Tunap Microflex Injecto 13310 Operating Manual

Gen. Operating Manual
Version 1 – 2020
13310- Injecto Clean Machine 2020 for Injector cleaning
diesel & gasoline fuel injection systems
Introduction
We congratulate you on purchasing the TUNAP Injecto Clean Machine 2020 and thank you for the trust you have placed
in us. With the TUNAP ICM cleaning system, we have implemented the latest technology in the field of injector cleaning.
This enables you to achieve the best cleaning results and high customer satisfaction while at the same time reducing costs
sustainably. In order to be able to use the full function of the system, we ask you to carefully observe the information and
notes summarized in this operating manual.
Device description
1
2
3
1 Pressure gauge
2
Pressure regulator
3
Quick coupling for the return (black)
4
Quick connector for the inlet (blue)
5
Display
6
Off / On button
Technical specifications
Weight
power
The specifications provided in this Service Information sheet are the results of careful analysis. Any application-related specifications shall be viewed as recommen-
dations based on past experiences. Due to the wide variety of applications and work methods, we are unable to provide binding specifications. Therefore, there exists
no contractual legal relationship, nor will secondary obligations arise from any purchase contracts. Only the most recent version of the Service Information sheet
retains its validity.
TUNAP GmbH & Co. KG | D-82515 Wolfratshausen | Tel. 08171 / 16 00 – 0 | info@tunap.com | www.tunap.com
5
4
12.8 kg
0.192 Kw
Device description
6
7
8
7
Button to set cleaning time
8
Level indicator
9
Connection terminals 12V DC
10 Fuel filter
11 15A fuse
12 Filler coupling
nominal voltage
12
11
9 10
12V DC
