OSI Systems Spacelabs 90207 Operation Manual

Ambulatory blood pressure monitors
Hide thumbs Also See for Spacelabs 90207:
Table of Contents

Advertisement

Quick Links

Download this manual
Ambulatory Blood Pressure
Monitors
90207/90217
Operations Manual
070-0137-03 Rev. J
more time to care

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Spacelabs 90207 and is the answer not in the manual?

Questions and answers

Related Manuals for OSI Systems Spacelabs 90207

Summary of Contents for OSI Systems Spacelabs 90207

  • Page 1 Ambulatory Blood Pressure Monitors 90207/90217 Operations Manual 070-0137-03 Rev. J more time to care...
  • Page 2 © 2004 Spacelabs Medical, Inc. All rights reserved. Contents of this publication may not be reproduced in any form without the written permission of Spacelabs Medical. Products of Spacelabs Medical are covered by U.S. and foreign patents and/or pending patents. Printed in U.S.A. Specifications and price change privileges are reserved.

  • Page 3: Table Of Contents

    Table of Contents Contents Operation Overview................. 1-1 ABP Monitor .

  • Page 5: Operation

    Operation Contents Overview ............1 Preparing the Patient and Precautions for Use .

  • Page 6: Replacing The Batteries

    Ambulatory Blood Pressure Monitors Rear Panel The rear panels of both monitors contain program input and data output communication ports. On the 90207, the power ON/OFF switch is also located on the rear panel. On the 90217, the ON/OFF switch is located on the top panel. Replacing the Batteries “AA”...

  • Page 7: Initializing The Monitor

    Ambulatory Blood Pressure Monitors Note: Once the lithium battery has been completely discharged, it is considered non-hazardous and can be safely discarded. Initializing the Monitor The ABP monitors must be initialized prior to the start of patient monitoring. Initialization specifies the monitoring period, patient information, time format, measurement interval, monitor tone ON/OFF during selected periods, event code display, and whether or not to display pressure values.

  • Page 8: Connecting To The Base Station Via Modem

    Ambulatory Blood Pressure Monitors Connecting to the Base Station via Modem For a modem connection to a remote IBM XT/AT/PS2 (or equivalent) base station, refer to Figure 1-3. cable to serial port public base telephone modem Monitor station network modem phone Figure 1-3: Modem connection configuration Note:...
  • Page 9 Ambulatory Blood Pressure Monitors Connection Procedure 1 If you are using an older 90207 with a 1200 modem, set the switches on the modem as follows: Switch # Setting at monitor site down down down down down 2 Connect the serial port cable (P/N 012-0096-00) between the monitor and the modem. Note: If call waiting or call forwarding are options on a telephone used to transfer data, ensure that both are deactivated.
  • Page 10 Ambulatory Blood Pressure Monitors 5 When the transfer of information is complete, the ABP monitor will beep. Voice communication is restored after the monitor beeps. • Power OFF the monitor and disconnect the monitor from the modem. • If direct connection between the monitor and the base station is used, power OFF the monitor and disconnect it from the ABP data interface unit.

  • Page 11: Office Check Mode

    Ambulatory Blood Pressure Monitors Office Check Mode The monitor automatically enters an office check mode for the first five measurements immediately following initialization. This allows you to verify the performance of the monitor on an individual patient without the need for re-initialization to reset the display features. While in the office check mode, the monitor operates as follows: •...

  • Page 12: Preparing The Patient And Precautions For Use

    Ambulatory Blood Pressure Monitors Preparing the Patient and Precautions for Use • Blood pressure measurements determined with this device are equivalent to those obtained by a trained observer using the cuff/stethoscope auscultation method, within the limits prescribed by the American National Standard, Electronic, or automated sphygmomanometers.
  • Page 13 Ambulatory Blood Pressure Monitors Table 3: Optional Accessories Accessories Part Number Cuff Support Harness 015-0070-xx Service Manual 070-0502-xx Quick Disconnect Coupling 712-0794-00 Male Quick Disconnect to Luer Adapter 712-0773-00 4 Position the cuff so that the center of the inflatable bladder is directly over the brachial artery. The center of the bladder location is marked on the outside of the cuff.

  • Page 14: Using Cuff Support

    Ambulatory Blood Pressure Monitors ALTERNATIVE #1 ALTERNATIVE #2 7 Connect the hose to the monitor. 8 To verify proper monitor operation, take one or more blood pressure readings. Push the START/STOP key to begin a measurement. Spacelabs Medical recommends taking three readings in the office so that the patient becomes comfortable with operation of the monitor and the measurement process.

  • Page 15: Correlating With Manual Readings

    Ambulatory Blood Pressure Monitors Correlating with Manual Readings The monitor bleeds pressure in discrete steps (not continuously), using the oscillometric method of blood pressure determination. If manual pressure readings are taken simultaneously with the monitor readings, interpolation is required to accurately correlate monitor systolic and diastolic pressure values with the manual auscultatory pressures.

  • Page 16: Cleaning The Cuff And Carrying Pouch

    Ambulatory Blood Pressure Monitors Cleaning the Cuff and Carrying Pouch Small soiled or stained areas may be cleaned by gentle scrubbing with a sponge or cloth soaked in a mild soap and water solution. The cuff wrap (with the air bladder removed) and the pouch are machine washable on “delicate” cycle only.

  • Page 17: Event Codes

    Ambulatory Blood Pressure Monitors Event Codes The monitor displays an event code whenever an event prevents the unit from successfully completing a blood pressure measurement. The two numerical digits of the event code indicate the reason the measurement was aborted. The table below lists event codes that are displayed on the monitor, as well as event codes that appear on the Event Code Report.
  • Page 18 Ambulatory Blood Pressure Monitors Monitor Report Condition EC52 Kinked hose. EC62 Cuff applied too loosely. EC82 Kinked hose. EC03 Patient canceled reading by pressing STOP key. No retry attempt is made EC03 following an EC03 code. The Office Check Mode has been reinstated. No retry attempt is made following EC13 an EC13 code.
  • Page 19 Ambulatory Blood Pressure Monitors Monitor Report Condition EC05 & EC85 Equipment malfunction. Return to Spacelabs Medical for service. EC85 Cuff pressure baseline out of bounds. The monitor should correct the baseline EC05 & automatically within 10 minutes, or it can be set by initialization of the monitor. If EC95 EC95 initialization does not correct the condition, the monitor must be returned to...
  • Page 20 Ambulatory Blood Pressure Monitors Monitor Report Condition EC99 Unexpected or contradictory data (such as a negative cuff pressure). EC16 Low battery detected prior to start of measurement. Low battery detected after measurement started. Usually caused by the pump EC26 drawing enough current to lower the battery voltage. The report does not print an event code for this condition, which is a low backup battery.

  • Page 21: Accuracy

    Accuracy Contents Checking Accuracy ........... 1 Checking Accuracy Accuracy of the monitor pressure readings should be checked annually.

  • Page 22: Accuracy Procedure

    Ambulatory Blood Pressure Monitors Accuracy Procedure To check the accuracy of the monitor: 1 Disconnect the cuff hose from the monitor. Connect the T-tube splitter to the monitor pneumatic connector and the sphygmomanometer. 2 Wrap the pressure cuff around the rigid cylinder, and then fasten the cuff. Connect the cuff hose to the remaining connection on the T-tube splitter.
  • Page 23 Ambulatory Blood Pressure Monitors 3 Press START/STOP on the monitor; the monitor should read approximately 165. Compare the readings on the monitor and the manometer as the pressure bleeds down. The monitor reading should be within three millimeters or 2%of the manometer reading, whichever is greater (±...

  • Page 25: Troubleshooting

    Troubleshooting Contents Problem Solving Checklist ..........1 Servicing .

  • Page 26: Servicing

    Ambulatory Blood Pressure Monitors Servicing There is a 12-month warranty on this product. Field service of the ABP monitor is limited to replacing batteries and accessories. If other repair is required, return the monitor to Spacelabs Medical. Contact your Spacelabs Medical Customer Service Representative for shipping details.

  • Page 27: Symbols

    Symbols The following list of international and safety symbols describes all symbols used on Spacelabs Medical products. No one product contains every symbol. Symbol Description Symbol Description HELP Key Keyboard Connection SPECIAL FUNCTIONS Key Mouse connection RECORD Key START/STOP Key NORMAL SCREEN Key START/STOP MONITOR SETUP Key...
  • Page 28 Ambulatory Blood Pressure Monitors Symbol Description Symbol Description Stand-by STAND-BY Key PAUSE or INTERRUPT Slow Run Reset Power Indicator LED Temporary Shut Off of Alarm Tone Alarm or Screen Indicators Indicator — Remote Control Indicator — Local Control PRINT REPORT Key Indicator —...
  • Page 29 Ambulatory Blood Pressure Monitors Symbol Description Symbol Description Data Input/Output Input/Output Input Reset Menu Keys Waveform/Parameter Keys Monitor Setup Set Initial Conditions Menu Select Program Options Access Special Function Menu Return Unit to Monitor Mode Serial Port 1 Serial Port 2 External marker push button SDLC Port SDLC...
  • Page 30 Ambulatory Blood Pressure Monitors Symbol Description Symbol Description Open Padlock Closed Padlock Down Arrow Up Arrow Hard Drive Power Indicator LED Antenna Mermaid Connector Microphone Omnidirectional Microphone Audio Output, Speaker Activate Telemetry Recorder Network Connection Universal Serial Bus Gas Sampling Port Gas Return Port Remote Alarm;...
  • Page 31 Ambulatory Blood Pressure Monitors Symbol Description Symbol Description Protective Earth Ground Functional Earth Ground Replace Fuse Only as Marked Fuse Power supply jack polarity. Equipotentiality Terminal (+ / - signs may be reversed) Alternating Current Direct Current Both Direct and Alternating Current AC/DC Input Amperes Hertz...
  • Page 32 Ambulatory Blood Pressure Monitors Symbol Description Symbol Description Canadian Standards Association ® ETL Laboratory Approved Approved Risk of Explosion if Used in the Operates on Non-Harmonized Presence of Flammable Anesthetics Radio Frequencies in Europe Attention - Consult Operations or Note Note Service Manual for Description Warning About Potential Danger to...
  • Page 33 Ambulatory Blood Pressure Monitors Abbreviations used as symbols are shown below. Symbol Description Symbol Description Access Codes 1 - 32 1 Through 32 ANT 1 Diversity Antenna System 1 Arr1 Arrhythmia Net 1 ANT 2 Diversity Antenna System 2 ArrNet2 Arrhythmia Net 2 EEG, EMG, or ECG Channel EEG Channels - CH1, CH2, CH3, CH4...
  • Page 34 Ambulatory Blood Pressure Monitors Symbol Description Symbol Description Temperature 1 Temperature 2 Systolic Temperature 3 Temperature 4 TEMP Temperature Uterine Activity or Umbilical Artery temp Vacuum Connection...
