Summary of Contents for racknex zr-msk Series
- Page 1 Assembly instructions Rack Mount Bracket zr-msk- _ _ _ The smart difference.
- Page 2 1. Pre-assemble the Rack Mount Bracket Fasten the chassis parts using the rackmount screws (included in the scope of supply). 2. Fasten the Rack Mount Brackets Aline the Rack Mount Kit in the desired position (furniture, wall, etc.) and secure it carefully with the appropriate mounting hardware (NOT included in the scope of supply).
- Page 3 Hole spacing: zr-msk-001 | width 470mm x depth 175mm zr-msk-002 | width 470mm x depth 175mm zr-msk-003 | width 470mm x depth 175mm zr-msk-004 | width 470mm x depth 175mm zr-msk-005 | width 470mm x depth 175mm zr-msk-011 | width 470mm x depth 255mm zr-msk-012 | width 470mm x depth 255mm zr-msk-013 | width 470mm x depth 255mm zr-msk-014 | width 470mm x depth 255mm...
- Page 4 3. Fasten the device to the Rack Mount Bracket Fasten the device (NOT included in the scope of supply) to the Rack Mount Bracket using the rackmount screws (included in the scope of supply). 4. Fasten the modular expansion Fasten additional rack mount brackets in a modular fashion using the rackmount screws (included in the scope of supply) as shown below.
