TABLE OF CONTENTS
Location of PC Boards & Versions Variation ........................ 1
Specifi cations ....................................................................... 2
Safety Instruction .................................................................. 3
Software Upgrade Instruction..................................................4
Troubleshooting.................................................................... 5
Disassembly Instructions ..................................................... 6
Set Block & Wiring Diagram ................................................. 7
Circuit Diagram & PCBA Layout........................................... 8
Set Mechanical Exploded View .......................................... 9
Revision List ........................................................................ 10
FX25/12
Page
3140 038 62110
Advertisement
Table of Contents
Related Manuals for WOOX FX25/12
Summary of Contents for WOOX FX25/12
- Page 1 WOOX Innovations. Philips and the Philips’Shield Emblem are registered trademarks of Koninklijke Philips N.V. and are used by WOOX Innovations Limited under license from Koninklijke Philips N.V.
-
Page 2: Main Board
PCB Board Locations FRONT CONTROL BOARD NFC BOARD KEY BOARD USB BOARD SUPPORT BOARD IN BOARD Inside the front panel LOADER POWER BOARD MAIN BOARD On the bottom plate Reminder: As BT and NFC need to be paired , and BT is on Front control board , when one of BT , NFC or Front control Board needs to be replaced , all of these three parts need to be replaced together. -
Page 3: Purpose And Scope Of Document
Title: Product Performance Reference: WX-B-009-01 Rev./Status: 0.1 / Draft Specification Model : FX15 FX25 FX55 Page 4 of 16 1. Introduction Purpose and Scope of Document TheProduct Performance Specificationis the leading specification and is the response of development. Whenever the specification cannot be met, Product Management is to be informed as early as possible in order to make sure the marketing can respond in time. -
Page 4: General Information And Requirement
Title: Product Performance Reference: WX-B-009-01 Rev./Status: 0.1 / Draft Specification Model : FX15 FX25 FX55 Page 5 of 16 2. General Information and Requirement Product Family Features 2.1.1 Identity and Key Features FX15 FX25 FX55 is a MiniAudio Systemthat incorporates CD player with USB and Tuner FM/AM, and Blue Tooth support. - Page 5 Title: Product Performance Reference: WX-B-009-01 Rev./Status: 0.1 / Draft Specification Model : FX15 FX25 FX55 Page 6 of 16 2.1.3 ACCESSORIES Model FX15 FX25FX55 Stroke Version Region Power Cord Audio cable (3.5mm audio) Tuner Antenna Speaker cable USB cable Remote Control 21keys Battery 1xAAA...
-
Page 6: Mechanical General Information
Title: Product Performance Reference: WX-B-009-01 Rev./Status: 0.1 / Draft Specification Model : FX15 FX25 FX55 Page 7 of 16 Mechanical General Information The productappearances and functions are defined in their respective MUS. Product management approves the MUS and it is a leading document where product appearance is applicable. Please refer to Sh560 for mechanical information. -
Page 7: Esd Requirements
Title: Product Performance Reference: WX-B-009-01 Rev./Status: 0.1 / Draft Specification Model : FX15 FX25 FX55 Page 8 of 16 ESD Requirements The product shall withstand electro static discharges on all user accessible parts of the product. Reference: IEC61000-4-2. For contact discharges: Level General (kV) USA (kV) -
Page 8: Technical Specifications
Title: Product Performance Reference: WX-B-009-01 Rev./Status: 0.1 / Draft Specification Model : FX15 FX25 FX55 Page 9 of 16 3. Technical Specifications Power Supply 3.1.1 Type and versions 3.1.1.1 Main set Build-inSMPS will be used for all models and stroke versions. Versions Region/Country SMPS... - Page 9 Title: Product Performance Reference: WX-B-009-01 Rev./Status: 0.1 / Draft Specification Model : FX15 FX25 FX55 Page 10 of 16 • Polarity and phase: Positive (phase 90º) & Negative (phase 270º) Common mode: • 6kV/2 ohm criteria C for Europe. • 6kV/12 ohm criteria C for Nafta.
- Page 10 Title: Product Performance Reference: WX-B-009-01 Rev./Status: 0.1 / Draft Specification Model : FX15 FX25 FX55 Page 11 of 16 Audio 3.2.1 Analog Audio Input/Outputs Gerneral Part Output Stage Protection: Temperature : Short Circuit: Indicators Standby Mode Indicator: Clock Display Active Power Standby Mode: LED Turns Off Electrical Data...
- Page 11 Title: Product Performance Reference: WX-B-009-01 Rev./Status: 0.1 / Draft Specification Model : FX15 FX25 FX55 Page 12 of 16 Speaker driver Impedance: Right/Left: FX15/FX25 8Ω FX55 4Ω Subwoofer: REMARKS: Electrical Parameters are to be measured at Speaker Terminals across rated impedance Loadwith Rated Input Signalin CD Mode setting in DBB/Loudness Off and Pre-eq at Flat unless specified otherwise.
- Page 12 2-10 Title: Product Performance Reference: WX-B-009-01 Rev./Status: 0.1 / Draft Specification Model : FX15 FX25 FX55 Page 13 of 16 3.4TUNER FM/AM tuner Module: KST-MW004MV1-R78W2 IC : RN5B800 GENARAL PART WAVE RANGE VERSION TOLERANCE TUNING GRID FM 87.5 – 108.00 MHz /05/12 QUARTZ PRECISION 50kHz...
-
Page 13: Infra Red Receiver
2-11 Title: Product Performance Reference: WX-B-009-01 Rev./Status: 0.1 / Draft Specification Model : FX15 FX25 FX55 Page 14 of 16 Infra Red Receiver Parameters Requirement Receiver sensitivity Max Distance • E(0°) = 0.70 mW/m • E(30°,h) = 1.12 mW/m , γ= ± 30° 7.92m Receiver Sensitivity off horizontal or vertical axis... - Page 14 2-12 Title: Product Performance Reference: WX-B-009-01 Rev./Status: 0.1 / Draft Specification Model : FX15 FX25 FX55 Page 15 of 16 MECHANICAL 3.5.1 Shock Sensitivity Refer to Quality plan for the details of the test discs and testing method. Requirement: No muting, plop sounds, picture freeze/jerk or audible/visible interference when impacting with force of - In the ±X and ±Y directions: F ≥...
- Page 15 Solder Joint...
-
Page 16: Restore Default Settings
The Guide of Software Operation for Philips Mini FX Series The Software Upgrade way (Update software via USB): 1.> Download the Software into the root directory of a USB storage device. 2.>Rename the download software file, such as rename the "PCM_MCU_V12.bin"to"PCM_MCU.bin“. 3.>Turn on the unit and switch to the USB source. ‐‐>"NO USB" is displayed. 4.>Connect the USB storage device to the USB socket on the unit. ‐‐>"MCU UPD"(MCU update) is displayed. 5.>Press " " key to start upgrade. ‐‐>"UPGING"(upgrading) is displayed during upgrade. At completion of upgrade, the unit reboots automatically. 6.> Delete the "PCM_MCU.bin" in the USB storage device, and repeat step 1.>/2.>/3.>/4.>/5.> to upgrade MPEG S/W, Rename software file, such as rename "PCM_MPEG_FX20_55_V13.bin"to"PCM_MPEG.bin". ‐‐>"MPEG UPD" is display. Caution: Do not turn off the power or remove the USB storage device when the software update is in progress because you might damage the unit. The Software Version to view: 1.>Turn on the unit and switch to the DISC source. ‐‐>"NO DISC" is displayed. 2.>Press "EJECT" key to open the door. ‐‐>"OPEN" is displayed. 3.>Press the key STOP ( ) ‐>PROG‐>NEXT ( ) in turn on RC. ‐‐>the VFD will show such as "M1220P13". Note : When view software version type, VFD can be show below information, eg: M0820P16 M08: MCU version 20 : FX20 model, if this unit is 15/25/30/50/55,mean is FX15/FX25/FX30/FX50/FX55 model. P16: Mpeg version. Restore default settings: You can also restore the default settings of the unit. Turn on the unit, in any source, press and hold both the key and PRESET‐ on the front panel for more than three seconds. ‐‐>After a while, "RESET OK" is displayed. Then, the unit reboots automatically. ... - Page 17 Trouble shooting Chart Power on Doesn't Work Adapter has problem Check the 39V voltage of XP5 and XP8 Check the 3.3V voltage of MCU Check the VCC5V out from DC-DC Check 9pin and 24pin of MCU and confirm whether they have normal voltage Confirm whether there are DVCC33 and VC12 MPEG has problem...
- Page 18 Can’t read USB or USB has no sound Check the 5V voltage of XP14 Confirm whether there is 5V voltage of S pin of Q13 Check the normality of the communication Q13 has problem between MPEG and USB MPEG has problem...
- Page 19 Can’t connect NFC Confirm whether there response U1 has problem of mobile phone The circuit of NFC can work normally...
- Page 20 BT has no sound board has problem Check whether there is audio signals of the 4 and 8 pin of XP11 and change it Check whether there is audio signals of Check the connection of VFD board the 22 and 24 pin of XP82 and main board Check the connection of R162 and Confirm whether there is audio signals of...
- Page 21 FM AUX and MP3 have no sound Confirm whether there is audio signals of Check the connection of these nets to the 5 and 14 pin of U17 Check as the procedure of BT has no sound from the forth step...
-
Page 22: Mechanical And Dismantling Instructions
Mechanical and Dismantling Instructions Dismantling Instruction Detailed information please refer to the model set. The following guidelines show how to dismantle the player. Step 1:Open the top cover.Remove 5 screws on the back panel and 2 screw on the left and right sides, then open the cover from the back panel side.(Figure 1) (Figure 1) Step 2:Dismantle the loader.Disconnect the connectors on main board.Remove 2 screws besides the... - Page 23 Mechanical and Dismantling Instructions Dismantling Instruction Detailed information please refer to the model set. The following guidelines show how to dismantle the player. Step 4:Dismantle the front panel.Disconnect the connectors on the main and power board. Release 2 buckles under the bottom plate and 2 screws on the left and right sides.(Figure 3) (Figure 3) Step 5:Dismantle the support board.Remove 2 screws on the board.(Figure 4)
- Page 24 Mechanical and Dismantling Instructions Dismantling Instruction Detailed information please refer to the model set. The following guidelines show how to dismantle the player. Step 10:Dismantle the front control board.pull out the volume knob. Remove 9 screws on the board. Release the buckles on the board.Then pull out the board.(Figure 6) (Figure 6) Step 11:Dismantle the power board.
- Page 25 Block Diagram: CD LOADER IM+TDL-5 Crystal 60W*4 @THD 10% MOTOR DRIVER AM5890 Signed and feedback SDRAM FLASH MPEG DECODER IIS.SLAVE STA518 SPHE8104WW Audio AK5358 Data Processor STA311B AM/FM Control I/O R78W2 Source Source UART Switch VFD DRIVER STA518 74HC4052 VFD Display M i b Main board STM8S005C6...
-
Page 26: Power Board
Wiring Diagram 6PIN 4PIN 4PIN 24PIN 24PIN Loader Loader 2PIN Power M i b Main board 6PIN board 3PIN IN board IN board XP82 XP14 24PIN 4PIN 2PIN XP82 XP83 KY board VFD board VFD board USB board USB board 3PIN NFC board... - Page 27 Circuit Diagram - Support board...
- Page 28 Circuit Diagram - Key board 3PIN/2.0mm 3PIN/2.0mm SW17 SW17 R146 R146 1K/1% 1K/1% LED1 SW16 SW16 5PIN/2.0mm 5PIN/2.0mm SW27 SW27 TAC020 TAC020 SW26 SW26 TAC020 TAC020 LED3 LED3 LED1 LED6 LED6 LED_BULE LED_BULE 100pF/50V/NP0 100pF/50V/NP0 LED_BULE LED_BULE...
- Page 29 Circuit Diagram - USB board USB_VCC USB_VCC USB_DM USB_DM USB_DP USB_DP To main board 4PIN/2.0mm/260mm 4PIN/2.0mm/260mm 4PIN/2mm 4PIN/2mm 0.01uF/50V/X7R 0.01uF/50V/X7R NC/0 NC/0 NC/0.01uF/50V/X7R NC/0.01uF/50V/X7R 0.1uF/50V/X7R 0.1uF/50V/X7R LED_BULE LED_BULE LED9 LED9 2PIN/2.0mm 2PIN/2.0mm 100pF/50V/NP0 100pF/50V/NP0 LED12 LED12 LED_BULE LED_BULE 2PIN/2.0mm 2PIN/2.0mm...
- Page 30 Circuit Diagram - IN board AUDIO IN CON2 CON2 3PIN/2.0mm/260mm 3PIN/2.0mm/260mm 500/200mA 500/200mA AUDIO IN_R TP64 TP64 AUDIO IN_L 500/200mA 500/200mA Audio in Audio in TP65 TP65 3300pF/50V/X7R 3300pF/50V/X7R AUDIO IN_R AUDIO IN_L MIC_det 12V_D_A 6PIN/2.0mm 6PIN/2.0mm 12V_D_A R609 R609 2.2K 2.2K 12VA...
- Page 31 Circuit Diagram - Front Control board +12V VFD1 VFD1 MCU3V3 XP11 XP11 + CE4 + CE4 PIO8 47uF/25V 47uF/25V BT_RESET BT_STATUS +5VA BT_POWER_CONTROL BT_STATUS1_PAIR BT_FN BT_R NPN_3DG3904M NPN_3DG3904M BT_L NFC_BT NPN_3DG3904M NPN_3DG3904M PNP_3CG3906M PNP_3CG3906M MCU3V3 +12V 14PIN/2.0mm 14PIN/2.0mm 0.1uF/50V/X7R 0.1uF/50V/X7R 3.3uF/50V 3.3uF/50V 330/1%...
- Page 32 Circuit Diagram - Power board Alternative R509 R509 CN502 CN502 R521 R521 NC/2.2/2W NC/2.2/2W Alternative RV502 RV502 CE503 CE503 CE5032 CE5032 C523 C523 C525 C525 Alternative CE5031 CE5031 D542 D542 HER203G/2A/200V HER203G/2A/200V Alternative R508 R508 CY507 CY507 470pF/250VAC 470pF/250VAC +41.5V 150uF/450V 150uF/450V R510...
- Page 33 8-15 Circuit Diagram - Bluetooth board R938 R938 NC/2K NC/2K R945 R945 R946 R946 C793 C793 R937 R937 4.7UF/10V/X5R 4.7UF/10V/X5R BT_R1 C797 4.7UF/10V/X5R C797 4.7UF/10V/X5R R949 R949 C791 C791 U603A U603A TP43 TP43 R939 R939 R943 R943 F4558M F4558M 4.7UF/10V/X5R 4.7UF/10V/X5R 3.9nH/400mA 3.9nH/400mA...
- Page 34 8-16 Circuit Diagram - NFC board 3PIN/1.25mm 3PIN/1.25mm NTAG203F NTAG203F 39pF/50V/NP0 39pF/50V/NP0 0.1uF/16V/X7R 0.1uF/16V/X7R...
- Page 35 8-17 Print-layout - USB Board & Key Board & Support Board (bottom side)
- Page 36 8-18 Print-layout -Front Control Board & In Board (bottom side)
- Page 37 8-19 Print-layout - Power Board (bottom side)
- Page 38 Exploded View for FX25: Remarks: ASSY1 includes 2,4,5,6,7,8,25,31,32,33,34,35,36,37,38 Partlist refer to a separated excel file on FYP...
-
Page 39: Revision List
REVISION LIST V 1.0 2014-5-30 Initial release for FX25/12. 2015-10-11 Content update. V2.0 2015-12-18 Add reminder of BT & NFC pair. V3.0...
