Summary of Contents for Art DAM-3028D
- Page 1 DAM-3028D User’s Manual Beijing ART Technology Development Co., Ltd.
- Page 2 Power Supply: unregulated +10~+30V Power Consumption: 2.6W@24V Industrial Design DAM-3028D was designed to use in industrial environment. It can be installed in standard DIN rail inside the cabinet. And it can be powered by unregulated 10V ~30V to meet the various power supplied ℃...
- Page 3 According to the label directs color to wiring: +Vs （R） Red DATA+ （Y） Yellow DATA- （G） Green GND（B） Black DAM-3028D Fig. 1 DAM-3028D Drawing DAM-3028D can be installed in standard DIN rail inside the cabinet, it also can be installed by stacking mode. Fig.2 standard DIN installation...
- Page 4 DAM-3028D User’s Manual V6.13 Fig.3 stack installation Wiring Application Reset Connection: Shorted the INIT * and GND shorted, add +10 ~ +30 VDC between +Vs and GND, power on, the module indicator quickly flashes three times, power off until the indicator stops flashing, disconnect the INIT * and GND, then reset the module has been completed.
- Page 5 DAM-3028D User’s Manual V6.13 Default Setting If the module’s address or baud rate is wrong, or forget the last modified value, the module can be reverted to default settings. Steps: Short-circuit the “INIT*” and “GND” when there is no power; power-on for 3 seconds, power off, disconnect “INIT*”...
