User Guide - ATU
Contents
1
Generalities ...................................................................................................................................... 2
2
Software Installation ........................................................................................................................ 3
3
Hardware ......................................................................................................................................... 4
4
Software Manual .............................................................................................................................. 4
5
Position measurement (ATU-1 and ATU-2) .................................................................................... 5
6
Measuring of signal accuracy (only ATU-2) .................................................................................... 6
7
Functional Reserve (Only BISS/C) .................................................................................................. 7
8
Register operations (ATU-1 and ATU-2) ......................................................................................... 8
1 von 8
AMO GmbH ATU Test kit
Technical Data are subject to change without
notice
User Guide ATU v.5.0 Test
kit.docx-5.0
Advertisement
Table of Contents
Related Manuals for AMO ATU
Summary of Contents for AMO ATU
- Page 1 Hardware ............................4 Software Manual ..........................4 Position measurement (ATU-1 and ATU-2) ..................5 Measuring of signal accuracy (only ATU-2) ..................6 Functional Reserve (Only BISS/C) ....................7 Register operations (ATU-1 and ATU-2) ..................8 Technical Data are subject to change without User Guide ATU v.5.0 Test...
- Page 2 Hardware: ATU Box (ATU-1 or ATU-2); USB cable (ATU to PC); Connection cable (ATU-1 to reading head) or 2 connection cables (ATU-2 to Adapter Box and Adapter Box to reading head); Adapter Box (only for ATU-2); Power supply unit (12V for ATU-1 or 5V for ATU-2).
- Page 3 User Guide - ATU ATU-1 Test Kit ATU-2 Test Kit 2 Software Installation Download software from official site of AMO GmbH (http://www.amo-gmbh.com/); Launch the file AMO_ATU_Setup to install the complete program; Technical Data are subject to change without User Guide ATU v.5.0 Test...
- Page 4 User Guide - ATU 3 Hardware Check polarity of Power supply unit and connect it to the ATU Box (for ATU-1) or to Adapter Box (for ATU-2); Connect the ATU Box with the PC (USB) and wait until the PC recognized and installed the ATU Box;...
- Page 5 Check the geometrical mounting conditions (use Mounting Instructions https://www.amo- gmbh.com/ If the ATU Box was connected successfully, you can start getting position with click at “Start” button. If something goes wrong during measurements, you will see error messages. Please follow the instructions and try again.
- Page 6 Before measuring of signal accuracy ensure that you get no error for total measuring distance using Position measurement function. If the ATU Box was connected successfully, you can measure signal accuracy by activating of “Signal accuracy” window. The signal deviations can be evaluated by moving the measuring head along the scale (or measuring flange) with a constant speed.
- Page 7 Check the geometrical mounting conditions (use Mounting Instructions https://www.amo- gmbh.com/). If the ATU Box was connected successfully, you can start getting functional reserve value with click at “Start” button. !! The Functional Reserve value is updated during the movement. After power-on the Functional Reserve (grey slider thumb) will always be in the middle of the green area (black markers) till movement is detected by the measurement system.
- Page 8 Revision (Address 0x7D). Access to the register is possible with ATU-1 and ATU-2 devices. The ATU Unit must be connected to USB Port and also initialized in the ATU Software (by pressing the "Connect Device" button). The ATU Software allows accessing 128 Bytes (0x00 – 0x7F) from the BiSS-C Encoder registers.
