LubriMist
Model DXT
Oil Mist Generating System
Installation and Operating Manual
Revision History:
Rev 1
1. Added Vacuum assists as standard.
2. Updated drawings and BOM; 235-273 is not in M2M replaced by 77500843
fast ball pump 1:1 ratio.
®
3. Added LubriMist
77740212 REV 2 August 2020
1
Advertisement
Table of Contents
Related Manuals for RelaDyne LubriMist DXT
Summary of Contents for RelaDyne LubriMist DXT
- Page 1 ® LubriMist Model DXT Oil Mist Generating System Installation and Operating Manual Revision History: Rev 1 1. Added Vacuum assists as standard. 2. Updated drawings and BOM; 235-273 is not in M2M replaced by 77500843 fast ball pump 1:1 ratio. ®...
- Page 2 ® LubriMist Model DXT Oil Mist Generating System Installation and Operating Manual Manufacturer 5615 W Fuqua St. B-201 Houston, Texas 77085 Ph 713.464.6266 Fax 713.464.7375 ©2006 Lubrication Systems Company. All Rights Reserved. Reproduction and transmission by any means without express written permission is prohibited, except as allow under the copyright laws.
- Page 3 Installation and Operation Manual Introduction: ® A LubriMist Oil Mist System is a centralized lubrication system that generates, conveys and automatically delivers lubricant to bearings, gearboxes, chains and ® sliding surfaces in various industrial machinery and equipment. The LubriMist Model DXT demisting tank is designed to separate suspended oil droplets from the vented mist stream after the oil mist has been passed through the mechanical bearing element being serviced.
- Page 4 Installation: The DXT should be mounted below the lowest machinery element being serviced by the Oil Mist Generator. If located indoors, the room should have cross ventilation from a fresh air supply. The return / drain header from the machinery being serviced by the Oil Mist Generator should be installed to continually drain toward the DXT reservoir.
- Page 5 Start-Up To start-up and commission the Model DXT Demisting Tank, follow these steps: 1) Check and insure that all utilities are properly and securely connected. 2) Ensure that the coalescing filter element is installed and the filter housing cover properly installed and secured with the spring-loaded latches. Ensure that the blower discharge pressure bleed valve is in the full closed position.
- Page 6 CAUTION Maximum discharge temperature is 160° F. If temperature rises to 155° F open the air pressure bleed valve and reduce the air blower discharge pressure. 7) When return header vacuum assist is used, close the vacuum vent gate valve to achieve the desired return header setting.
- Page 7 Model DXT Parts List 77740212 REV 2 August 2020...
- Page 8 Model DXT Dimensions 77740212 REV 2 August 2020...
