DANLERS HASE 1RF Installation Notes

Troubleshooting
Radio receiver switch does not respond to sender:
• Ensure the sender is correctly associated to the radio receiver.
• The sender is too far away or RF absorbed by building or trees.
Move sender closer to receiver or consider using a repeater.
• The sender battery is flat (average life approx. 5 years).
Change battery, see 'changing batteries' section.
• DANLERS hand senders are only compatible with DANLERS radio
receiver switches and dimmers.
Load and receiver LED flash twice every time the sender is pressed:
• Ensure the radio receiver switch is not in programming mode.
Radio receiver switch relay clicks but load does not switch on / off:
• The load or in-rush current is too large and has damaged receiver.
Use a contactor to switch over limit loads.
Radio receiver dimmer stops working:
• The load or in-rush current is too large and has damaged receiver.
Ensure halogen lamps include a thermal safety fuse
Precautions and Warranty
This product conforms to BS EN 60669-2-1.
Please ensure the most recent edition of the appropriate local wiring regulations are observed
and suitable protection is provided e.g. 6 amps over current, 1kV over voltage. Please ensure
that this device is disconnected from the supply if an insulation test is made.
This product is covered by a warranty which extends to 5 years from the date of manufacture.
Also available from DANLERS
• PIR occupancy switches • Daylight linked dimmers • Manual high frequency dimmers
• Photocells • Radio remote controls • Time lag switches • Outdoor security switches
• Dimmers • Heating, ventilation and air-conditioning controls • Bespoke / O.E.M. products
Please call for more information or a free catalogue, or visit our website.
DANLERS Limited, Vincients Road, CHIPPENHAM, Wiltshire, SN14 6NQ, UK.
Telephone: +44 (0)1249 443377 Fax: +44 (0)1249 443388
E-mail: sales@danlers.co.uk Web: www.danlers.co.uk
Company Registered Number 2570169 VAT Registration Number 543 5491 38
26/01/11
.
INS965 HASE
Radio remote control hand senders
HASE 1RF HASE 2RF
DANLERS radio remote control hand senders are used to control
DANLERS radio receiver switches and receiver dimmers, details of
the full range of receivers are in the DANLERS product catalogue and
on the DANLERS web site.
The hand senders incorporate either 1, 2 or 12 channels as identified
by the appropriate product code number. The 12 channel hand sender
has 6 pre-selector buttons with the switching and/or dimming controlled
by the 2 pairs of larger buttons. The left hand pair serves channels
1-6, the right hand pair serves channels 7-12. For more details see
diagrams overleaf.
A quick up press will switch on a receiver switch or receiver dimmer
and a holding up press will dim a receiver dimmer up. A quick down
press will switch off a receiver switch or receiver dimmer and a holding
down press will dim down a receiver dimmer.
Each button pair uses a unique code to identify it to the radio receiver.
Each radio receiver can be programmed to respond to up to 15 different
codes. This is done by the installer by following the installation notes
supplied with the receiver switch or dimmer.
RF range reduction
The radio remote control hand senders can transmit up to 100m in free-
air. This distance is reduced by the following obstacles as shown:
Approximate transmission distance reduction from 100m:
Brick wall 10-50m
Partition wall 5-20m
Glass sheet 10-30m
Vaporised metal coated glass
The distance will be further reduced by multiple obstacles or particularly
thick or damp obstacles, such as the walls of an old property.
Installation notes
HASE 12RF
Metal reinforced wall 40-80m
Metalised wall 90-100m
Plastic sheet 5-20m
40-70m
