ROBLAN ICEIP44SENFRW18F Instruction Manual

LED ICE FPL IP44

NOTES

The product should be installed by a qualified electrician. The manufacturer reserves the right to refuse warranty service if the
product shows signs of damage due to incorrect maintenance or installation. Surface mounted installation only.
Do not install the product in high temperature or humid place.

INSTALLATION

1. Turn off the power.
2. Turn the lamp difuser to losen and and separate from the housing. as shown in picture a.
3.Fix the housing with the expansion pipe and self-tapping screws as shown in picture b.
4.Connect the commercial power wire with the terminal block as shown in picture c.
5. Recheck if everything is well connected. Cover the housing with the lamp difuser and rotate to finish the installation (as
shown in picture d).Turn on the power.
a.

WARNINGS:

* Power should be cut off before installation, maintenance or inspection.
* Please install and use the light strictly according to the instruction.
* Do not disassemble or remold the product to avoid accident of electric shock or light failure.
* The wall switch only controls the main power, not the emergency lighting.
* If you discover any malfunction or abnormal condition, please informt the supplier.
ITEM NUMBER
Input Voltage(VAC)
Input Current(A)
Power(W)
Power Factor
Color Temperature(K)
Luminous Flux (Lm)
Beam Angle(°)
Lifespan (hour)
Protection Rate
Working Temperature(°C)
CRI (Ra)
Detection sensitivity
Hold Time
Daylight Sensor
Mounting height
Motion detection
Detection angle
Measurements
MANUAL DE INSTRUCCIONES
INSTRUCTION MANUAL
SENSOR
b.
Avda. de Las Retamas 5. 45950 Casarrubios del Monte (Toledo) España
Tel: +34 91 616 50 20 Email: roblan@roblan.com
c.
ICEIP44SENFRW18F
220-240V AC
0.14
18
3000WW/ 4000NW
1500/1600
30000
-20-40
10% / 25% / 50% / 75% / 100%
5s / 30s / 90s / 3min / 20min / 30min
2lux / 10lux / 25lux / 50lux / Disable
6m Max.
0.5~3m/s
150°(wall installation)/ 360°(ceiling installation)
105 360
d.
ICEIP44SENFRW32F
0.24
32
>0.9
2800/3000
120
IP44
>80
11 5 410
