MODEL W1690
DELUXE CEILING-MOUNTED
AIR FILTER
OWNER'S MANUAL
(FOR MODELS MANUFACTURED
SINCE 02/03)
Phone: (360) 734-3482 • Online Technical Support: techsupport@woodstockint.com
COPYRIGHT © FEBRUARY, 2003 BY WOODSTOCK INTERNATIONAL, INC.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT
THE WRITTEN APPROVAL OF WOODSTOCK INTERNATIONAL, INC.
V1.12.16
#4946CR Printed in China
Advertisement
Table of Contents
Related Manuals for Shop fox W1690
Summary of Contents for Shop fox W1690
- Page 1 MODEL W1690 DELUXE CEILING-MOUNTED AIR FILTER OWNER'S MANUAL (FOR MODELS MANUFACTURED SINCE 02/03) Phone: (360) 734-3482 • Online Technical Support: techsupport@woodstockint.com COPYRIGHT © FEBRUARY, 2003 BY WOODSTOCK INTERNATIONAL, INC. WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF WOODSTOCK INTERNATIONAL, INC. V1.12.16 #4946CR Printed in China...
- Page 2 This manual provides critical safety instructions on the proper setup, operation, maintenance, and service of this machine/tool. Save this document, refer to it often, and use it to instruct other operators. Failure to read, understand and follow the instructions in this manual may result in fire or serious personal injury—including amputation, electrocution, or death.
-
Page 3: Table Of Contents
TABLE OF CONTENTS PAGE INTRODUCTION ......................2 About Your New Deluxe Ceiling-Mounted Air Filter ..............2 Woodstock Service and Support ...................2 Warranty and Returns ......................3 Specifications ......................3 SAFETY .......................... 4 Standard Safety Instructions ....................4-5 Additional Safety Instructions for Air Filters ................6 ELECTRICAL ........................7 110V Operation ........................7 Extension Cords ........................7 Grounding ..........................7 INSTALLATION ....................... 8 Unpacking ..........................8 Box Contents .........................8 Shop Preparation ........................9 Dust System ..........................9 Beginning ..........................10 Table-Top Mount .........................10 Hanging Mount ........................11 Flush Mount .........................12 OPERATION ......................... -
Page 4: Introduction
Close attention to detail, ruggedly built parts and a rigid quality control program assure safe and reliable operation. When used in conjunction with a dust collector system, the W1690 Deluxe Ceiling-Mounted Air Filter efficiently removes fine wood particles in the air that many dust collectors cannot. Your unit has key features like a 5-micron outer filter, a washable 1-micron inner filter, three fan speeds, 110V operation, remote control functions, and a compact design. -
Page 5: Warranty And Returns
Warranty and Returns SHOP FOX Woodstock International, Inc. warrants all machinery to be free of defects from workmanship ® and materials for a period of 2 years from the date of original purchase by the original owner. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence or accidents, lack of maintenance, or to repairs or alterations made or specifically authorized by anyone other than Woodstock International, Inc. -
Page 6: Safety
SAFETY READ MANUAL BEFORE OPERATING MACHINE. FAILURE TO FOLLOW INSTRUCTIONS BELOW WILL RESULT IN PERSONAL INJURY. Indicates an imminently hazardous situation which, if not avoided, WILL result in death or serious injury. Indicates a potentially hazardous situation which, if not avoided, COULD result in death or serious injury. - Page 7 12. DO NOT force tool. The machine will do a safer and better job at the rate for which it was designed. 13. Use correct tool. Do not force machine or attachment to do a job for which it was not designed. 14.
-
Page 8: Additional Safety Instructions For Air Filters
Additional Safety for Air Filters INTENDED USE. This air filter is designed DISCONNECTING POWER SUPPLY. Turn the to capture dust from ambient air in a switch OFF, disconnect the air filter from the woodworking shop for a short time after power supply, and allow the impeller to come cutting or sanding operations. -
Page 9: Electrical
Ground this machine! The electrical cord circuit that can carry the load. supplied with the Model W1690 Air Filter has a ground pin. If your power receptacle does not DO NOT modify an existing low-amperage circuit... -
Page 10: Installation
Figure 2. Model W1690 Deluxe Ceiling- Mounted Air Filter and filters. No assembly is required for the Model W1690 Deluxe Ceiling-Mounted Air Filter; however, you should remove the filters and remove any packing material that may be inside of the unit. -
Page 11: Shop Preparation
When used in conjunction with a dust collector • Machine Mobility: This air filter unit has a system, the Model W1690 Deluxe Ceiling- balanced fan and uses digital components. Mounted Air Filter efficiently removes most Move this air filter unit with care, and do not fine wood particles in the air that many dust drop or handle it roughly. -
Page 12: Beginning
Flush Mount Flange Bracket Figure 5. Air filter unit mounting hardware. lifting assistance before installation. At 55 pounds, the Model W1690 air filter is heavy. Rubber Foot To set up the air filter for table-top operation, do these steps: Flush Mount... -
Page 13: Hanging Mount
At 55 pounds, the Model W1690 air filter is heavy. Figure 7. Plug screw. ONLY hang air filter to load bearing ceiling supports or joists that can hold at least 100 lbs. -
Page 14: Flush Mount
Figure 9. Typical unacceptable fasteners. lifting assistance before installation. At 55 pounds, the Model W1690 air filter is heavy. Mounting holes To install the air filter for flush mount operation, do these steps: 1. -
Page 15: Operation
OPERATION Overview Control Panel When the Model W1690 Deluxe Ceiling-Mounted The control panel enables you to manually turn Air Filter is turned on, the fan motor starts on HI the air filter ON and OFF, and set the fan speed. -
Page 16: Troubleshooting
Troubleshooting This section covers the most common problems and corrections with this type of machine. WARNING! DO NOT make any adjustments until power is disconnected and moving parts have come to a complete stop! PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Machine does not start or a 1. -
Page 17: Maintenance
Filters The amount of use has a direct bearing on when you must change the primary air filter and service Filter Retainer Latch SHOP FOX the secondary air filter. Contact your ® dealer for other possible filter types available. Keep the air filter unit... -
Page 18: Closure
However, due to Woodstock International, Inc.’s policy The Model W1690 is specifically designed for air of continuous improvement, changes may be filtering operation. DO NOT MODIFY AND/OR made at any time with no obligation on the USE THIS MACHINE FOR ANY OTHER PURPOSE. -
Page 19: Parts Breakdown And Parts List
-17-... - Page 20 X1690024 RUBBER BUSHING X1690058 LABEL (DUST MASK) X1690025 LARGE LABEL (ELECTRICAL) X1690059 LABEL (EXPLODE) X1690026 RIVET NUT M6 X 8 X1690060 LABEL (SHOP FOX) X1690027 SMALL LABEL (ELECTRICAL) X1690061 LABEL (HANDS AWAY) X1690028 RUBBER FOOT X1690029 HANDLE X1690062 HOUSING X1690030...
- Page 21 2. How long have you been a woodworker/metalworker? _____ 0-2 Years _____ 2-8 Years ____ 8-20 Years _____ 20+ Years 3. How many of your machines or tools are Shop Fox? _____ 0-2 _____ 3-5 ____ 6-9 _____ 10+ 4. Do you think your machine represents a good value?
- Page 22 FOLD ALONG DOTTED LINE Place Stamp Here WOODSTOCK INTERNATIONAL INC. P.O. BOX 2309 BELLINGHAM, WA 98227-2309 FOLD ALONG DOTTED LINE TAPE ALONG EDGES--PLEASE DO NOT STAPLE...
