Summary of Contents for Corinex 1T
- Page 1 Corinex Installation Guide Corinex 1T External Modem CXP-HD200-GH1T Version 2.0 | May, 2022...
- Page 2 COPYRIGHT The content of this document is furnished for informational use only, it is subject to change without notice, and it does not represent a commitment on the part of Corinex Communica- tions Corp. Corinex Communications Corp. assumes no responsibility or liability for any errors or inac- curacies that may appear in this document.
-
Page 3: Table Of Contents
Included in the delivery of the CXP-HD200-GH1T ......... 3 Hardware ....................3 Installation ......................3 Status LEDs ......................4 Connectors ......................7 Software and Initial Setup ................7 Commissioning ..................7 Installation ......................7 Powering up the device ..................8 BPL Coupling ....................... 9 Corinex 1T External Modem CXP-HD200-GH1T... - Page 4 Figure 1: CXP-HD200-GH1T Mounting ................4 Figure 2: CXP-HD200-GH1T LEDs ................... 4 Figure 3: CXP-HD200-GH1T connectors ................ 7 Figure 4: CXP-HD200-GH1T Ethernet cable connection ..........8 Figure 5: CXP-HD200-GH1T Coupling cable connection ........... 9 Figure 6: CXP-HD200-GH1T Cover Installation ............10 Corinex 1T External Modem CXP-HD200-GH1T...
-
Page 5: General Information
Transport Security Model User Based Security Model General Information This document is a general description and installation guide for the following device: • Corinex 1T External Modem (CXP-HD200-GH1T) Included in the delivery of the CXP-HD200-GH1T • Corinex 1T External Modem (CXP-HD200-GH1T) Hardware... -
Page 6: Status Leds
Figure 1: CXP-HD200-GH1T Mounting Status LEDs CXP-HD200-GH1T has 4 LEDs showing its operational status. All of them are clearly marked on the casing. Figure 2: CXP-HD200-GH1T LEDs Corinex 1T External Modem CXP-HD200-GH1T... - Page 7 SMGW authen- down tication failed BPL Link Function: Shows the status of BPL link Different statuses are given below: LED Status Fast flashes Slow flashes Function BPL link estab- No BPL link BPL link activity lished Corinex 1T External Modem CXP-HD200-GH1T...
- Page 8 System Status successful TSM: Persistent TSM: Persistent TLS link estab- TLS link not es- TSM: Establish- lished. tablished yet. ing TLS link Corinex 1T External Modem CXP-HD200-GH1T...
-
Page 9: Connectors
Figure 3: CXP-HD200-GH1T connectors Software and Initial Setup After bootup, CXP-HD200-GH1T starts with some default settings. To change its settings, au- to-configuration mechanism can be used which involves provisioning using the Corinex Grid- Value Software system. Commissioning Installation Mount the device using the DIN rail. Refer section 2.1 for more details. -
Page 10: Powering Up The Device
Powering up the device CXP-HD200-GH1T gets its power using ethernet cable. Connect the ethernet cable to the SMGW ethernet port as shown below: Figure 4: CXP-HD200-GH1T Ethernet cable connection Corinex 1T External Modem CXP-HD200-GH1T... -
Page 11: Bpl Coupling
CXP-HD200-GH1T has an internal single-phase BPL coupler. The coupling cable is to be con- nected to the same ports from where SMGW is getting power as shown in below picture. Figure 5: CXP-HD200-GH1T coupling cable connection Corinex 1T External Modem CXP-HD200-GH1T... -
Page 12: Figure 6: Cxp-Hd200-Gh1T Cover Installation
Cover Installation After completing the ethernet cable & coupling cable installation, install both covers and tight- en the screws. Final setup should look like below. The screws are marked by green hexagons. Figure 6: CXP-HD200-GH1T installation Corinex 1T External Modem CXP-HD200-GH1T...
