XVision TP12 A Series Quick Start Manual

4. Specifications
Model: TP1210A
Input Power:
Output Power:
Total Output Current (Max):
Output Current (Max) per port:
2.5A for each port, however max current cannot exceed the total
Fuses Rating at:
Main Fuse Rated at:
Mounting:
Weatherproofing:
Dimensions: 187 x 226mm
TECHNICAL SUPPORT:
For Technical Support for any Xvision product please contact your local distributor.
LIMITED WARRANTY:
This product is supplied with a 1 Year warranty. The Warranty excludes products that have been misused,
(including accidental damage) and damage caused by normal wear and tear. In the unlikely event that you
encounter a problem with this product, it should be returned to the place of purchase.
Manufactured exclusively for Xvision
CCTV
TP1220A
120 / 240V AC @ 50/60Hz
12V DC
10A 20A
capacity of units rating.
250V 3A
Wall
No
281 x 255mm
TP1210A / TP1220A
Models:
12V DC 9 output 10A / 18 output 20A,
Professional Wall Mount Power Supply
Before you begin
•
Power to the unit should be correct for local electrical appliance standards & regulations.
•
Ensure the AC Input power is off before working with the unit.
•
The Unit will supply a constant voltage to all Output contacts as specified. Each Output
is protected with a PTC fuse, this will auto reset and stop any short circuit causing
damage to the device. The fuse will auto reset, note: All other Outputs will be
unaffected.
•
The unit is protected against reverse polarity and fuse fault. Should the common supplied
output be short circuited, the unit will drop the voltage until the fault is corrected. It will
immediately reset the voltage when the fault is removed. The same applies when
exceeding the Current specification.
Model:
TP12xxA Series
12V DC PTC fused protected outputs,
Professional Wall Mount Power Supply
