- Page 1 OD662200TX Pair - Catania Outdoor Deep Seating Armchairs For assistance with assembly contact: Assembly Instructions Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com www.seidal.com Page 1...
- Page 2 OD662200TX - Pair - Catania Outdoor Deep Seating Armchairs Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Screws shown in actual size. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw.
- Page 3 OD662200TX - Pair - Catania Outdoor Deep Seating Armchairs Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Screws shown in actual size. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw.
- Page 4 OD662200TX - Pair - Catania Outdoor Deep Seating Armchairs Assembly Instructions Figure 1 Attach the Left Leg Frame (A) and Right Leg Frame (B) into Seat Frame (C) and insert the Wooden Dowel (2) and Cross Nut (3) into Seat Frame (C) then using the Long F-Screw 7x70 (4) to tighten Attch Back Fram (D) to Leg Frames and insert Wooden Dowel (2) then using Short F- Screw 7x60 (1) to tighten.
- Page 5 Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
- Page 6 OD662100TX Catania Outdoor Deep Seating Sofa Assembly Instructions For assistance with assembly contact: Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com www.seidal.com Page 1...
- Page 7 OD662100TX - Catania Outdoor Deep Seating Sofa Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Screws shown in actual size. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw.
- Page 8 OD662100TX - Catania Outdoor Deep Seating Sofa Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Screws shown in actual size. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw.
- Page 9 OD662100TX - Catania Outdoor Deep Seating Sofa Assembly Instructions Figure 1 Attach the Right Leg Frame (A) and Left Leg Frame (B) into Seat Frame (C) and insert the Wooden Dowel (2) and Cross Nut (3) into Seat Frame (C) then using the Long F-Screw 7x70 (4) to tighten Attch Back Fram (D) to Leg Frames and insert Wooden Dowel (2) then using Short F- Screw 7x60 (1) to tighten.
- Page 10 Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
