Intellinet 164603 Quick Instruction Manual

19" Rackmount 16-Port USB-A Power Distribution
Unit (NEMA 5-15)
With Overload Protection Power Switch, 2.1 A Max. per Module, 2m (6.6 ft.) Power
Cord
Part No.: 164603
The Intellinet Network Solutions 19" Rackmount 16-Port USB-A Power Distribution
Unit (PDU) provides reliable power distribution via a single input to multiple output
receptacles. Designed for installation at the front of a 19" network rack, this PDU
provides easy access to power up to 16 portable electronic devices. The PDU distributes
2.1 amps of power to each port to support the fast-charging of each connected device.
Simply connect devices to the Intellinet Network Solutions 19" Rackmount 16-Port
USB-A Power Distribution Unit with compatible USB-A cables and devices will charges
safely and securely in the rack.

Features:

19" 1U rackmountable USB power distribution unit
Bracket installation style: front
16 USB type-A sockets
Aluminum chassis
Overload protection switch
Three-year warranty

Specifications:

General
• 19" rackmount PDU
• Socket/outlet standard: USB type A
• Outlets: 16
• Cable specification: standard 2 m (6.6 ft.) power cord
• Dimensions: 482 (L) x 45 (W) x 40 (H) [mm] / 18.98 (L) x 1.77 (W) x 1.57 (H) [in]
• Rated voltage: 110 V
• Rated current: 15 A
• Max output power: 1650 W
• NEMA 5-15 Plug type

Package Contents

• 19" Rackmount 16-Port USB-A Power Distribution Unit (NEMA 5-15)
