Summary of Contents for Scanndy powerlineECCO+
- Page 1 Quick Reference Guide SCANNDY USER GUIDE Page 1...
- Page 2 These devices has been tested and found to comply with the limits for class B digital devices, pursuant to the CE EMC directive. For more information, please contact us at: advanced PANMOBIL systems GmbH & Co. KG Hansestrasse 91 51149 Cologne Germany E-mail: info@panmobil.com SCANNDY USER GUIDE Page 2...
-
Page 3: Product Reference
(Other function can be defined by UniversalConfigurator or API) Key 2 (Delete button) Triggers the barcode and/or RFID reader. The captured data will be deleted from the memory. (Other function can be defined by UniversalConfigurator or API) Key 3 (Custom1) Customer configurable key SCANNDY USER GUIDE Page 3... -
Page 4: Charging The Battery
PC by using the included USB cable. The PC opens the device as a memory stick where the UniversalConfigurator is located. Run the SetupSUC.exe and follow the instructions of the installation wizard. After the software is successfully installed, run the UniversalConfigurator to configure the connected device. SCANNDY USER GUIDE Page 4... - Page 5 Scan barcode, delete data Triggers the barcode reader. If the scanned barcode is found in the database it will be deleted. SCANNDY USER GUIDE Page 5...
- Page 6 Clear mass storage mode text data base Deletes the data records from the database Clear HID/SPP mode cached data Deletes the data records saved in the cache file Delete mode Presentation mode (continuous scan) at start up Section Data SCANNDY USER GUIDE Page 6...
- Page 7 Bluetooth connection to Panmobil cradle. The cradle transmits the data to the PC as a HID keyboard Bluetooth configuration The Bluetooth properties can be configured in the file “config.ini” which is located on the device memory. Connect the device to the PC and open the file “config.ini” SCANNDY USER GUIDE Page 7...
- Page 8 WEP key wepkey= wpapsk= WPA-PSK/WPA2_PSK Wireless mode(0=Auto, 1=ad-hoc peer-to-peer, 2=infrastructure) mode=2 WiFi region region=48 WiFi channel channel=0 (reserved) bssid= Note! Save the config.ini file after you have modified any settings and restart the device SCANNDY USER GUIDE Page 8...
- Page 9 SComP is intended to allow data transfer to and from, as well as remote control of, Panmobil (smart)Scanndy devices by exchanging messages between two endpoints. SComP uses message ids to allow for matching request/response pairs and assures data integrity through use of CRC-32 checksums. Its main use is to provide reliable bidirectional communication over unreliable serial communication lines.
- Page 10 Some applications require a data header as first line in the data file. The header can be set in the field “Data header” Online modes For all online modes like Bluetooth, WiFi or USB serial, the data record can be configured in the field “Data format” SCANNDY USER GUIDE Page 10...
- Page 11 For application where the device is used as a cable connected barcode reader simulation a USB keyboard, the device can be configured to send static data triggered by a keystroke. Section Time Format The time stamp saved in the data record can be configured to the requirements of the application SCANNDY USER GUIDE Page 11...
- Page 12 UHF region setting (please refer to the config.ini file description) region=8 Power save mode (please refer to the config.ini file description) pwrsave=2 read/write power 1000…1999 centi-dbm rwpower=1999 UHF fast mode fast=1 EPC Gen2 sessioning gen2session=0 UHF single frequency opration freq=0 SCANNDY USER GUIDE Page 12...
- Page 13 Barcode or Tag was found in the data file for deletion Signals: No feedback: the device does not beep or vibrate Beep: the device beeps (no vibration) Vibrate: the device vibrates (no beep) Beep and vibrate: the device beeps and starts the vibration SCANNDY USER GUIDE Page 13...
- Page 14 The advanced device configuration for Barcode, Bluetooth, WiFi ect. is saved in a file “config.ini” located on the device. Click the button “Open config.ini file” to open the config.ini file. Please Note! Changing parameters in this file will have direct effect on the device function! SCANNDY USER GUIDE Page 14...
-
Page 15: Safety And Regulatory
This equipment is intended to be commercialised in all the countries of the European Union and there is no commercialisation or operational restrictions in any of the countries. SCANNDY USER GUIDE Page 15... - Page 16 User Guide or other misuse or abuse of the product. The warranty does not cover problems linked to batteries. SCANNDY USER GUIDE Page 16...
