install Shield Wizard will begin to install the software and copy files to your hard disk.
  • Page 13 太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. 9. After finish installation, please select reboot your system to finish the installation. Or you can select to reboot later. 13/44...
  • Page 14 User’s Manual SYNTEK Semiconductor Co., Ltd. 10. Please plug the BlueW-2310 miniCard MiniCard Module in your Notebook MiniCard slot. After a few seconds, another “Found New Hardware” message will appear briefly, as shown on the fallowing pictures. The system will prompt installation.
  • Page 15 太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. 11. The system will prompt now installation the driver for the wireless MiniCard, select continue installation. Because the system will installation both WiFi and Bluetooth.
  • Page 16 太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. 16/44...
  • Page 17 太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. 12. There are two new Bluetooth icons appear on the desktop and the windows task bar respectively when logged in Windows operating system. For more information on the BlueSoleil, please refer to Chapter 2.
  • Page 18 太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. Please remove the Software CD after the installation is complete. A Bluetooth icon will appear in your system tray Click Finish to close the wizard.

  • Page 19: Wireless Configuration

    Configuring Your Wireless Network with Windows XP The Windows XP SP2 operating system has the “Wireless Zero Configuration” feature, which can be used to configure and control the BlueW-2310 miniCard 802.11b/g and Bluetooth v2.0 + EDR Combo MiniCard Module. Wireless Zero Configuration is most appropriately used in home and small office networks and in ad hoc networks.
  • Page 20 太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. Follow these steps to start Wireless Zero Configuration: services.msc 1. From the Start menu, select Run. Enter 2. Scroll down to Wireless Zero Configuration Service. Double-click on it to open the settings box.

  • Page 21: Single Access Point Network

    太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. Single Access Point Network In a small environment, you can set up a wireless network using a single Access Point and one or more Wireless MiniCard. This type of network provides a coverage area sufficient to satisfy the network requirements for many homes and small businesses.

  • Page 22: Multiple Access Point Network

    太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. Multiple Access Point Network In a large environment, you can set up a wireless network using multiple Access Points and thereby create a large coverage area. In such a network, computers with Wireless MiniCard that “roam”...

  • Page 23: Setting Up A Peer-To-Peer Network

    太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. Setting Up a Peer-to-Peer Network A Peer-to-Peer Network consists of two or more notebook or desktop computers with Wireless MiniCard that communicates directly to each other without the use of an Access Point.

  • Page 24: Wireless Performance Considerations

    太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. WiFi device in your Peer-to-Peer Group (802.11b and 802.11g). 4. Establish the Privacy settings that all the computers in the network will be using.

  • Page 25: Wifi Security Considerations

    You cannot configure a profile using WPA and expect to communicate with an Access Point using WEP. For those who want an effective security feature, the BlueW-2310 miniCard 802.11b/g and Bluetooth v2.0 + EDR Combo MiniCard support the Wired Equivalent Privacy (WEP) security standard.

  • Page 26: Bluetooth Configuration And Utilities

    太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. 5. Bluetooth Configuration and Utilities Start the Bluetooth Device Start the Bluetooth service for ready to service. 1. After you install the MiniCard, the system tray Icon will become available.

  • Page 27: Manual Configuration Bluetooth Dongle

    太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. Manual Configuration Bluetooth Dongle If the IVT BlueSoleil can not identify the MiniCard Bluetooth services, there you can manually configuration the IVT BlueSoleil.
  • Page 28 太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. b. Start the IVT BlueSoleil, the go to [Tool] => [My Bluetooth Device]. c. Set as UART device, and then go to the advance setup page.
  • Page 29 太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. d. Configuration as the fallowing picture setting. Setup the [COM Port] [Transmit speed] [Data Bit] [Parity Check] [Stop bit] [Fallow control]. As COM Port = X that reference from the device management information.

  • Page 30: Start Bluetooth

    太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. Start Bluetooth Start BlueSoleil. (Double click the IVT Bluesoleil icon or in the Start Menu) Establish Bluetooth Connection A connection is normally initiated from the client.

  • Page 31: Stop The Bluetooth Device

    太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. 3. Connect. Single-click the highlighted service button to establish the connection 4. If the other device needs pair, the Bluetooth Icon in the system tray will show a warning massage that the Bluetooth connection need input pair numbers.
  • Page 32 太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. Figure 1-26: The Bluetooth Device is not available. 32/44...

  • Page 33: Dsp Combo Usb Dongle Configuration

    太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. 6. 3DSP Combo USB Dongle Configuration. Right-Click on the green three-bar icon in the system tray, a pop-up list that displays several options will appear. (Recommended) Click Coexist to use both utilities simultaneously.

  • Page 34: Remove Driver

    太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. 7. Remove Driver If you want to remove the wireless Combo card driver, please read this chapter for introduction. 7.1 Go to Windows Control Panel, select and start “Add or remove programs”...
  • Page 35 太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. 7.3 System will ask you again for sure you want to remove it. Click “Continue” for remove the program. 7.4 Finish removes the program. Please fallow the same method to remove the...
  • Page 36 太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. IVT BlueSoleil for clean your system. 36/44...

  • Page 37: Troubleshooting

    This section provides solutions to problems that may occur when trying to use the BlueW-2310 miniCard 802.11b/g and Bluetooth v2.0 + EDR Combo MiniCard. Q1. The computer does not recognize the BlueW-2310 miniCard 802.11b/g and Bluetooth v2.0 + EDR Combo MiniCard.
  • Page 38 太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. A3. Any wireless adapter will shorten your battery’s life to some extent. Heavy network activity (Transmitting and receiving lots of data) will drain your battery much more than if the MiniCard is in idle mode.
  • Page 39 太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. exists after uninstallation. A6. If you use v2.2’s 3DSP Wireless LAN uninstallation shortcut or running setup.exe to uninstall and your machine has the previous released v2.1CD installed, a wlancfgdlg.ico and its 3DSP folder will exist after uninstallation.
  • Page 40 太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. Q9. Why I can’t hear any sound from my Bluetooth Headset or Bluetooth Speaker? 1. Please connect the Bluetooth Headset, after connect. The Headset icon will change to Green and there is a small "stop"...
  • Page 41 太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. 5. If it still can’t works, please tell us witch AP router Brand and module you are use. We will check it out ASAP.

  • Page 42: Specifications

    太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. 9. Specifications WLAN Spec IEEE 802.11b/g Transmit Power 13 dBm to 17 dBm Sensitivity -74dBm@54Mbps, -85dBm@11Mbps Frequency Channel Modulation 802.11g: OFDM / 802.11b: DSSS...

  • Page 43: Contact Information

    太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. 10. Contact Information SYNTEK Semiconductor Co., Ltd. Taipei Office: 10F, No.1, Alley 30, Lane 358, Rui-Guang Road, Neihu, Taipei Taiwan R.O.C. 114...
  • Page 44 太 欣 半 導 體 股 份 有 限 公 司 BlueW-2310 User’s Manual SYNTEK Semiconductor Co., Ltd. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help.
