Cable Drum Machine
Operation Manual
ST-420, ST-440, ST-440W
Used For: Sinks, Tubs, Floor Drains and Roof Stacks
(Not for roots)
READ THIS OPERATION MANUAL CAREFULLY
BEFORE USING THIS PRODUCT. FAILURE TO UNDERSTAND
AND FOLLOW THE CONTENTS OF THIS MANUAL MAY
RESULT IN ELECTRICAL SHOCK, FIRE, AND/OR SERIOUS
PERSONAL INJURY OR DEATH. KEEP THESE INSTR UCTIONS
IN A SAFE PLACE FOR FUTURE USE OR WHEN LOANING OR
SELLING THE PRODUCT.
Advertisement
Table of Contents
Summary of Contents for Speedway ST-420
- Page 1 Cable Drum Machine Operation Manual ST-420, ST-440, ST-440W Used For: Sinks, Tubs, Floor Drains and Roof Stacks (Not for roots) READ THIS OPERATION MANUAL CAREFULLY BEFORE USING THIS PRODUCT. FAILURE TO UNDERSTAND AND FOLLOW THE CONTENTS OF THIS MANUAL MAY RESULT IN ELECTRICAL SHOCK, FIRE, AND/OR SERIOUS PERSONAL INJURY OR DEATH.
- Page 2 SAFETY SYMBOLS & CABLE DRUM MACHINE SIGNAL WORD SAFETY In this Operation Manual and on the product, safety Read all safety warnings and instructions. symbols and signal words are used to communicate important safety information. This section is provided to Acquaint yourself with the functions and controls prior improve understanding of these signal words and symbols.
-
Page 3: Work Area Safety
• Prevent unintentional starting. Ensure the switch WARNING indicates a hazardous is in the off-position before connecting to power situation that, if not avoided, could result in death or source and/or battery pack, picking up or carrying serious injury. the tool. Carrying power tools with your finger on the Save all warnings and instructions for future reference. -
Page 4: Tool Description
Tool Description • Disconnect the plug from the power source and/or the battery pack from the power tool before making Your cable drum machine has four benefi cial tool any adjustments, changing accessories, or storing attachments to cope with a wide variety of obstructions. As power tools. -
Page 5: Preparation For Operation
PREPARATION FOR OPERATION Determine the best access point to the drain and the size of the drain. If possible, determine the distance Do not operate a machine that has the belt guard to the blockage or the nature of the clog. If necessary, removed, any absent or broken parts, or that is remove the fixture (water closet, sink, etc.) to allow inadequately assembled. - Page 6 • Confirm that the FOR/OFF/REV switch is in the OFF against an elbow or joint in the pipe or may have position. Using dry hands, plug the cord into a correctly reached the clog. grounded outlet. To test the GFCI provided, push the test button in, the indicator light should go off.
-
Page 7: Machine Maintenance
Storage back into the drum, cleaning in cold water then oiling the cable as you go. It is recommended that the cable • Make sure all water and residue is removed from the is continuously flushed through with clean water and drum prior to storage. -
Page 8: Installing Replacement Cable
Replacing Belt Guard/Belt Installation REPAIRING YOUR DRUM 1. Remove wing nuts on the belt guard MACHINE (pulley wheel cover) and remove the belt guard. (See figure 6) 2. Slide the belt under and over the drum and onto the pulley wheel. General maintenance and other tasks detailed in this manual, such as the replacement of the cable or a figure 6... - Page 9 Manufacturer assumes no responsibility for failure due to improper use. ©2019 Brasscraft Manufacturing Company, Novi, MI 48375-5331 U.S.A. All Rights Reserved. www.brasscraftmfgco.com Made in China to Brasscraft Mfg. Co. specifications. Speedway brand is a trademark of Brasscraft Mfg. Co. ®...
