HS-NH8100
8 Port 10/100Mbps
Fast Ethernet Switch
For Use with Concourse Home Wiring System
Installation & User Guide
WARNING: This manual contains information on
limitations regarding product use and function
and information on the limitations as to liability of
the manufacturer. Read the entire manual care-
fully
firealarmresources.com
Advertisement
Table of Contents
Related Manuals for DSC HS-NH8100
Summary of Contents for DSC HS-NH8100
- Page 1 HS-NH8100 8 Port 10/100Mbps Fast Ethernet Switch For Use with Concourse Home Wiring System Installation & User Guide WARNING: This manual contains information on limitations regarding product use and function and information on the limitations as to liability of the manufacturer. Read the entire manual care- fully firealarmresources.com...
-
Page 2: Table Of Contents
4.0 Connecting the HS-NH8100 ........... 4 4.1 HS-NH8100 to a Networkable PC ......... 4 4.2 HS-NH8100 to a Hub with an Uplink (MDI-II) Port..... 4 4.3 HS-NH8100 to a Hub without Uplink (MDI-II) Port .... 5 4.4 HS-NH8100 to Other Devices (switches, routers) ....5 4.5 Port Speed &... -
Page 3: Introduction
Installation in a Concourse Home Wiring System cabinet requires optional mounting bracket, HS-HUB100-BRKT. When used with Concourse module HS-DH800, an 8-channel data patch panel, installing the HS-NH8100 as part of your home network is as simple as running patch cords from one to the other. 1.1 Features... -
Page 4: Unpacking And Installation
2.0 U NPACKING AND NSTALLATION This section provides unpacking and installation information. 2.1 Unpacking Open the shipping cartons of the HS-NH8100 and carefully unpack the contents. The carton should contain: • One HS-NH8100 8-port 10/100M Fast Ethernet Switch • One external power adapter •... -
Page 5: Rear Panel
Use this jack to connect additional hubs/switches or network connections. This jack is an MDI-II (Medium-dependent Interface, straight-wired), allowing you to connect the HS-NH8100 to another device with a MDI-X port using an ordinary straight-through cable, making a crossover cable unnecessary. -
Page 6: Connecting The Hs-Nh8100
4-2 HS-NH8100 to a Hub with an Uplink (MDI-II) Port Using a CAT5 UTP straight-through cable, connect any of the eight MDI-X port (1x - 8x) on the HS-NH8100 to the uplink (MDI-II) port on the 10BASE-T or 100BASE-TX hub. -
Page 7: Hs-Nh8100 To A Hub Without Uplink (Mdi-Ii) Port
Using a CAT5 UTP crossover cable, connect any (MDI-X) port on the HS- NH8100 to any port on the hub. 4-4 HS-NH8100 to Other Devices (switches, routers) The HS-NH8100 may be connected to another switch or other devices such as routers or bridges using a CAT5 UTP straight-through or crossover cable. •... -
Page 8: Port Speed & Duplex Mode
4-6 Using the HS-DH800 with the HS-NH8100 The HS-NH8100 may be installed as part of a network using the HS-DH800 8- channel patch panel using CAT5 UTP patch cords. Note: The connections for the devices described above apply when using the HS-DH800. -
Page 9: Appendix A - Technical Specifications
Appendix A - Technical Specifications A - T PPENDIX ECHNICAL PECIFICATIONS General Standards IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet ANSI/IEEE Std. 802.3 NWay Auto-negotiation Protocol CSMA/CD Data Transfer Ethernet: 10Mbps Rate Fast Ethernet: 100Mbps Topology Star Network Cables 10BASET: CAT5 UTP (100 m), EIA/TIA- 568 100-ohm STP (100 100BASE-TX: CAT5 UTP (100 m), EIA/TIA-568 100-ohm STP (100 m) -
Page 10: Appendix B - Rj-45 Pin Specification
B - RJ-45 P PPENDIX PECIFICATION When connecting your HS-NH8100 8-port 10/100M Fast Ethernet Switch to another switch, a bridge or a hub, a CAT5 crossover cable may be necessary depending on your connection choice (as described earlier). Please check the Installation Instructions included with these products for matching cable pin assignments. - Page 11 Warranty Digital Security Controls Ltd. warrants that for a period of 12 months from the date of purchase, the product shall be free of defects in materials and workmanship under normal use and that in fulfillment of any breach of such war- ranty, Digital Security Controls Ltd.
- Page 12 Home Systems is a division of Digital Security Controls Ltd. 2001 Digital Security Controls Ltd. Toronto, Canada 1-800-387-3630 • www.dsc.com Printed in Canada 29034471 R001 firealarmresources.com...
