Operating Instructions & Parts Manual
Model
44010
44020
Model 44010
!
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
ADVERTENCIA
!
• Leer, comprender, y seguir las instrucciónes antes
de utilizar el aparato.
• El manual de instrucciónes y la información de
seguridad deben estar comunicado en lengua del
operador antes del uso.
• No seguir estas indicaciónes puede causar daños
personales o materiales.
Read this manual and follow all the Safety Rules and Operating Instructions before using this product.
Engine Cranes
(Foldable Legs)
(Retractable Legs)
Capacity
1 Ton
2 Ton
Model 44020
WARNING
!
To avoid crushing and related injuries:
NEVER work on, under or around a
load supported only by engine crane.
ALWAYS use adequately rated engine
stand.
http://www.omegalift.com
SFA Companies
Printed in China
44010-M0 rev 11/07

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 44010 and is the answer not in the manual?

Questions and answers

Related Manuals for Omega Lift Equipment 44010

Summary of Contents for Omega Lift Equipment 44010

  • Page 1 • No seguir estas indicaciónes puede causar daños personales o materiales. SFA Companies http://www.omegalift.com Read this manual and follow all the Safety Rules and Operating Instructions before using this product. Printed in China 44010-M0 rev 11/07...
  • Page 2 Boom Boom Extension Hook Figure 2 - Model 44020 Components...
  • Page 3 M20x100 1 26 -Lock Washer M20 27 -Nut 29 -Bolt M16x70 1 30 -Lock Washer M16 31 -Nut 33 -Bolt M10x30 2 34 -Lock Washer M10 35 -Nut 37 -Bolt M16x90 1 Figure 3 - Assembly Illustration for Model 44010...
  • Page 4 ASSEMBLY 5. Attach bracket (#5) to hydraulic unit (#1) with bolts, Model 44020: washers & nuts (#6, 25 & 26). 1. Make sure all parts are present (refer Fig. 2 & 4). If Then attach the assembly to upright mounting ears any parts is missing or damage, contact customer using bolt &...

  • Page 5: Before Use

    Capacity Length Position Height Height Stroke (Front) (Rear) 1 Ton 4 7/8" 82 1/4" 33 7/8" 18 1/2"~ 44010 1 Ton 19" 71 5/8" 31 1/2" 3/4 Ton 3 3/8" 85" 39 3/4" 44 7/8" 1/2 Ton 0" 86 5/8"...
  • Page 6 WARNING • Study, understand, and follow all instructions provided with/on this device before use. • After removing, immediately transfer the engine to an appropriately rated work station such as an engine stand. • Do not exceed rated capacity. Do not exceed rated capacity for each boom and/or leg position. •...

  • Page 7: Operation

    OPERATION For model 44020: Incorrect boom/ leg The crane features length adjustable boom and, length and width adjustable leg position may result extensions. Extend both rear legs to an equal width. It is recommended that both rear in personal injury and/or legs be extended to the maximum allowable distance as limited by the marking on property damage.

  • Page 8: Maintenance

    MAINTENANCE Periodically inspect the engine crane and fasteners. Replace worn or damaged parts with factory replacement parts only. Ensure caster, wheels, boom extension, leg extensions (if equipped) and pump assembly move freely. Important: Use only a good grade hydraulic jack oil. We recommend Mobil DTE 13M or equivalent. Avoid mixing different types of fluid and Never use brake fluid, turbine oil, transmission fluid, motor oil or glycerin.

  • Page 9: Troubleshooting

    TROUBLESHOOTING Symptom Possible Causes Corrective Action Crane will not lift load • Release valve not tightly closed • Ensure release valve tightly closed • Overload condition • Remedy overload condition Crane will lift, but not maintain • Ensure release valve tightly closed •...

  • Page 10: Replacement Parts

    Boom Extension T473-00005-000 Hydraulic Unit Bracket T474-09000-000 Hardware Kit T474-07000-000 Hook Assembly BL800S-034 Seal Kit, Hydraulic Unit T474-00003-000 Front Wheel, 5" 44010-L0 Label T474-00002-000 Middle Wheel, 3-1/2" 44010-M0 Manual T474-04000-000 Caster, 3-1/2" Figure 7 - Replacement Parts Illustration for Model 44010...
  • Page 11 BL80-20000-000 Pump Handle T473-00002-100 Rear Leg Extension T473-00005-000 Hydraulic Unit Bracket T473-06000-000 Hardware Kit T473-05000-000 Hook Assembly BL800S-034 Seal Kit, Hydraulic Unit T473-04000-000 Caster, 3-1/2" 44020-L0 Label T473-00001-000 Braces 44010-M0 Manual Figure 8 - Replacement Parts Illustration for Model 44020...

  • Page 12: One-Year Limited Warranty

    ONE YEAR LIMITED WARRANTY For a period of one (1) year from date of purchase, SFA Companies will repair or replace, at its option, without charge, any of its products which fails due to a defect in material or workmanship under normal usage. This limited warranty is a consumer's exclusive remedy.
