ALL-O-MATIC TK-1000 Installation Instructions

Tandem gate hardware

All manuals and user guides at all-guides.com

TK-1000 TANDEM GATE HARDWARE

INSTALLATION INSTRUCTIONS

WARNING!

If this is the first time attempting a tandem gate installation

please consult ALL-O-MATIC or someone with tandem gate

installation experience. These instructions are guidelines only,

every Tandem Gate installation is unique and has its own unique

measurements. The TK-1000 Tandem Kit was designed to work

with ALL-O-MATIC slide gate operators slowed down to about

50% speed. Please make sure to request a Slowed Tandem

Gate Setup on all gate operators that will be used with the ALL-

O-MATIC Tandem Gate Hardware Kit.

Note: TK-1000 works best with ALL-O-MATIC DC Slide Gate

Operators (SL-100DC and SL-150DC) operators must be slowed

down.

Table of Contents

Do you have a question about the TK-1000 and is the answer not in the manual?

Page 1 These instructions are guidelines only, every Tandem Gate installation is unique and has its own unique measurements. The TK-1000 Tandem Kit was designed to work with ALL-O-MATIC slide gate operators slowed down to about 50% speed. Please make sure to request a Slowed Tandem Gate Setup on all gate operators that will be used with the ALL- O-MATIC Tandem Gate Hardware Kit.
Page 2 All manuals and user guides at all-guides.com INSIDE SECOND PANEL OPERATOR TRACKS FIRST PANEL POST FENCE LINE OUTSIDE TOP VIEW 24’’ 8’’ 3’’ 1’’ FIRST PANEL SECOND PANEL IDLER ON FIRST PANEL 4’’ IDLER ON THE POST 4’’ VIEW FROM OUTSIDE PROPERTY When installing chain, make sure the two gate panels are in the fully closed position.
Page 3 All manuals and user guides at all-guides.com INSIDE SECOND PANEL OPERATOR 3’’ TRACKS FIRST PANEL 3’’ FENCE LINE POST TOP VIEW OUTSIDE ’’ ’’ 1’’ NOTE: Slow down operator by half the speed on every installation to maintain 12’’ per second on second panel. DRIVEWAY REAR SPACE TOTAL LENGHT...
