Lucent Technologies
Instruction Sheet
Introduction
This set of instructions contains the necessary information for field installation of the optional AC Generator
Receptacle.
Procedures
Before starting installation procedures, check the AC Generator Receptacle Kit (Comcode 107958704) to
ensure that all the following parts are included:
ITEM
1
AC Generator Receptacle Assembly
2
Base Plate Assembly
3
Spacer Panel
4
1/4-20 Flat Head Screws, 1/2 in. Long
5
1/4-20 SEELNUTS
6
Tube of RTV Sealant
7
Conduit/Fitting Assembly/Seal Ring
8
Instruction Sheet
Note:
Comcodes are for replacement purposes only.
Installation
Two different types of installations are described in this instruction sheet:
• Section A describes installing a "new" or "unpowered" cell site
• Section B describes installing a "live" or "powered" cell site.
Note:
If the installation is for a "live" cell site, refer to Section B on Page 14 before proceeding.
COMCODE 847714748
60C POWER CABINET
AC GENERATOR RECEPTACLE KIT
FIELD INSTALLATION INSTRUCTIONS
DESCRIPTION
Copyright © 1997 Lucent Technologies
All Rights Reserved
COMCODE
847793148
847899085
847770849
900787185
407631647
901059337
—
847714748
Printed in U.S.A
640-030-190-2
Issue 3, March 1997
QTY
1
1
1
5
5
1
1
1
Page 1
15 Pages
Advertisement
Summary of Contents for Lucent Technologies 60C
- Page 1 • Section B describes installing a “live” or “powered” cell site. Note: If the installation is for a “live” cell site, refer to Section B on Page 14 before proceeding. COMCODE 847714748 Copyright © 1997 Lucent Technologies Page 1 All Rights Reserved 15 Pages...
- Page 2 640-030-190-2 Instruction Sheet SECTION A Attaching AC Generator Receptacle Assembly to Rear of Cabinet: STEP 1— Viewing the power cabinet from the rear, remove three hex-head (1/4-20) screws located on the rear surface of the cabinet and discard (Figure 1). CONDUIT IN AN EXISTING OPERATING...
- Page 3 Iss 3, 640-030-190-2 Instruction Sheet Note: Refer to FIgure 2 for Steps 2 through 5. STEP 2— Locate the flat head screws, Item 4, supplied with the kit and attach the Base Plate, Item 2, to the rear of the cabinet using three of the screws supplied (the remaining screws are spares).
- Page 4 640-030-190-2 Instruction Sheet STEP 6— Apply RTV Silicone, Item 6, around the TOP AND SIDE EDGES of the box ONLY where it attaches to the surface of the cabinet to provide a continuous seal (Figure 3). Note: Do not seal bottom edge. 848504-03.id Figure 3.
-
Page 5: Terminal Block
Iss 3, 640-030-190-2 Instruction Sheet STEP 7— Ensure the AC Generator Receptacle Assembly has been shipped with the AC Utility Breaker, CB1A, in the OFF position (Figure 4). TERMINAL BLOCK EQUIPMENT GROUND IF SUBFEED 848504-07.id Figure 4. AC Generator Receptacle Schematic Page 5 15 Pages... - Page 6 640-030-190-2 Instruction Sheet STEP 8— Loosen, but DO NOT REMOVE, the compression fitting located in the bottom of the AC Generator Receptacle Assembly (Figure 5). Locate the conduit assembly, Item 7, and push the long piece of conduit up through the compression fitting located in the bottom of the AC Generator Receptacle Assembly.
- Page 7 Iss 3, 640-030-190-2 Instruction Sheet STEP 9— Loosen compression fitting nut located on the end of the shorter piece of conduit and remove the fitting portion keeping the sealing ring in place and ensure the nut and compression ring remain on the conduit (Figure 5). STEP 10—...
- Page 8 640-030-190-2 Instruction Sheet OPTIONAL SHELF 848504-09.id Figure 6. Location of AC Power Panel Inside of Power Cabinet Page 8 15 Pages...
- Page 9 Iss 3, 640-030-190-2 Instruction Sheet 13 24 R EM O V E S C R EW S T O AC C ES S C IR C U IT BR EA KE R S GN D C B7 NOTE C B1 C B8 C B9 C B2...
- Page 10 640-030-190-2 Instruction Sheet AC Utility Service Wire Installation: STEP 18— Ensure the Main Circuit Breaker, CB1, on the AC power panel inside the power cabinet is in the OFF position (Figure 7). 848504-08.id Figure 8. AC Power Panel Schematic Page 10 15 Pages...
- Page 11 Iss 3, 640-030-190-2 Instruction Sheet STEP 19— Install the Utility conduit (not provided with the kit) through the compression fitting located on the lower left side of the AC generator receptacle assembly. Loosen, but do not remove the fitting. Insert the conduit through the fitting and tighten with a tool (Figure 9). Apply RTV silicone (provided with kit) around the fitting/conduit interface to provide a continuous seal.
- Page 12 640-030-190-2 Instruction Sheet STEP 20— Connect the AC utility wiring to the neutral bus and Circuit breaker CB1A as shown in Figures 4 and 9. Note: If this Inlet is being installed as “Service Entrance Equipment”, proceed to Step 21. If not “Service Entrance Equipment”, skip to Step 22.
- Page 13 Iss 3, 640-030-190-2 Instruction Sheet STEP 26— Close the front cover of the AC Generator Receptacle Assembly and secure using the tool, Item 8, provided with the kit. Install a padlock (not provided) if required (Figure 3). NOTE NOTE NOTE 848504-06.id Figure 10.
- Page 14 Notice: Since every Cell Site location is unique, careful evaluation of the site must be performed to determine the safest and most practical method to install the AC Generator Receptacle to the 60C Power Cabinet at an operating Cell Site.
- Page 15 Iss 3, 640-030-190-2 Instruction Sheet Note: Perform Steps 1 through 6 in Section A before performing the following steps. STEP 1— Turn off the external AC service to the Power Cabinet. The system will now operate on batteries for the Initial Battery Reserve time listed in the table below. STEP 2—...
