Page 2
FG-BD100 Technical Specification Part Number FG-BD100 Standard Listed LPCB/CE-CPR Compliance EN 54-12:2015 Fire Detection and Alarm Systems BS 5839 Part 1:2017 Specification Operating Voltage 20 V to 28 V DC Current Parameters Standby: 23mA Commission: 56mA Alarm: 33mA Beam Sensor Sensitivity [via Encoder] Level 1: 2.6 dB High Sensitivity...
Page 4
FG-BD100 Connection Details Terminal D1 (+) and D2 (-) for connecting Power supply [24VDC] Terminal S1 and S2 for connecting handheld programmer when setting parameters, and then connecting to terminal D1 and D2 respectively when finishing config Terminal HJ1 and HJ2 for connecting Fire signal relay...
Page 5
( ) FG-BD100 Programming Devices By DIP Switch As shown in the figure of the shell base. Use DIP switch(SW2) to set the parameter set you want (see table on the right). Note:①“1” means to Enable/Disable;if you want adjust parameter by DIP Switch,you should turn “1”...
Page 6
( ) FG-BD100 Programming Devices By Handheld Connect the programming cable to S1 and S2 terminals Note: The "1" of the DIP switch must not be in the "ON" state, otherwise it will not code properly. TX7932 1. Read View Program 2.
Page 7
FG-BD100 Troubleshooting Guide Trouble Comment Troubleshooting Advice Indicates Faults after wire Wrong connection; Check wring,make sure that S1 connection and S2 are connected to D1 and D2 respectively. Indicates Faults after The detector is Dirty; Conduct maintenance commissioning The line of sight between detector and Re-Commission the detector mirror was moved;...
