- Page 1 ASSEMBLY INSTRUCTIONS COASTER FINE FURNITURE Fine Furniture for every stage of life 212421KW(B1&B2) California King Bed REVISION 0 : 01/18/2021 COASTERFURNITURE.COM PAGE 1 OF 4...
-
Page 2: Parts Identification
FROM BOX 1 FOOTBOARD 212421KW(B1) FROM BOX 1 HEADBOARD COMPLETE HARDWARE IDENTIFICATION Z-B1 (BOX 1) - HARDWARE PACK IS LOCATED IN 212421KW (B1) BIG ALLEN BOLT 6PCS WRENCH (M6 x 30mm - BLK) (M5 x 65mm - BLK) PAN HEAD... - Page 3 212421KW (B1&B2) ITEM: ASSEMBLY INSTRUCTIONS STEP 1 STEP 2 LOOSEN STICKER LEFT **BACK VIEW** STICKER RIGHT Note: Please take note of the marking sticker ( L & R) on the headboard legs. STEP 3 PAGE 3 OF 4 COASTERFURNITURE.COM...
- Page 4 212421KW (B1&B2) ITEM: ASSEMBLY INSTRUCTIONS STEP 4 TIGHTEN leveler leveler STEP 5 COMPLETE PAGE 4 OF 4 COASTERFURNITURE.COM...
- Page 5 212421KW (B1&B2) ITEM: INNER SIZE : 76.93" X 85.98" 79.45" 31.34" 56.50" 14.57" 73.62" 9.65" 79.06" 16.81" 25.20" 85.98" 88.03" 74.80" 8.66" 3.54" Note : Dimension tolerence ± 5% COASTERFURNITURE.COM...
