HOZAN C-738 Instruction Manual

Spoke tension meter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
C-738
SPOKE TENSION
METER
Please check the package contents.
This symbol urges caution.
Make sure to read and follow
the rules and the instructions.
INSTRUCTION
MANUAL
Thank you for purchasing the HOZAN
C-738 SPOKE TENSION METER.
By controlling the spoke tension, you
can assemble the correct wheel and
diagnose wheel problems.
● Please read this entire instruction manual carefully before
attempting to place this product in service.
Please keep this instruction manual available for reference.
● Please attach this instruction manual when transferred or
lent for someone.
This product is special tool for
measuring the tension of
spokes used bicycle wheels.
The capacities of this tool is
written down on page ❶. Do
not use it for any other purpose.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C-738 and is the answer not in the manual?

Questions and answers

Related Manuals for HOZAN C-738

Summary of Contents for HOZAN C-738

  • Page 1 ❶. Do not use it for any other purpose. INSTRUCTION C-738 MANUAL Thank you for purchasing the HOZAN C-738 SPOKE TENSION METER. SPOKE TENSION By controlling the spoke tension, you can assemble the correct wheel and diagnose wheel problems.

  • Page 2: Table Of Contents

    How to find the reference value ………………… 5-6 Main operation …………………………………… 7-9 Daily inspection …………………………………… 10 Maintenance / Storage method …………………… 10 Product disposal …………………………………… 10 Specifications ……………………………………… 11 C-738 Spoke tension meter Conversion table ……❶ Identification of parts Upper knob Display Degital indicator Battery case...

  • Page 3: Identification Of Parts

    Identification of parts Package contents 取 扱 説 明 書 Checker Main unit Instruction manual Coin type lithium battery (for test operation) Other necessary items ● Coin type lithium battery (CR2032) Safety Precautions Please read this safety precations carefully before use to ensure correct use. The following symbols are displayed in this instruction manual.

  • Page 4: Operation

    Safety Precations Caution Do not use for anything other than May cause damege or malfunction. adaptive spokes. May cause injury, damege, malfunction Do not drop or hit the product. or inaccurate measurement. Operation Preparation for use How to insert the battery 1.

  • Page 5: How To Find The Reference Value

    How to find the reference value By using the checker, it is possible to easily check whether the C-738 is measuring correctly. You need to find the "reference value" before using the checker. You should to measure it when using for the first time after purchase.
  • Page 6 6. Read the measured value on the display with the checker and the stopper pin contacted. This value is the reference value of your C-738 spoke tension meter. Record it in the blank below. This reference value is only for the product you purchased.

  • Page 7: Main Operation

    Operation Main operation 1. Use the checker to make sure you can measure correctly. Measure according to the procedure on page 5 to 6 "How to find the reference value". Compare the measured value with the reference value. Acceptance Range： The reference value ±0.02mm. 2.
  • Page 8 Ex.) Round plain spoke 6. Place the C-738 aligning the spoke. Fixed pivot Hold the C-738 perpendicular to the wheel and hook the Probe spoke by the fixed pivot of C-738. And position the C-738 so that the spoke contact the surface of the guide plate A.
  • Page 9 Operation Main operation 7. Slide the C-738 until the side of the guide plate B to the position where it contacts the rim. By making the measurement points the same, you can make stable measurement. Bladed or Butted spoke Round plain spoke 8.

  • Page 10: Daily Inspection

    Keep out of reach of children. ● Keep away from high temperature, humidity and dust. ● Please store after rust prevention. ● If you do not use the C-738 for a long time, remove the battery. Product disposal Follow local reguration when disposing.

  • Page 11: Specifications

    Specifications Spokes with the shape, size, and material described Applicable Spoke Shape in the conversion table. Battery Coin type lithium battery (CR2032) x 1 pc Dimensions 185 （W） ×180 （H） ×70 （D） mm Weight 380g 1-2-12 Saiwaicho, Naniwa-ku, Osaka 556-0021, Japan Tel : +81-6-6567-3111 Fax : +81-6-6562-0024 20.09...
  • Page 12 ❶...
